1. OVERVIEW

1.1 Product Description

With the high storage capacity feature, this MPEG-4 DVR model is designed to accommodate up to 3 HDDs, or
accommodate 2 HDDs and connect 1 independent disk array depending on your needs. To quickly backup, a CD or DVD
writer (optional) and USB interface are built in for your choices except for network backup. Remote Event Trigger
Recording (R.E.T.R.) can be activated remotely and any event recording will be saved in the specified path in your PC. An
IR transmitter is also supplied for remote control.

1.2 Features

MPEG4 DVR Technology
‧ Compression format providing crystal clear images with real time performance
Multiplex Operation
‧ Allow live display, record, playback, backup, and network operations at the same time
Remote Independent Operation
‧ Allow you to individually see the live view of a single channel without changing the main display setting from AP side
Huge Storage Capacity
‧ Support up to 3 HDD accommodation, or 2 HDD accommodation + 1 independent disk array (optional)
Free Upgrade to Advanced Functions
‧ Allow you to upgrade DVR functions without any charges
Long-Recording Hours
‧ 500GB can record more than 52 days (16CH, CIF Normal Quality, 60IPS)
‧ 500GB can record more than 104 days (8CH, CIF Normal Quality, 30IPS)
‧ Connect to Independent Disk Array (optional) to have more storage capacity
Backup Function
‧ Support CD or DVD writer backup (optional), USB flash drive backup & network backup
‧ The backup file can be played directly in your PC via the supplied licensed AP, or via other media players
(For example, Windows Media Player or RealPlayer) after the file is converted to "AVI" format
Remote Surveillance
‧ Support remote surveillance up to 5 users simultaneously with licensed software AP and IE browser
Intelligent Motion Trigger Recording
‧ R.E.T.R. (Remote Event Trigger Recording)
‧ With the advanced functions of motion detection, scheduled motion detection recording (4 different adjustable factors
for motion detection sensitivity) and quick search, customized security environments are achieved
‧
Alarm trigger recording will send alerts with images to designated e-mails and the FTP address
‧ Support pre-alarm recording (8MB)

Covert Recording

‧ A mask replaces the live image with a blank screen and the monitor shows nothing, but the recording is still on
A/V Support
‧
Support 4 audio-in, 2 audio-out to record sounds
‧ Support VGA output to monitor (optional)
General
‧ Support multi-language OSD
‧ Support IR remote control
‧ System auto recovery after power reconnected
‧ Support IR remote control, PTZ camera operations through RS-485, and PTZ Hot Point function
‧ Support daylight saving function
‧ Support manual / timer / motion / alarm / network recording
‧ Ensure the authentication of recorded images with Watermark function
‧ Support TCP/IP, PPPOE, DHCP and DDNS network connection
-1-
