APPLE 2 PEAR
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for iCandy APPLE 2 PEAR

Summary of Contents for iCandy APPLE 2 PEAR

  • Page 1 APPLE 2 PEAR INSTRUCTION MANUAL...
  • Page 2 APPLE 2 PEAR Welcome to the world of iCandy IMPORTANT: Keep these instructions for future reference. Read carefully. Your child’s safety may be affected if you do not follow these instructions. WARNING: Never leave your child unattended. If you have any problems or queries, please contact your local stockist or read the FAQ’s at www.icandyworld.com...
  • Page 3 APPLE 2 PEAR...
  • Page 4 The iCandy Apple 2 Pear is tested to comply with AS/NZS 2088:2000 and Consumer Protection Notice Nº. 8 of 2007. IMPORTANT: This stroller has been modified specifically for the Australian market and includes a red brake operator, tether strap and labeling which may differ from images shown.

  • Page 5: Chassis

    APPLE 2 PEAR Section 1 - Chassis Contents Chassis including: front wheels x 2 • basket • rear wheels x 2 • rear axle / brake bar assembly Seat unit including: Seat frame • seat fabric • safety harness and pads • PVC raincover 1.
  • Page 6 APPLE 2 PEAR 2. Fitting the brake bar / rear axle assembly: Turn the chassis upside down. Position the brake bar / rear axle assembly with the brake levers uppermost and push down onto rear leg. Pull firmly on each side of the brake bar/rear axle assembly to check that both sides are securely locked into place.
  • Page 7 APPLE 2 PEAR 4. To remove the rear wheels: Lift the rectangular shaped locking catch and remove the wheel from the axle. Note: Inflating the air filled tyres (available separately as an accessory). Use only the pump provided or a similar hand / foot pump device.
  • Page 8 APPLE 2 PEAR 6. Front wheels: Can be selected in fixed or swivel position by rotating grey disc behind wheels. (Swivel position is required for folding chassis). Useful tip: if the swivel device is rotated in use the wheels will automatically lock into fixed position when the wheel is next in line...
  • Page 9 APPLE 2 PEAR 8. To fold chassis: (Remove seat/bassinette before folding): Ensure the basket is empty and apply brakes. Switch front wheels to swivel mode. (See 6). Squeeze the central handle button  depress the circular secondary lock button  on the left arm of the chassis.

  • Page 10: Seat Unit

    APPLE 2 PEAR Section 2 - Seat Unit (All seat units) (Shown with Raspberry Blue Flavour Pack hood - available separately). 1. Attaching the hood: Attach the hood clips into the receptor brackets on the seat frame ensuring both locking tabs are fully engaged.
  • Page 11 APPLE 2 PEAR 4. Fold down rear fabric over the seat frame and adjust hood to the desired position. Useful tip: The peak of the hood is extendible and can be folded back into the hood when not required. 5. Removal of hood: Lift the rear fabric up over the seat frame and insert the hood removal / operation key into the zip puller.
  • Page 12 APPLE 2 PEAR 5. Depress both locking tabs firmly before removing from sockets. 6. Attaching seat unit: Insert the seat attachment arms into the main connectors on the chassis. Push down on each side to engage. Check security of seat by pulling upwards.
  • Page 13 APPLE 2 PEAR 8. To remove the seat unit: (Remove child first). Depress the circular grey button on each side of the seat simultaneously and lift the seat unit upwards. 9. To fold the chassis with the Apple 2 seat attached: Folding is shown with seat unit rearward facing.
  • Page 14 APPLE 2 PEAR 10. Folding of the chassis itself is the same as in steps 7 & 8 - Section 1.  Squeeze the central handle button depress the circular secondary lock button  on the left arm of the chassis.

  • Page 15: Safety Harness

    APPLE 2 PEAR Safety Harness Securing your child using the 5 point safety harness: Push the left and right connectors (a) into the buckle housing & click together. Adjust the length of the straps using slider buckles (b). To release connectors: Squeeze the connectors inwards (c) and pull out of the buckle housing.

