Thermal Arc 400MSTW CC Operating Manual

Thermal Arc 400MSTW CC Operating Manual

Inverter arc welder
Hide thumbs
Table of Contents

Advertisement

Quick Links

A THERMADYNE
Company
®
INVERTER
ARC
WELDER
MODEL 400MSTW CC/CV
• STICK
•TIG - Lift Start
•MIG - Short Circuit
- Globular
- Spray
OPERATING MANUAL
July 1, 2001
Manual No. 430429-490

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 400MSTW CC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Thermal Arc 400MSTW CC

Summary of Contents for Thermal Arc 400MSTW CC

  • Page 1 A THERMADYNE Company ® INVERTER WELDER MODEL 400MSTW CC/CV • STICK •TIG - Lift Start •MIG - Short Circuit - Globular - Spray OPERATING MANUAL July 1, 2001 Manual No. 430429-490...
