Transmitter/Microphones - TeachLogic Neo Owner's Manual

UT-96BP Body-Pack Transmitter Operation
To change channel selection
13.
• Press and hold frequency SET button for 2
seconds
• LCD panel will commence flashing (indicating
programming mode)
• Press UP or DOWN arrow to select channel
desired
• Press SET button to lock in channel selected
The battery status is displayed on the left edge
14.
of the LCD screen.
• When battery nears depletion: Icon will flash
15.
3 times
• Transmitter will automatically turn "off" to
prevent damage
To turn microphone "Off"; push power switch
16.
to "OFF".
LM-835 Lapel Microphone
The Lapel Microphone (LM-835) is a small capsule
microphone with a spring clip for securing it
on to a clothing edge. The lapel microphone
renders excellent vocal reproduction. The lapel
microphone is less obtrusive to the user and least
visible.
However, due to the greater distance from mouth
to microphone it will require additional gain. As a
result it is more prone to feedback. So adjustment
of volume is more critical, especially near or under
a speaker.
HBM-935 Headband Microphone
The Headband Microphone (HBM-935) is worn
around the head with a unidirectional microphone
located on the end of a flexible boom. This
is the best performing microphone due to its
unidirectional mic element and its always close
proximity to the mouth. The microphone also
renders maximum gain and is least prone to
feedback.
Owner's Manual

TRANSMITTER/MICROPHONES

25