  • Page 16: Bassinette

    APPLE 2 PEAR Section 3 - Bassinette Contents Bassinette including: • mattress • padded liner • handle • hood • apron • raincover 1. Initial assembly: Remove the apron, bassinette mattress and liner to access the base board. Useful tip: The liner is secured by press studs under the hood also.
  • Page 17 APPLE 2 PEAR 3. Operation of the hood: Pull up the handle as shown until the locking devices engage with a positive "Click". Check that the handle is secure before placing your baby in the bassinette. IMPORTANT: Do not attempt to over extend the handle.
  • Page 18 APPLE 2 PEAR 6. Pull down the stabiliser frame and lock onto the basket bar as shown. 7. Removal of bassinette: Release and store the stabiliser bar. Depress the circular grey release buttons as shown and lift bassinette.
  • Page 19 fires, gas fires etc, in the vicinity of the bassinette. 4. The iCandy Apple 2 bassinette is not a safe means of transport by car and should NEVER be used as such. Use an approved car safety seat for transport by car.

  • Page 20: Car Seat Adaptors

    APPLE 2 PEAR Section 4 - Car Seat Adaptors Available separately to fit the Maxi Cosi Mico Air Protect and Maxi Cosi Titan Air Protect infant carrier car seats. 1. Fitting the car seat adapters: Depress the central button and fit the adaptors into the left and right sides of the main chassis connectors.
  • Page 21 APPLE 2 PEAR 2a. Fitting the infant car seat - Maxi Cosi Mico Air Protect (Rearward facing only). Ensure adaptors are aligned with the fixing slots on each side of the car seat. Press down firmly to ensure the car seat is firmly locked onto the adaptors.
  • Page 22 APPLE 2 PEAR 3a. Removing the infant car seat - Maxi Cosi Mico Air Protect. Depress the 2 grey buttons on either side of the car seat to disengage the locking devices and lift. Useful tip: It may be easier to do this if the handle is positioned to the rear of the car seat.
  • Page 23 APPLE 2 PEAR 4. Removing the car seat adaptors: Depress the central release button as shown and lift adaptors.

  • Page 24: Converter System

    Box 1: As Apple single pushchair (See section 1). Box 2: Apple 2 Pear conversion system (a) Apple 2 Pear seat unit with frame (b). PVC rain cover (not shown). For single pushchair assembly and operation, including fitting the Flavour Pack hood and using the safety harness, please see section 1 of these instructions.
  • Page 25 APPLE 2 PEAR Attaching the Apple 2 Pear conversion system. 1a. Attaching the upper adaptor arms: Depress the central grey button and insert both of the upper adaptor arms into the main connectors on the chassis. The extended portion of the arms should face towards the front of the pushchair.
  • Page 26 APPLE 2 PEAR 1c. Align the lower receptor bracket with the ridges on the frame attachment device. Depress the spring clip on the inside of the lower receptor bracket and slide the bracket down onto the frame attachment device. Press down firmly until "click" is heard.
  • Page 27 Useful tip: You may need to slide the hold together strap to the side to ensure a positive fit of the seat attachment bracket. WARNING: Check that the Apple 2 Pear converter system is correctly fitted before use. Useful tip: The lower Apple 2 Pear...
  • Page 28 APPLE 2 PEAR Attaching the Apple 2 Pear seat units – (all seat units): (Shown with Raspberry Blue Flavour Pack Hood - sold separately). 2a. Orientate the seat unit to face forwards and insert the seat attachment arms into the Apple 2 Pear lower adapter brackets.
  • Page 29 APPLE 2 PEAR 3. To recline the seat unit (all seat units): Depress the grey buttons simultaneously and rotate the seat to desired position. Note: The upper seat features 2 recline positions when in Pear 2 tandem mode. This is to ensure there is no interference between upper and lower seat units.
  • Page 30 APPLE 2 PEAR 5. To fold the chassis with the Apple 2 Pear seat units or with lower Pear 2 Newborn Nest attached: Ensure the basket is empty and apply the brakes. Switch the front wheels to swivel mode. (See 6 - Section 1).
  • Page 31 APPLE 2 PEAR 6. Fold the chassis by following instructions in section 1, steps 8 & 9. Squeeze the central handle button and depress the circular secondary lock button on the left arm of the chassis. Slide the handle downwards to its lowest point and push down sharply to disengage the main locks and fold the chassis.
  • Page 32 1 x Newborn nest fabric including base, mattress and apron. The Newborn Nest fabric has been designed to fit on the Apple 2 Pear seat frames. 1. Converting the seat frames - removing the seat unit fabric: Remove the hood as shown in section 2 and release the press stud closures at each side of the seat.
  • Page 33 APPLE 2 PEAR 3. Once the fabric is off the frame, pass the webbing security strap over the foot end of the frame. Your frame is now ready to fit your Newborn Nest. 4. Pear 2 Newborn Nest fabric. Remove the apron.
  • Page 34 APPLE 2 PEAR 6. Secure the webbing safety straps around the frame and through the metal rings. Attach the velcro security strap. 7. Secure each set of velcro loops around the seat frame and wrap the upper edge of the Newborn Nest fabric over the seat frame.
  • Page 35 10. Attach the apron to the Newborn Nest frame using the press stud closures on the frame and inside of the hood. Note: To re-fit the Apple 2 Pear seat fabrics, simply reverse these steps and follow from 10 - 1.

