Intelliguard 750
O O w w n n e e r r ' ' s s G G u u i i d d e e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Intelliguard 750 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Directed Electronics Intelliguard 750

Summary of Contents for Directed Electronics Intelliguard 750

  • Page 1 Intelliguard 750 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...

  • Page 2: Limited Lifetime Consumer Warranty

    Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories,...
  • Page 3 ® ® ® Mode ™ , Soft Chirp ® , Stealth Coding ™ , Stinger ® , Valet ® , Vehicle Recovery System®, VRS ® , and Warn Away are all Trademarks or Registered Trademarks of Directed Electronics, Inc. ®...

  • Page 4: Table Of Contents

    contents what is included ... .2 anti-code grabbing (ACG) ..17 important information ..2 high frequency ....18 system maintenance .

  • Page 5: What Is Included

    what is included Intelliguard control module and harness Two five-button transmitters Presentation envelope and quick reference card Two window decals XHF antenna/receiver with harness Pre-wired blue status LED PlainView 2 Valet switch 518C neo-siren 506T audio sensor Digital dual-zone omnisensor important information Congratulations on the purchase of your state-of-the-art vehicle security system.

  • Page 6: System Maintenance

    Changes or modifications not expressly approved by the party responsi- ble for compliance could void the user's authority to operate this device. Directed Electronics, Inc. Tested to Comply with FCC Standards © 2 0 0 3 d i re c t e d e l e c t ro n i c s , i n c .

  • Page 7: Transmitter Configurations

    transmitter configurations Remote Start or Arm/Disarm and Accessory Output Panic Button Button Silent Arm/Disarm Trunk Release or or Accessory Optional Accessory Output Button Channel Button Shift Button n n o o t t e e : : This manual describes the features and accessories that are included with your system along with information about compatible Clifford accessories that are not included.

  • Page 8: Transmitter Functions

    transmitter functions This system uses computer-based code learning to learn the transmit- ter buttons. This makes it possible to assign any transmitter button to any system function. The transmitter initially comes programmed with standard configuration, but may also be customized using the CliffNet Wizard PC program.
  • Page 9 Button, then Button Accessory C output is controlled by these buttons. Button twice, then Button These buttons active remote valet. Button twice, then Button These buttons disable the sensors. Button twice, then Button These buttons enter safe start mode for manual transmission vehicles and activate Autostart mode.

  • Page 10: Using Your System

    using your system The buttons used in the instructions in this manual correspond to the standard transmitter configuration. If your transmitter has been custom configured, the icons on your transmitter buttons may not correspond to the indicated functions. arming You can activate, or arm, the system by pressing on your trans- mitter for one second.

  • Page 11: Disarming

    and programmed for passive locking) at 30 seconds, but the siren will not chirp. The early chirps provide you with a 25-second warning prior to arming. n n o o t t e e : : If any protected entry point (a door or a switch-protected trunk or hood) is open, the system will not passively arm.

  • Page 12: Disarming Without A Transmitter

    disarming without a transmitter This feature allows you to disarm the system without the transmitter should it be lost, damaged, or disabled. In order to disarm without a transmitter, you must have the vehicle’s ignition key, know where the PlainView 2 Valet switch is located, and have the PIN code. Be sure to check with the installer for the location of the PlainView 2 Valet switch.

  • Page 13: Transmitter Sensor Disable

    transmitter sensor disable To temporarily disable a sensor input, arm the system, press twice and then . The lights will flash four times and all warn away trigger zones one, two, three, and eight are bypassed. Press the buttons again; the lights flash four times and both warn away and full trigger zones one, two, three, and eight are bypassed until the system is disarmed.

  • Page 14: Auxiliary Channel Bypass

    auxiliary channel bypass Alarm sensor input zones one, two, three, and eight will be bypassed while a pulsed or timed auxiliary Output is active. panic mode with smart door locking If you are threatened in or near your vehicle, you can attract attention by triggering the system with your transmitter! Just press two seconds to enter Panic Mode.

  • Page 15: Transmitter Valet Mode

    b. To enter valet mode: Press and hold three seconds. The LED status indicator will light steadily if you are entering Valet Mode and will turn off if you are exiting Valet Mode. To exit Valet Mode: 1. Turn the ignition on. 2.

  • Page 16: Low Battery Warning

    The system will not auto arm. n n o o t t e e : : The system will revert to normal auto arming when the system sees the ignition on for at least three seconds. During auto arming bypass the system will not roll up the windows if SmartWindows is connected, and the accessory output will not auto- activate when using the remote to arm the system.

