PURSUIT 2470 CENTER CONSOLE Owner's Manual

Fishing boats
Hide thumbs Also See for 2470 CENTER CONSOLE:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
2470 CENTER CONSOLE
OWNER'S MANUAL
FISHING BOATS
3901 St. Lucie Blvd.
Ft. Pierce, Florida 34946
2470 CENTER CONSOLE
Print Date 11/98

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2470 CENTER CONSOLE and is the answer not in the manual?

Questions and answers

Related Manuals for PURSUIT 2470 CENTER CONSOLE

Summary of Contents for PURSUIT 2470 CENTER CONSOLE

  • Page 1 2470 CENTER CONSOLE OWNER’S MANUAL FISHING BOATS 3901 St. Lucie Blvd. Ft. Pierce, Florida 34946 2470 CENTER CONSOLE Print Date 11/98...
  • Page 2 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...
  • Page 3 Dear Pursuit 2470 Center Console Owner: All of us at Pursuit are pleased that you have selected one of our products as your boat. As I’m sure you’ve discovered during the selection and decision process, your Pursuit has been designed, engineered and built with care and precision.
  • Page 4 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 5: Safety Information

    IMPORTANT NOTE: Your boat uses internal combustion engines and flammable fuel. Every precaution has been taken by Pursuit Fishing Boats to reduce the risks associated with possible injury and damage from fire or explosion, but your own precaution and good maintenance procedures are neces- sary in order to enjoy safe operation of your boat.
  • Page 6 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 7: Boat Information

    SERIAL #: GVRW: DEALER PURSUIT NAME: PHONE: DEALER/PHONE: REPRESENTATIVE: SALESMAN: ADDRESS: SERVICE MANAGER: ADDRESS: Pursuit Fishing Boats reserves the right to make changes and improvements in equipment, design and vendored equipment items, at any time without notification. 2470 CENTER CONSOLE...
  • Page 8 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 9: Important Information

    IMPORTANT INFORMATION Warranty and Warranty Registration Cards The Pursuit Limited Warranty Statement is included with your boat. It has been written to be clearly stated and easily understood. If you have any questions after reading the warranty, please contact the Pursuit Customer Relations Department.
  • Page 10 Limited Warranty, you should contact your Pursuit dealer to arrange for the necessary repair. If you are not near your dealer or another authorized Pursuit dealer or the dealer fails to remedy the cause of the problem, then contact the Pursuit Customer Relations Department within 15 days.
  • Page 11 Power Squadrons, United States Coast Guard Auxiliary, State Boating Authorities and the American Red Cross offer excellent boating educational programs. These courses are worthwhile even for experienced boaters to sharpen your skills or bring you up to date on current rules and 2470 CENTER CONSOLE...
  • Page 12 Coast Guard jurisdiction. These agencies may also require additional equipment that is not required by the Coast Guard. Your dealer or local boating authority can provide you with additional information for the equipment requirements for your boating area. 2470 CENTER CONSOLE...

  • Page 13: Table Of Contents

    Trim Tabs ................2-4 Control Systems Maintenance ..........2-5 Fuel System Chapter 3: Chapter 3: Chapter 3: Chapter 3: Chapter 3: General ..................3-1 Outboard Fuel System ............. 3-3 Fueling Instructions..............3-4 Fuel System Maintenance ............3-5 2470 CENTER CONSOLE viii...
  • Page 14 Chapter 7: Cockpit Drainage ..............7-1 Leaning Post and T-Top Drainage ..........7-1 Bilge Drainage ................. 7-2 Fishbox and Storage Compartment Drainage ......7-2 Sink and Livewell Drains ............7-3 Console Cooler Drain .............. 7-3 Maintenance ................7-3 2470 CENTER CONSOLE...
  • Page 15 Fishing ..................9-9 Trailering Your Boat ..............9-9 Chapter 10: Exterior Equipment Chapter 10: Chapter 10: Chapter 10: Chapter 10: 10.1 Deck ..................10-1 10.2 Hull ..................10-3 10.3 Cockpit Equipment ..............10-3 10.4 Center Console ................ 10-4 2470 CENTER CONSOLE...
  • Page 16 Hydraulic Steering System ..............14-3 Twin Engine Fuel System ..............14-4 Single Engine Fuel System ..............14-5 Freshwater System ................14-6 Raw Water System - Macerator ............14-7 Raw Water System - Without Macerator ..........14-8 Drainage System ................... 14-9 2470 CENTER CONSOLE...
  • Page 17 TABLE OF CONTENTS Appendix A: Glossary of Terms ............A-1 Appendix B: Maintenance Log .............. B-1 Appendix C: Boating Accident Report ........... C-1 2470 CENTER CONSOLE...
  • Page 18 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 19: Chapter 1: Propulsion System

