- Page 1 Istruzioni per l’uso e l’installazione Cappa Instructions for use and installation Cooker Hood Mode d’emploi et installation Hotte de Cuisine Bedienungsanleitung und Einrichtung Dunstabzugshaube FSW 918 TC W BK XS-CH FSW 918 TC W WH XS-CH...
- Page 2 INDICE CONSIGLI E SUGGERIMENTI.............................. 3 CARATTERISTICHE................................4 INSTALLAZIONE ................................... 6 USO......................................9 MANUTENZIONE ................................11 INDEX RECOMMENDATIONS AND SUGGESTIONS ........................14 CHARACTERISTICS ................................15 INSTALLATION..................................17 USE ...................................... 20 MAINTENANCE ................................... 22 SOMMAIRE CONSEILS ET SUGGESTIONS............................25 CARACTERISTIQUES................................. 26 INSTALLATION..................................28 UTILISATION ..................................
-
Page 3: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS The Instructions for Use apply to several versions of this appliance. Accordingly, you may find descriptions of individual features that do not apply to your specific appliance. INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or im- proper installation. -
Page 4: Characteristics
CHARACTERISTICS Components 7.2.1 Ref. Q.ty Product components Cooker hood with control unit, lights, blower unit, filters Upper chimney Lower chimney Air outlet grid Cover for recycling version Sucker Ref. Q.ty Installation components 7.2.1 Fixing brackets for upper chimney Plugs Plugs SB 12/10 Screws 4,2 x 44,4 Screws 2,9 x 6,5 Screws 2,9 x 9,5... - Page 5 Dimensions Min. Min. 368mm 368mm 1 16...
-
Page 6: Wall Drilling And Bracket Fixing
INSTALLATION Wall drilling and bracket fixing 1÷2 7.2.1 249 249 210 210 As a first step, proceed with the following drawings: • a vertical line up to the ceiling or up to the upper limit, at the centre of the area in which the hood is to be fitted;... - Page 7 Fitting the Hood canopy • Adjust the two screws Vr, in the brackets 11a, so that they are at the start of their travel (B). • Hook the hood body to the two brackets 11a. • Connect the Hood to the Mains Power Supply, inserting a bipolar switch with a contact aperture of at least 3mm.
-
Page 8: Maintenance
RECYCLING VERSION AIR OUTLET To install the hood in recycling version, the optional charcoal filter kit must be purchased. • Remove the chimney angle bracket. • Screw the filter cover onto the air outlet, using four screws 12c (2.9 x 12.5). •... -
Page 9: Control Panel
Control panel -When power is supplied to the hood, LED A flashes for approximately 10 seconds; during this time the interface is not enabled. -When the control panel functions are not active only button A can be seen. When this is pressed all the other commands become visible. -The functions selected are shown by backlighting the button at maximum intensity, while the other buttons are lit at reduced intensity. -
Page 10: Remote Control Panel
REMOTE CONTROL (OPTIONAL) The appliance can be controlled using a remote control powered by a 1.5 V carbon-zinc alkaline batteries of the standard LR03-AAA type (not included). • Do not place the remote control near to heat sources. • Used batteries must be disposed of in the proper manner. - Page 11 MAINTENANCE Metal grease filters These filters can be washed in a dishwasher, and need to be cleaned when the Button F LED on the display lights up in a con- tinuous manner or at least once every approximately two months' use, or more frequently in the case of particularly intensive use.
-
Page 12: Changing The Activated Charcoal Filter
Activated Charcoal Filter (Recirculation Version) This cannot be washed or regenerated, and must be changed when the F button LED on the display starts to flash, or at least once every 4 months. The Alarm signal must be activated in advance. -
Page 13: Light Replacement
Lighting LIGHT REPLACEMENT 20 W halogen light. • Extract the lamp from the lamp holder by pulling gently. • Replace with another of the same type, making sure that the two pins are properly inserted in the lamp holder socket holes. Lighting unit REPLACING OF THE LED UNIT •... - Page 14 Franke S.p.a. Via Pignolini,2 37019 Peschiera del Garda (VR) www.franke.it 436005650_ver1...