  • Page 17: False Alarm Control Technology (Fact Ii)

    false alarm control technology (FACT II) Your system offers FACT , a feature that prevents annoying repetitive trigger sequences due to a faulty sensor or environmental conditions such as thunder, jackhammers, airport noise, etc. Here’s how it works: The alarm triggers three times. If the same sensor is triggering the alarm and the first and the third triggers are within 60 minutes of each other, FACT will interpret this pattern of triggers as...

  • Page 18: Select Siren Sounds

    select siren sounds To customize siren sounds, please refer to the selectable siren sounds feature in the User Selectable Features grid. Once in programming mode, press on the transmitter to begin playback of the avail- able sounds. Press on the PlainView 2 Valet switch while playing the desired sound to add that sound;...

  • Page 19: Disarming Diagnostics

    tem will monitor that input normally. For example, if your vehicle has interior light exit delay, and you arm the system before the interior light goes out, you may hear Bypass Notification chirps. Once the light shuts off, however, the doors are monitored normally. disarming diagnostics Extra disarm chirps are the Tamper Alert.

  • Page 20: Table Of Zones

    table of zones The zone number is the number of LED flashes used by the system to identify a specific input. The standard input assignments are listed below, along with spaces to write in any optional sensors or switches you have had installed. If the Warning Zone response is triggered, the LED will not report it.

  • Page 21: High Frequency

    high frequency Your system transmits and receives at 433 MHz. This provides a cleaner spectrum with less interference and a more stable signal. smart power up II This security system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory.

  • Page 22: Programming Options

    Power Saver in Valet Mode: When the system enters Valet Mode the LED illuminates steadily. If the vehicle is not used (ignition is not turned on) for a period of one hour while the system is in Valet Mode, the LED will shut off. If the system remains in Valet Mode, the LED will come back on the next time the ignition is turned on and then back off.
  • Page 23 Panic mode enabled/disabled: Some states have laws against siren capability while driving. Full trigger response 30, 60, or 90 seconds: This determines how long the full triggered sequence lasts. Some states have laws regulating how long a security system can sound before it is considered a nuisance.

  • Page 24: Cliffnet Wizard Installation Software Programming

    cliffnet wizard installation software programming Cliffnet Wizard provides access to all available system features and some that are not available when manually programming with the Valet switch. Cliffnet Wizard is compatible with Microsoft Windows 95/98/2000/ME/XP/NT so most programming operations can be accomplished by pointing and clicking with a mouse.
  • Page 25 Feature select - Press the same number of times as the desired feature. The siren will chirp with each press. The fea- ture can now be changed using the remote control. Feature change - Press on the transmitter. If the sys- tem chirps once, the feature has just turned off;...

  • Page 26: User Selectable Features

    user selectable features First Press Then Press Add new remote Set PIN code New remote learn (default = 2) (autolearn) arm/disarm only Auto (passive) Select siren New remote learn sounds arm on/off accessory A channel Chirps New remote learn FACT II on/off on/off/quiet accessory B channel Auto lock...

  • Page 27: User Selectable Features Descriptions - Column One

    user selectable features descriptions - column one add new remote (auto learn) Auto-learn new five-button Radar2 remote controls to the system in the standard button configuration. Once you have entered the feature, press on the transmitter until you hear a confirmation chirp. Press again until you hear two chirps indicating the new remote is learned.
  • Page 28 auto unlock - ignition/off Ignition: The doors will automatically unlock as soon as the ignition is turned off. Off: The doors will not automatically unlock when the igni- tion is turned off auto (passive) arm and lock - on/off On: The doors will lock when the system passively arms. This feature only applies when passive arming is programmed on.

  • Page 29: User Selectable Features Descriptions - Column Two

    user selectable features descriptions - column two set pin code This feature allows the setting of the user's personal PIN code. For more information, please refer to the PIN Programming section of this guide. select siren sounds The individual sounds the siren produces during an full trigger alarm can be customized for owner recognition of an alarm trigger.
  • Page 30 reset to default settings All system settings (except PIN and remote programming) in the User Programming grid will be reset to their default fac- tory setting as indicated in bold lettering. Press the arm/disarm button of the TX; the siren will chirp twice as confirmation.

  • Page 31: User Selectable Features Descriptions - Column Three

    user selectable features descriptions - column three The features in this column pertain to programming individual trans- mitter channels in custom configurations. Following is an explanation of the features. arm/disarm only The remote control channel programmed into this feature will arm/dis- arm the system only.
  • Page 32 remote start This feature is only available with IntelliStart connected The transmitter channel programmed into this feature will activate or shut down the Intellistart remote start system. window control This feature is only available with SmartWindows connected The transmitter channel programmed into this feature will activate the vent or roll down feature of the SmartWindows system.

