Pro-Form PETL32570 User Manual

Hide thumbs

Table Of Contents

Quick Links

Model No. PETL32570

Serial No.

Write the serial number in the space

above for future reference.

Serial Number Decal

QUESTIONS?

As a manufacturer, we are

committed to providing complete

customer satisfaction. If you

have questions, or if there are

missing or damaged parts, we

will guarantee complete satis-

faction through our Customer

Service Department.

Please CALL:

0345-089009

Or WRITE:

ICON Fitness Lifestyle Ltd.

Greenwich House

223 North Street

Sheepscar

Leeds LS7 2AA

West Yorkshire

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

Class H C

Fitness Product

USER'S MANUAL

Table of Contents

Need help?

Do you have a question about the PETL32570 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Form PETL32570

Page 1 Model No. PETL32570 Serial No. Write the serial number in the space Class H C above for future reference. Fitness Product Serial Number Decal QUESTIONS? As a manufacturer, we are committed to providing complete customer satisfaction. If you have questions, or if there are...
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ............. 2 BEFORE YOU BEGIN .
Page 3 16. To reduce the possibility of the treadmill 21. Inspect and tighten all parts of the treadmill overheating, do not operate the treadmill every three months. continuously for longer than one hour. 22. Never insert any object into any opening. 17.
Page 4: Before You Begin
The model number of the treadmill is PETL32570. form of cardiovascular exercise in the convenience The serial number can be found on a decal attached and privacy of your home.
Page 5: Assembly
ASSEMBLY Before beginning assembly, carefully read the The following tools (not included) are required following information and instructions: for assembly: ¥ Assembly requires two people. ¥ Two (2) adjustable spanners ¥ Place all parts in a cleared area and remove the ¥...
Page 6 3. Carefully rotate the Console Base (45) to the posi- tion shown. Secure the Console Base with two Console Base Bolts (91), two Console Base Washers (90), and two Console Base Nuts (11) as shown. Refer to the inset drawing. Tighten all four Handrails Console Base Bolts (91) and Console Base Nuts (11) as tightly as possible.
Page 7: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPOR- TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. They will deteriorate the walking belt and cause excessive wear.
Page 8 DIAGRAM OF THE CONSOLE Monitor Displays On/Reset Button Speed Control Clip CAUTION: removed from the console, the walking belt Before operating the will stop. console, read the following precautions. ¥ Adjust the speed in small increments. ¥ Do not stand on the walking belt when turning on the power.
Page 9 Insert the key fully into the power switch. CALORIES/FAT CALO- RIES displayÑThis Inserting the key will display shows the not turn on the dis- approximate numbers plays. The displays will of calories and fat calo- turn on when the ries you have burned. ON/RESET button is (See FAT BURNING on pressed or when the...
Page 10: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. Caution: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1.
Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, slide open the storage latch. Pivot the treadmill until the frame guide and the foot rail are past the storage latch. Storage Opened Latch...
Page 12: Maintenance And Trouble-Shooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: THE POWER DOES NOT TURN ON SOLUTION: a.
Page 13 PROBLEM: THE WALKING BELT IS OFF-CENTRE OR SLIPS WHEN WALKED ON SOLUTION: a. If the walking belt has shifted to the left, first remove the key and UNPLUG THE POWER CORD. Using the allen wrench, turn the left rear roller adjust- ment bolt clockwise, and the right bolt counterclock- wise, 1/4 of a turn each.
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES the speed and incline of the treadmill until your heart rate is near one of the lower two numbers in your train- WARNING: Before beginning ing zone. this or any exercise program, consult your physician. This is especially important for Aerobic Exercise individuals over the age of 35 or individuals with pre-existing health problems.
Page 15 Cool-down Exercise Frequency Finish each workout with 5 to 10 minutes of stretching To maintain or improve your condition, complete three to cool down. This will increase the flexibility of your workouts each week, with at least one day of rest muscles and will help prevent post-exercise problems.
Page 16 PART LISTÑModel No. PETL32570 R0598A Key No. Qty. Description Key No. Qty. Description Hood Speed Control Knob Adhesive Clip Ground Screw Motor Belt Wire Harness Motor Pivot Nut Grommet Pulley/Flywheel/Fan Base Leg Motor/Pulley/Flywheel/Fan Belly Pan Fastener Motor Belly Pan Reed Switch...
Page 17 EXPLODED DRAWINGÑModel No. PETL32570 R0598A...
Page 18: Ordering Replacement Parts
¥ The NAME of the product (PROFORM ¨ 325E treadmill) ¥ The MODEL NUMBER of the product (PETL32570) ¥ The PART NUMBER of the part (see the EXPLODED DRAWING and PART LIST attached in the centre of this manual) ¥ The DESCRIPTION of the part (see the EXPLODED DRAWING and PART LIST attached in the centre of this manual).