    PROPULSION SYSTEM 1.1 General The Pursuit 2470 Center Console is designed to be powered with either a single outboard engine or twin outboard engines. Outboard motors use an oil injection system. Oil is automatically injected in the engine(s) and mixed at the proper ratio from oil tank(s) located in the stern of the boat.

  • Page 20: Drive Systems

    DO NOT PAINT THE OUTBOARD MOTORS WITH ANTIFOULING PAINTS DESIGNED FOR BOAT HULLS. MANY OF THESE PAINTS CAN CAUSE SEVERE DAMAGE TO THE EN- GINES. CONTACT YOUR PURSUIT DEALER OR ENGINE MANUFACTURER FOR INFOR- MATION ON THE PROPER PAINTING PROCEDURES.

  • Page 21: Engine Cooling System

    The propellers convert the engine’s power into thrust. They come in a variety of styles, diameters and pitches. The one that will best suit the needs of your Pursuit will depend somewhat on your application and expected average load. Propeller sizes are identified by two numbers stamped on the prop in sequence.

  • Page 22: Engine Instrumentation

    The instrumen- tation is unique to the type of outboard motors installed on your Pursuit. Some or all of the following gauges may be present.
  • Page 23 If you have a fuel management system installed on your boat, please refer to the engine or fuel management manual for information on that system. 2470 CENTER CONSOLE...
  • Page 24 The ignition switches should be sprayed periodically with a contact cleaner/lubricant. The ignition switches and all instruments, controls, etc. should be protected from the weather when not in use. Excessive exposure can lead to gauge and ignition switch difficulties. 2470 CENTER CONSOLE...

  • Page 25: Chapter 2: Helm Control Systems

    The helm on your Pursuit is designed for a binnacle style control with a single lever for each engine that operates as a gear shift and a throttle. General operation will include a position for neutral (straight up and down), a forward position (the 1st detente forward of neutral), and a reverse position (the 1st detente aft of neutral).

  • Page 26: Engine Stop Switch

    Control or cable adjustments may be required to correct this condition should it persist. See your Pursuit dealer for necessary control and cable adjustments.

  • Page 27: Steering System

    A slight clicking sound may be heard as the wheel is turned. This sound is the opening and closing of valves in the helm unit and is normal. Refer to the manufacturer owner’s manual for specific information on the steering system. 2470 CENTER CONSOLE...

  • Page 28: Trim Tabs

    2.7 Trim Tabs Pursuit uses a dual toggle switch to control the trim tabs. The switch is labeled and controls bow up and down movements. It also controls starboard and port up and down movements. Bow up and bow down will control the hull planing attitude while port and starboard up and down provides control for the hull listing.

  • Page 29: Control Systems Maintenance

    The trim tab fluid should be checked often. Keep the fluid level between the marks on the trim tab pump reservoir. If your Pursuit will be left in saltwater for extended periods, it may be necessary to install zinc anodes on the trim tab planes to prevent galvanic corrosion. Refer to the trim tab owner’s manual for additional maintenance information and fluid specifications.
  • Page 30 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 31: Chapter 3: Fuel System

    Fuel System 3.1 General The gasoline fuel system used in Pursuit boats is designed to meet or exceed the requirements of the U.S. Coast Guard, the Boating Industry Association, and The American Boat and Yacht Council in effect at the time of manufacture.
  • Page 32 After fueling, replace the fill cap and wash the areas around the fuel fill deck plate and below the fuel vent. Residual fuel left on the deck and hull sides can be dangerous and will yellow the fiberglass or damage the striping. 2470 CENTER CONSOLE...

