- Page 1 FAD906-PXS 9925114 630006071 HANDBOOK WALL MOUNTED UPDATED NOVEMBER 2007 CONTROL TYPE ELECTRONICS 3 SPEED + INTENSIVE 3 HALOGEN LAMPS X20 W EACH ONE STAINLESS STEEL CHARCOAL FILTER 9925204 OUTLET TUBE DIAMETER 150 MM - ( 120 MM ADAPTOR SUPPLIED)
- Page 3 FUNCTION T1 ON-OFF MOTOR Switches the hood motor on and off. The latest selected speed appears on the display. T2 SPEED - Decreases the suction speed: V3 →» V2 →» V1 T3 SPEED + Increases the suction speed: V1 →» V2 →» V3 T4 INTENSIVE SPEED Activates the intensive speed from any previously selected speed.
- Page 4 ì...
- Page 5 CONTROLS ASSEMBLY GRUPPO COM.K-CS/M-CS 6-1D ORIZ.FRANKE 1960128 GLASS CONTROL BOARD VETRINO COMANDI FRANKE PC 1960627 CONTROL BOARD BOX -1 D.FRANKE GM S SCATOLA COM.6-1 D.FRANKE GM S.M-CS OR 1960628 CONTROLS BOARD SCHEDA TASTIERA 6-1 DIGIT ROSSI ORIZZ. 1960129 COVCER CONTROL BOARD PP-V2 COPERCHIO COMANDI PA 6.8 V0...
- Page 6 1960171 SPACER CONNECTION FOR RECIRCULATING DISTANZIALE RACC.FILT.DISASS.(PARETE) 1960200 SPIGOT 120-150 FLANGIA RIDUZIONE 150-120 BK 1960346 LOWER CHIMNEY CAMINO INFERIORE RETT.X A545 S.FRANKE 1961079 BRACKET EASY CUBE STAFFA D09 ZN EASY CUBE 1960218 PARTICULAR CABLE GUIDE PARTICOLARE PASSACAVO (V2) 1960166 CAPTIVATED NUT 5004-A 4M...
- Page 7 POSIZIONE SPARE DESCRIPTION DESCRIZIONE QUANTITY POSITION PART CODE 1960103 REFINING COVER F. EASY CUBE TAPPO RIFINITURA PER EASY CUBE 1960224 SECURING PIN D4,6X11 CLIP D4,6X11 ART.000670111 BK...
-
Page 13: Legenda Schema Elettrico
LEGENDA SCHEMA ELETTRICO Autotrasformatore di avviamento TRASFORMATORE Condensatore Connessione disinserire Lampada Direction Lamp Lampada spia Morsettiera Motore Micro potenza Pulsante Scheda Scheda Starter VENTOLA...