  • Page 36: Newborn Nest

    fires, gas fires etc, in the vicinity of the Newborn Nest. iCare The Newborn Nest fabric body and the apron are washable at 30 degrees. Do not bleach, tumble dry, iron or dry clean. Allow to dry naturally. The Apple 2 Pear Flavour Pack hood is sponge clean only.
  • Page 37 Push down on each side to engage. 10b. Orientate the upper Newborn Nest to face rearwards and insert the attachment arms into the Apple 2 Pear upper adapters. Push down on each side to engage. Check security of each nest by pulling upwards.
  • Page 38 APPLE 2 PEAR 11. To remove the Newborn Nests: (Remove child first). Depress the circular grey button on each side of the frames simultaneously and lift the Newborn Nest upwards.
  • Page 39 1b. Fitting the lower car seat adapters: Orientate and fit the lower adaptors onto the left and right sides of the Apple 2 Pear lower adapter brackets. Push down firmly to engage.
  • Page 40 APPLE 2 PEAR 2a. Fitting the lower infant car seat - Maxi Cosi Mico Air Protect or Titan Air Protect (Rearward facing only). Ensure adaptors are aligned with the fixing slots on the car seat. Press down firmly to ensure the car seat is firmly locked onto the adaptors.
  • Page 41 APPLE 2 PEAR 2b. Fitting the upper infant car seat - Maxi Cosi Mico Air Protect or Titan Air Protect (Rearward facing only). Ensure adaptors are aligned with the fixing slots on the car seat. Press down firmly to ensure the car seat is firmly locked onto the adaptors.
  • Page 42 APPLE 2 PEAR 3a. Removing the infant car seats - Maxi Cosi Mico Air Protect or Titan Air Protect (all positions). Depress the 2 grey buttons on either side of the car seat to disengage the locking devices and lift.
  • Page 43 Depress the moulded release button as shown and lift adaptors. Removing the Apple 2 Pear conversion system 5a. Removing the upper Apple 2 Pear adaptor arms: Depress the circular grey release button as shown and lift the upper adapter arms.
  • Page 44 APPLE 2 PEAR 5b. Removing the lower Apple 2 Pear adaptor brackets: Depress the spring clip at the base of the attachment bracket and lift upwards and off the frame attachment devices. Gently push the frame attachment devices forward away from the rear legs and store with the fitting bracket.