  • Page 33: Outboard Fuel System

    3.2 Outboard Fuel System The fuel system on the Pursuit 2470 Center Console has one fuel tank. The fuel tank is mounted in the center of the bilge and has one or two withdrawal lines equipped with anti-siphon valves where the fuel lines attach to the fuel tank.

  • Page 34: Fueling Instructions

    LINE FOR GASOLINE ENGINES. DO NOT USE A FUEL THAT CONTAINS HARSH ADDI- TIVES OR IS AN ALCOHOL BLEND. ANY DAMAGE DONE TO THE FUEL SYSTEM THAT IS THE RESULT OF USE OF AN ALCOHOL BLEND, IS NOT COVERED BY THE PURSUIT WARRANTY. REFER TO THE ENGINE MANUFACTURER OWNER’S MANUAL REGARD- ING FUEL REQUIREMENTS FOR YOUR ENGINE(S).

  • Page 35: Fuel System Maintenance

    The covers help prevent water and other foreign matter from contaminating the fuel and fuel system. If a vent cover is damaged or lost it should be replaced as soon as possible. 2470 CENTER CONSOLE...
  • Page 36 DO NOT DRAIN ANY FUEL INTO THE BILGE. THIS COULD LEAD TO A FIRE OR EX- PLOSION. AFTER THE FILTER ELEMENT HAS BEEN CHANGED, PRIME THE FUEL SYSTEM AND CHECK ALL FITTINGS FOR LEAKS BEFORE AND AFTER STARTING THE ENGINE. 2470 CENTER CONSOLE...

  • Page 37: General

    Chapter 4: ELECTRICAL SYSTEM 4.1 General Your Pursuit is equipped with a 12-volt D.C. electrical system that draws current from on-board batteries. The 12-volt batteries in your boat are usually the lead-acid type. They will require maintenance similar to those found in automobiles. The batteries are located in the stern bilge. The starboard battery is located near the battery switches and the port battery is below the removable stern tackle locker.
  • Page 38 12-volt accessories should be on either the battery # 1 or the battery # 2 position. This will keep one battery in reserve for starting the engines. Both battery switches should be turned to the “OFF” position when leaving the boat unattended. 2470 CENTER CONSOLE...
  • Page 39 The switch is a three-position switch. The middle position is “OFF." Moving the switch in one direction will activate the navigation lights. Moving the switch in the opposite direction activates the anchor light. Courtesy Lights Activates the lights that illuminate the cockpit area. Panel Lights Activates the engine gauge and compass lights. 2470 CENTER CONSOLE...
  • Page 40 Additional switch panels may be located in various locations in the cockpit and helm area of the boat. Most of these panels are equipped with one switch and one circuit breaker. The following is a description of additional panels that may be on your Pursuit and the accessories they control: Baitwell Switch This switch activates the baitwell circulating pump that supplies water to the baitwell.

  • Page 41: Electrical System Maintenance

    NEVER USE AN OPEN FLAME IN THE BATTERY STORAGE AREA. AVOID STRIKING SPARKS NEAR THE BATTERY. A BATTERY CAN EXPLODE IF A FLAME OR SPARK IG- NITES THE HYDROGEN GAS THE BATTERY EMITS WHILE BEING CHARGED. 2470 CENTER CONSOLE...
  • Page 42 CLEANED AS REQUIRED. DO NOT ALLOW CORROSION TO BUILD ON CONNECTIONS. THE ELECTRICAL SYSTEM ALWAYS SHOULD BE DISCONNECTED FROM THE POWER SOURCE BEFORE INSPECTING OR SERVICING THE SYSTEM. NEVER SERVICE ANY COM- PONENT OF AN ELECTRICAL SYSTEM WHILE IT IS ENERGIZED. 2470 CENTER CONSOLE...

