Remote Control Operation (See Figure 9)
The remote control can perform most of the manual operations. For best performance aim the front part of the control towards the
infrared detector shown in Figure 6. The functions of the control are listed below.
POWER. Press this button to turn power on. The LCD display will illuminate and show one of the modes previously selected.
Press again to turn power off.
TREBLE. Press this button if it is desired to adjust the TREBLE level. The LCD display will show TREBLE. To
increase/decrease treble volume press the plus (+) or minus (-) part of the VOL button. The level indicators shown on the LCD
display will increase in ascending order as treble volume is increased and will turn off in descending order as treble volume
is decreased.
BASS. Press this button if it is desired to adjust the BASS level. The LCD display will show BASS. To increase/decrease bass
volume press the plus (+) or minus (-) part of the VOL button. The level indicators shown on the LCD display will increase in
ascending order as bass volume is increased and will turn off in descending order as bass volume is decreased.
MUTE. This function is only available when using the remote control. Press this button to mute the sound. The LCD display
volume level indicators will turn off. The function indicator remains on. Press this button again to restore sound.
Press any other function and sound will be restored.
CENTER. This function is only operational in the Pro Logic or Dolby Digital mode. Press this button to adjust the volume
level of the center channel. The LCD display will show CENTER. Set the center level by using the plus (+) or minus (-) part
of the VOL button. The LCD display will increase in ascending order as volume is increased and will turn off in descending
order as volume is decreased.
SURR(SURROUND). This function is operational in the StereoX2, Quad, Pro Logic, and Dolby Digital mode. Press this
button to adjust the volume level of the surround channel. Set the surround level by using the plus (+) or minus (-) part of the
VOL button. The LCD volume level indicators will increase in ascending order as the volume is increased and will turn off in
descending order as the volume is decreased.
MODE. Repeatedly press this button to access all modes of operation: STEREO, STEREO X2, PRO LOGIC, DOLBY
DIGITAL and QUAD.

SPECIFICATIONS

System Response 27Hz - 20kHz
Total Audio Output 120 Watts(103 dB SPL @ Listening Position)
Input Impedance >10k Ohms
Analog Input Sensitivity 300 mV for full output
Digital Input S/PDIF*

SATELLITE SPEAKERS

Drivers Four 3" Full Range
Two 1" Tweeters
Power 60 Watts (15 watts per satellite)
Signal-to-Noise Ratio >70dB
SUBWOOFER
Driver One 8" dual voice coil
Power 60 Watts
Crossover Frequency 150Hz
Signal-to-Noise-Ratio >70dB

POWER REQUIREMENTS

USA/Canada 120v/60Hz/360W
Europe/United Kingdom and
various Asian Countries 230v/50Hz
UL/cUL/CE Approved
DIMENSIONS
Subwoofer 365mm Wide x 260mm Deep x 290mm High
Main Speaker 137mm Wide x 110mm Deep x 162mm High
Surrounds 110mm Wide x 104mm Deep x 117 mm High
*Sony/Philips Digital Interconnect Format
7
Figure 9