  • Page 45: Configurations

    Section 8 - iCandy Apple 2 Pear Configurations “Which mode am I in today?” The iCandy Apple 2 Pear is a versatile multi-functional design which enables you to adapt your stroller to your family’s requirements. 1. Chassis & seat unit forward facing – 3 position recline 2.
  • Page 46 APPLE 2 PEAR 4. Chassis and Maxi Cosi Mico Air Protect infant car seat (rearward facing only) 5. Chassis & Maxi Cosi Titan Air Protect infant car seat (rearward facing only)
  • Page 47 APPLE 2 PEAR New Pear 2 Tandem 1. 2 x seat units - upper & lower (Both seats are same size & universal. Upper seat is restricted to 2 position incline by moulding to prevent interference) 2. 2 x Newborn Nests - facing toe to toe (both upper &...
  • Page 48 APPLE 2 PEAR 4. 2 x Maxi Titan Air Protect car seats (both facing rearwards - lower car seat adaptors are swan neck shaped, upper adaptors are straight) Pebble infant car seat (rearward facing only) 5. 1 x upper seat (facing forward), 1 x Newborn Nest (facing forward) 6.
  • Page 49 APPLE 2 PEAR 7. 1 x upper seat (facing forwards), 1 x lower Maxi Cosi Titan Air Protect car seat (facing rearwards) 8. 1 x lower Newborn Nest (facing forward), 1 x upper Maxi Cosi Mico Air Protect car seat (facing rearwards) 9.
  • Page 50 APPLE 2 PEAR 10. 1 x lower seat unit (facing forwards), 1 x upper Maxi Cosi Mico Air Protect car seat (facing rearwards) 11. 1 x lower seat unit (facing forwards), 1 x upper Maxi Cosi Mico Titan Air Protect...
  • Page 51 APPLE 2 PEAR Section 9 - Accessories Accessories available for the iCandy Apple 2 Pear: 1. Apple 2 Pear flavour pack hood 2. Footmuff 3. Apple 2 main / Pear 2 upper car seat adaptors...
  • Page 52 APPLE 2 PEAR 4. Apple 2 Pear converter system 5. Apple 2 Pear lower car seat adaptors 6. Apple 2 Pear seat fabric...
  • Page 53 APPLE 2 PEAR 7. Pear 2 newborn Nest fabric 8. Palm sunshade 9. Parasol/cupholder clamp...
  • Page 54 APPLE 2 PEAR 10. Cupholder 11. Lifestyle changing bag 12. Rear Air tyres available separately...
  • Page 55 Your child’s safety may be affected if you do not follow these instructions. Your iCandy Apple 2 Pear is intended for children from birth up to 15kg per seat (3 years approximately). Your iCandy Apple 2 Pear chassis is suitable for use with the Apple 2 Pear seat unit(s), Apple 2 bassinette, Pear 2 Newborn Nest pram body, Maxi Cosi Mico Air Protect and Maxi Cosi Titan Air Protect infant car seats.
  • Page 56 • Always use the tether strap to stop the stroller rolling away. • Take care when using the iCandy Apple 2 Pear stroller on stairs or escalators and never try to lift this stroller by the bumper bar.
  • Page 57 APPLE 2 PEAR • iCandy Apple 2 bassinette is not intended for use as an infant restraint device in a motor vehicle. • The iCandy Apple 2 bassinette is only suitable for use on the iCandy Apple 2 chassis. When using the iCandy Pear 2 Newborn Nest •...

  • Page 58: General Use

    • The brakes and wheels are subject to wear and should be replaced as and when necessary. • Should any part of your iCandy Apple 2 Pear become stiff or difficult to operate, ensure that dirt is not the cause. Then try a light application of a sprayable lubricant e.g. Silicone spray, ensuring that the lubricant penetrates between the components, but take care as excessive application may encourage the accumulation of dirt.
  • Page 59 We would encourage all customers to register their iCandy product on-line using your serial number which can be found on the packaging of each iCandy item, on the shopping basket frames of the chassis, on the base boards of the bassinette and on the seat boards beneath the seat units.
  • Page 60 We are continually looking at ways to improve our iCandy product range and welcome feedback on design, materials, user friendliness and our instructions as well as your own iCandy experience. If you have any feedback, please write to us at the address on the back of this manual.
  • Page 61 APPLE 2 PEAR...
  • Page 62 APPLE 2 PEAR...
  • Page 63 APPLE 2 PEAR...
  • Page 64 APPLE 2 PEAR The iCandy Apple 2 Pear is a quality product of British design and is distributed by Tobil & Co. Pty Ltd. For further technical information please contact your place of purchase, e-mail: info@tobil.com.au or visit www.icandyworld.com/au/en Imported into and distributed in Australia by: Tobil &...