  • Page 43: Chapter 5: Chapter 5: Freshwater System

    ATTEMPT TO PUMP IT OUT YOURSELF. WATER AND WASTE PUMPS ARE NOT DE- SIGNED TO PUMP FUEL AND A FIRE OR EXPLOSION COULD RESULT. CONTACT YOUR DEALER OR THE PURSUIT CUSTOMER RELATIONS DEPARTMENT FOR ASSISTANCE IN HAVING THE FUEL PROFESSIONALLY REMOVED AND COMPONENTS OF THE FRESH- WATER SYSTEM REPLACED AS NECESSARY.

  • Page 44: Freshwater System Operation

    The batteries must be properly maintained and charged. Operating the pressure pump from a battery with a low charge could lead to pump failure. Add a commercially available potable water conditioner to the water tank(s) to keep them fresh. 2470 CENTER CONSOLE...
  • Page 45 THE BATTERIES MUST BE PROPERLY CHARGED. OPERATING THE FRESHWATER PUMP FROM A BATTERY WITH A LOW CHARGE MAY LEAD TO A PUMP FAILURE. 2470 CENTER CONSOLE...
  • Page 46 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 47: Chapter 6: Raw Water System

    Note: It may be necessary to reprime the raw water system if the system is not used for an extended period and at the time of launching. 2470 CENTER CONSOLE...

  • Page 48: High Pressure Washdown

    Washdown Hose Connector ALWAYS TURN THE RAW WATER PUMP SWITCH TO THE “OFF” POSITION WHEN LEAV- ING THE BOAT UNATTENDED. DO NOT RUN THE HIGH PRESSURE PUMP DRY FOR EXTENDED PERIODS AS DAMAGE TO THE PUMP WILL RESULT. 2470 CENTER CONSOLE...

  • Page 49: Livewell

    This should be checked frequently and cleaned as necessary. Note: Do not use the livewell as a dry storage area when it is not in use. Sea water could accidently be delivered to the livewell from the thru hull and damage equipment stored there. 2470 CENTER CONSOLE...

  • Page 50: Raw Water System Maintenance

    THE BATTERIES MUST BE PROPERLY CHARGED. OPERATING ANY PUMPS FROM A BATTERY WITH A LOW CHARGE MAY LEAD TO A PUMP FAILURE. THE RAW WATER SYSTEM MUST BE PROPERLY WINTERIZED PRIOR TO WINTER LAY- UP. SEE SECTION ON WINTERIZING. 2470 CENTER CONSOLE...

  • Page 51: Chapter 7: Drainage Systems

    Drainage System 7.1 Cockpit Drainage Your Pursuit has two scupper drains located on each side of the hull, near the waterline, to provide drainage for the cockpit. Water is channeled away from all opening hatches by a gutter or drain rail system.

  • Page 52: Bilge Drainage

    The fishbox and storage compartment located in the bow are drained by gravity. The fishbox drains overboard out of a thru hull fitting located in the hull side above the waterline and the bow storage box drains into the bilge. 2470 CENTER CONSOLE...

  • Page 53: Sink And Livewell Drains

    ALL DRAINS AND PUMPS MUST BE PROPERLY WINTERIZED BEFORE WINTER LAY-UP. NEVER USE HARSH CHEMICAL DRAIN CLEANERS IN MARINE DRAIN SYSTEMS. PER- MANENT DAMAGE TO THE HOSES AND FITTINGS MAY RESULT. 2470 CENTER CONSOLE...
  • Page 54 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 55: Chapter 8: Safety Equipment

    Immediately throttle the engine back to idle. • Shift the transmission to neutral. • Monitor the engine gauges to determine the cause of the problem. • If necessary, shut off the engine and investigate until the cause of the problem is found. 2470 CENTER CONSOLE...

