- Page 1 ® EVO180 180mm ( 7”) TCT STEEL CIRCULAR SAW Instruction Manual Read instructions before operating this tool. www.evolutionsteel.com...
-
Page 2: Table Of Contents
EVO 180mm Steel Cutting Circular Saw TABLE OF CONTENTS EC - Declaration of Conformity Important Information Original Instructions 12 Month Limited Warranty Read instructions before operating this tool. General Safety Rules Safety Instructions for All Saws…... Symbols & Labels Additional Specific Safety Rules…. Specification Assembly Machine Overview... -
Page 3: Ec - Declaration Of Conformity
Name: Mr Matthew J Gavins is no warranty – written or verbal – for saw blades. Position: Managing Director In no event shall Evolution Power Tools be liable for Date: 1st June 2011 loss or damage resulting directly or indirectly from the use of our merchandise or from any other cause. -
Page 4: General Safety Rules
Never modify the plug in any way. Do not use any sale and none shall be binding on Evolution Power adapter plugs with earthed (grounded) power tools. Tools. Questions relating to this limited warranty Unmodified plugs and matching outlets will reduce should be directed to the company’s head office, or... -
Page 5: Safety Instructions For All Saws
EVO180 or long hair can be caught in moving parts. workpiece. g) If devices are provided for the connection of c) Adjust the cutting depth to the thickness of dust extraction and collection facilities, ensure the workpiece. Less than a full tooth of the blade these are connected and properly used. -
Page 6: Symbols & Labels
Do not use dull or damaged blades. and / or instruction labels are missing or damaged. Unsharpened or improperly set blades produce Contact Evolution Power Tools for replacement a narrow kerf causing excessive friction, blade labels. binding and kickback. -
Page 7: Additional Specific Safety Rules
EVO180 Only use genuine Evolution replacement parts. in the open position. Ensure that the guard operates Unauthorized parts may be dangerous! freely without jamming. m) Only use blades that comply with the To obtain an additional copy of your manual, please characteristics specified in this manual. -
Page 8: Assembly
ASSEMBLY ASSEMLY Your Evolution Power Tools saw is shipped complete. Remove all contents from the box and inspect to ensure no damage was incurred during shipping, and that the items listed below are included. ITEMS SUPPLIED Description Instruction Manual: Qty 1... -
Page 9: Machine Overview
EVO180 MACHINE OVERVIEW EVO 180MM STEEL CIRCULAR SAW 1. ON/OFF TRIGGER SWITCH 2. AUXILLARY FRONT HANDLE 3. DISCHARGE EXHAUST PORT 4. LOWER BLADE GUARD 5. FITTED BLADE IN SITU www.evolutionsteel.com... -
Page 10: Getting Started
FIG 1 Installing or Removing a Blade WARNING: Only use genuine Evolution blades which are designed for this machine. Ensure that the maximum speed of the blade is compatible with the machine. Only perform this operation with the machine disconnected from the power supply. - Page 11 EVO180 10. Replace the chip collector and securely tighten the two thumb screws. 11. Check that the arbor lock is fully released by manually rotating the blade. 12. Check the operation of the safety guard. Parallel Edge Guide A parallel guide (for help when rip cutting) can be...
- Page 12 ON/OFF Trigger Switch This machine is equipped with a safety start trigger switch. To start the machine: • Push in the safety lock button on the side of the handle with your thumb. •Depress the main trigger switch to start the motor.
-
Page 13: Maintenance
EVO180 Cutting Advice MAINTENANCE MAINTENANCE The operator should wear all relevant PPE (Personal Protection Equipment) necessary for the job at Note: Any maintenance must be carried out with the machine switched off and disconnected from hand. This could include safety glasses, dust the power supply. -
Page 14: Environmental Protection
ENVIRONMENTAL PROTECTION ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice www.evolutionsteel.com... - Page 15 EVO180 F11100 www.evolutionsteel.com...
