10-3 VOLTAGE DIAGRAM

J1
HEC0470-01-230

10-4 BOARD LAYOUT

J1
MP1
MP2
C : 13.8V
N : 13.8V
R1 68
R2
DS1
1k
TLG124A
C : 9.2V
N : 13.8V
10 - 2
C : 7.2V
N : 13.8V
R2
R1
B5650
MP1
MP2
