722 User Guide and Technical Information
Inputs/Outputs – Digital
AES3-id
Digital Storage
Internal hard drive
Compact Flash
File Types
Utilities
Data Transfer / Control
FireWire
C. Link
Powering
Internal Voltages
Power supply (batteries)
Power supply (external)
Environmental
Operation and Storage
Other
LCD Display
Tone Oscillator
Quick Setups

Dimensions and Weight

Size
Mass
46
firmware v. 1.15
75 ohm, 0.5 V p-p, S/PDIF compatible with RCA adapter
ATA-5 interface 1.8-in or 2.5-in hard drive 4200–7200 RPM supported, FAT32 formatted, up to 2 TB
addressable
CF type I, II, and + (microdrive) compatible, FAT32 formatted, up to 2 TB addressable
WAV, mono or polyphonic, at supported Fs, 24-bit or 16-bit
MP3 @ 64, 96, 128, 240, or 320 kb/s stereo
Format, speed test, and repair utility for internal HD and CF volumes
peripheral-mode, IEEE-1394a compliant, 6-pin FireWire, Windows 2000, XP, Mac OS X only
6-wire modular input and output, RS-232 machine control, word clock, time code transfer (744T)
±16 VDC regulated audio rails
5 VDC data
3.3 VDC data
1.5 VDC DSP core
48 VDC phantom power
operating cell, removable 7.2 V (nominal) Sony M- or L-type Li-on, operational from 6–8 V
10–18 V, 1000 mA minimum, via locking 4-pin Hirose connector, use Hirose #HR10-7P-4P
(DigiKey# HR100-ND) for locking mating DC connector; pin-1 (−), pin-2 (−), pin-3 (+), pin-4 (+).
See Powering section for additional details
Ambient temperature 5–55° C,
Relative humidity (non-condensing) <80%
202 x 32 pixels, extended temperature, backlit display
100 Hz–10 kHz, variable output, assigned to tracks or outputs (menu-selectable)
Four factory presets, one user setup stored to CF or HD as data file
45 mm x 209 mm x 125 mm (H x W x D)
1.8" x 8.2" x 4.9"
unpackaged: 1.2 kg, (2.6 lbs) without battery
Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