  • Page 56: Neutral Safety Switch

    8.4 Engine Stop Switch Your Pursuit is equipped with a engine stop switch and lanyard. When the lanyard is pulled it will engage the switch and shut off the engine. We strongly recommend that the lanyard be attached to the driver whenever the engine is running.
  • Page 57 PFDs should be worn at all times when the vessel is underway. Throwable devices must be immediately available for use. All Pursuit boats must be equipped with at least one Type I, II or III PFD for each person on board, plus one throwable device (Type IV). Some states have special PFD requirements for children.
  • Page 58 50-70 times per minute is considered a distress signal. Fire Extinguishers At least one fire extinguisher is required on all Pursuit boats. Boats 26' and larger may require two or three fire extinguishers. Coast Guard approved fire extinguishers are hand-portable, either B-I or B-II classification and have a specific marine type mounting bracket.

  • Page 59: Maximum Capacity Rating

    (fog, rain, haze, etc.) Navigation lights are intended to keep other vessels informed of your presence and course. Your Pursuit is equipped with the navigation lights required by the U.S. Coast Guard at the time of manufacture. It is up to you to make sure they are operational and turned on when required.
  • Page 60 Fenders First Aid Kit Flashlight Mirror Searchlight Sunburn Lotion Tool Kit Ring Buoy Whistle or Horn Anchor Chart and Compass Boat Hook Spare Propeller Mooring Lines Food & Water Binoculars Sunglasses Marine Hardware Extra Clothing Spare Parts 2470 CENTER CONSOLE...

  • Page 61: Chapter 9: Operation

    OPERATION 9.1 General Before you start the engines on your Pursuit, you should have become familiar with the various component systems and their operation, and have performed a “Pre-Cruise System Check.” A thorough understanding of the component systems and their operation is essential to the proper operation of the boat.
  • Page 62 You should be familiar with these and any other markers used in your boating area. STORMS AND WAVE ACTION CAN CAUSE BUOYS TO MOVE. YOU SHOULD NOT RELY ON BUOYS ALONE TO DETERMINE YOUR POSITION. 2470 CENTER CONSOLE...

  • Page 63: Pre-Cruise System Check

    • Check the bilge water level. Look for other signs of potential problems. Monitor for the scent of fuel fumes. • Test the automatic and manual bilge pump switches to make sure the system is working properly. 2470 CENTER CONSOLE...
  • Page 64 Be sure the shift control is in the neutral position. • Be sure the emergency stop lanyard is attached to the operator and the stop switch. VAPORIZING LIQUID EXTINGUISHERS GIVE OFF TOXIC FUMES; USE ONLY COAST GUARD APPROVED FIRE EXTINGUISHERS. 2470 CENTER CONSOLE...

  • Page 65: Operating Your Boat

    Alcohol reduces night vision, and the ability to distinguish red from green. YOU SHOULD NEVER OPERATE YOUR BOAT WHILE UNDER THE INFLUENCE OF AL- COHOL AND DRUGS. • Avoid sea conditions that are beyond the skill and experience of you and your crew. 2470 CENTER CONSOLE...
  • Page 66 Note: If the engines have been run at high speed for a long period of time, allow the engines to cool down by running the engines in the idle position for 3 to 5 minutes. • Turn the ignition keys to the “Off” position. • Raise the trim tabs to the full “UP” position. 2470 CENTER CONSOLE...

  • Page 67: Grounding And Towing

    U.S. Coast Guard or a commercial towing company, to safely accomplish the towing task. THE MOORING CLEATS ON PURSUIT BOATS ARE NOT DESIGNED OR INTENDED TO BE USED FOR TOWING PURPOSES. THESE CLEATS ARE SPECIFICALLY DESIGNED AS MOORING CLEATS FOR SECURING THE BOAT TO A DOCK, PIER, ETC.

  • Page 68: Water Skiing

    The skier should also be kept on the helm side of the boat so the operator can keep the skier in sight at all times. 2470 CENTER CONSOLE...