  • Page 33: Pin Programming

    pin programming A PIN code can have one to four digits; each digit can be from 0-9. n n o o t t e e : : A PIN code cannot begin with a zero. Programming Procedure Enter the feature location in the installer programming grid. Immediately press and release of the PlainView 2 Valet switch.

  • Page 34: Auto-Immobilization Feature

    PIN Code Confirmation Procedure Begin this procedure within 15 seconds of finishing the programming sequence or the new code will not be set. Turn on the ignition. Enter the new PIN code. Press and hold for three seconds. LED turns on: New PIN code is learned and program- ming is complete.

  • Page 35: One-Time Valet Feature

    Disarming auto-immobilization To disarm auto-immobilization when active, follow any of the sequences listed below. Turn ignition on and press the arm/disarm button. Arm the alarm and then disarm the alarm. Turn the ignition on and enter the system valet/PIN code. one-time valet feature This feature allows the system to be put in valet mode only until the next time the ignition is turned on.

  • Page 36: Blackjax Feature

    blackjax feature Clifford's exclusive BlackJax feature provides a safe and effective means of recovering your vehicle after a carjacking by monitoring the door input, brakes, and engine speed. Simply get out of the vehicle and let the thief drive away. After the vehicle is at a safe distance BlackJax will activate the siren and brake lights to draw attention to the vehicle.

  • Page 37: Blackjax Deactivation Sequence34

    System then begins monitoring the engine speed. System sees the engine speed at two times idle. BlackJax begins 20 second countdown. After a 20 second countdown: 5 siren chirps as reminder to enter PIN code. Brake light output pulses to flash brake lights. You then have 20 more seconds to enter PIN to turn off Blackjax.

  • Page 38: Bypass Blackjax Temporarily

    bypass blackjax temporarily This feature allows you to easily bypass BlackJax activation when another person drives your vehicle that should not know your PIN code. (IE: valet parking, auto service dept.) Bypass BlackJax temporarily Turn ignition on. Enter PIN code. Do not enter valet or programming mode. Within 10 seconds press Siren chirps 1 time as confirmation of BlackJax bypassed.

  • Page 39: Blackjax Off Warning Indicator

    blackjax off warning indicator Each time the ignition is turned off when BlackJax is bypassed the LED will blink 10 times as warning that the BlackJax has been temporarily bypassed. audio sensor The 506T Audio Sensor is a low-current device that provides an added level of protection to an existing security system by detecting sounds that have the acoustic signature of breaking glass or metal-to-glass impacts.
  • Page 40 Sensor test and adjustment mode is entered. To test Primary (full trigger) zone. Press of the remote control. Siren will chirp 2 times. Hit vehicle. Siren chirps 1 time if hit hard enough to activate sen- sor. Adjust Primary zone Press of the remote control.

  • Page 41: Glossary Of Terms

    Sensor adjustment mode is entered. Hit vehicle at the desired level of impact. Sensor adjusts itself to the force of Hit. Siren chirps 1 time as confirmation of adjustment. Press to lock adjustment. Press to re-enter Primary zone adjustment Siren chirps 2 times. Primary zone can now be re-adjusted as described in step 4.
  • Page 42 vehicle’s engine from operating whenever the system is armed. The vehicle is never prevented from running when the system is disarmed, in Valet mode, or loss of power. Omnisensor: A dual-zone learning impact sensor. PlainView 2 Valet Switch : A small two-button switch mounted some- where inside the vehicle.

  • Page 43: Security & Convenience Expansions

    security & convenience expansions Here we have listed only some of the many expansion options avail- able. Please contact your dealer for a complete list of all the options available to you. Backup Battery: The 520T keeps the system armed, triggers the alarm and keeps the immobilization circuits active if main battery power is discon- nected.

  • Page 44: Health Check

    Directed Electronics recommends you return to your installing Clifford dealer to have your system checked for correct operation. The first check is due one year after the installation date and at yearly intervals thereafter. n n o o t t e e : : There may be a small charge incurred for this service.
  • Page 46 © 2 0 0 3 d i re c t e d e l e c t ro n i c s , i n c .
  • Page 47 ISO ® 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world. E&OE, specification is subject to change without notice. Some vehicles require optional parts/wiring and a few are incompatible with some features.
