- Page 1 KG-Series American Weigh High Capacity Scales, Inc. Precision Balance INSTRUCTION MANUAL KG-10 KG-20 ©2010 American Weigh Scales, Inc. Doc. Rev. 2.1...
-
Page 2: Table Of Contents
KG-Series Balance Structure ........ -
Page 3: Kg-Series Balance Structure
KG-Series Manual 1.1. KG-Series Balance Structure Figure 1.3 Weighing Pan UNIT Button Leveling Foot Weight Display TARE Button Battery Compartment Bubble Level MODE Button ON/OFF Button CAL Button... -
Page 4: Technical Specifications
KG-Series Manual 1.2. Technical Specifications Model KG-10 KG-20 Max. Capacity 10,000g 20,000g Readability 0.1g 0.1g Repeatability ±1d Linearity ±2d Span Calibration Weight 5000g 10,000g Linear Calibration 5000g, 10000g 10,000g, 20,000g Weights Response Time 2~3 sec. Pan Size 12 x 9 inch Dimensions 12 x 12.5 x 7 inch... -
Page 5: Installation
KG-Series Manual 2. INSTALLATION 2.1. Part List Balance ............1 pc. -
Page 6: Operation
KG-Series Manual 3. OPERATION 3.1. Sample Weighing 1. Press TARE / ZERO to make the balance return to zero. 2. Load the sample onto the scale pan. 3. The weight is stable when g (depending on weighing unit is active) appears on the display. -
Page 7: Calibrating The Balance
KG-Series Manual 2. Press the UNIT key until the display shows “%” to indicate percent weighing mode. 3. The display will show “100.00%” with the reference sample on the scale. You may now remove the reference sample and add the unknown sample to determine its relative weight. Press UNIT to exit. -
Page 8: Appendix
KG-Series Manual 4. APPENDIX 4.1. RS232 Serial Data Communication This balance has a Bi-Directional RS232 port for communication with a PC. When connected to a computer, the weight value can be sent to the computer and commands can be sent to the balance... -
Page 9: Troubleshooting
KG-Series Manual 4.4. Care & Maintenance Please read all operating instructions carefully before use. Scales are precision instruments and should always be handled with proper care. To ensure years of reliable service, keep these simple tips in mind: • Do not exceed the scales maximum capacity. Overloading your scale can permanently damage it! • Avoid exposure to extreme heat or cold. Scales perform best at normal room temperature. If temperatures have changed dramatically, recalibration may be necessary.