  • Page 69: Fishing

    Using a trailer with a capacity too low will be unsafe on the road and cause abnormal wear. A trailer with a capacity too high, can damage the boat. Contact your dealer to evaluate your towing vehicle and hitch, and to make sure you have the correct trailer for your boat. 2470 CENTER CONSOLE...
  • Page 70 Important Note: Your Pursuit is a heavy boat and care must be taken when selecting the trailer. We recommend that you use a bunk style trailer that incorporates a combination of heavy duty rollers, to support the keel and long bunks running under and parallel to the stringers to support the hull.
  • Page 71 Too little weight on the hitch will cause the rig to fishtail and will make controlling the tow vehicle difficult. Contact your Pursuit dealer or the trailer manufacturer for the correct weight on the hitch for your trailer.
  • Page 72 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 73: Deck

    All fittings must be periodically inspected for loose fit, wear and damage. Any problems should be corrected immediately. PURSUIT BOATS ARE NOT EQUIPPED WITH HARDWARE DESIGNED FOR TOWING PUR- POSES. THE MOORING CLEATS ARE NOT TO BE USED FOR TOWING ANOTHER VES- SEL OR HAVING THIS BOAT TOWED.
  • Page 74 ROPE LOCKER. A LOOSE ANCHOR IN THE ANCHOR LOCKER WILL BOUNCE AND CAN DAMAGE THE BOAT. DAMAGE RESULTING FROM THE ANCHOR BOUNCING IN THE ANCHOR LOCKER IS NOT COVERED BY THE PURSUIT WARRANTY. Windlass (Optional) The optional windlass is mounted to the deck near the rear of the pulpit above the rope locker. The anchor is stored on the pulpit and is raised and lowered by the windlass.

  • Page 75: Hull

    10.2 Hull Swim Platform Your Pursuit is equipped with an integral swim platform and engine mounting system located in the stern of the boat. There are two inspection deck plates in the transom engine well to provide access to the stern bilge and engine mounting bolts. Always make sure these plates are secure before operating your boat.

  • Page 76: Center Console

    The front of the console can then be lifted to expose the underside of the helm. A strap holds the helm in the open position and prevents it from opening too far. Always make sure the helm station clamps are properly secured when the helm is closed. 2470 CENTER CONSOLE 10-4...
  • Page 77 . If you have any questions about installing a T-top on your boat, please contact your dealer or the Pursuit Customer Relations Department. ALWAYS MAKE SURE THE HELM STATION CLAMPS ARE PROPERLY SECURED BEFORE OPERATING OR TRAILERING YOUR BOAT.
  • Page 78 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 79: Portable Head

    KNOW THE LAWS FOR THE AREAS IN WHICH YOU BOAT BEFORE MODIFYING OR RE- MOVING THE PUMP OUT SYSTEM. THE PORTABLE HEAD MUST BE PROPERLY WINTERIZED BEFORE WINTER LAY- UP OR FOR COLD WEATHER USE. PLEASE REFER TO THE MANUFACTURER OWNER’S MANUAL FOR COLD WEATHER AND WINTERIZING INSTRUCTIONS. 2470 CENTER CONSOLE 11-1...

  • Page 80: Marine Head System

    When the macerator discharge pump is installed, the Y-valve will be used to select either the macerator discharge pump or the waste deck fitting to evacuate the holding tank. 2470 CENTER CONSOLE 11-2...
  • Page 81 See the head manufacturer owner’s manual for additional operating and maintenance information. Periodically spray the macerator pump with a metal protector. THE HEAD SYSTEM MUST BE PROPERLY WINTERIZED BEFORE WINTER LAY-UP. SEE SECTION ON WINTERIZING. 2470 CENTER CONSOLE 11-3...
  • Page 82 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 83: Exterior Hull And Deck

    Zincs should be checked monthly and changed when they are 75% of their original size. When replacing the anodes, make sure the contact surfaces are clean, shiny metal and free of paint and corrosion. Never paint over the anode. 2470 CENTER CONSOLE 12-1...
  • Page 84 UNDER NO CIRCUMSTANCES SHOULD ANY ABRASIVE MATERIALS SUCH AS SANDPAPER, BRONZE WOOL, OR STEEL WOOL BE USED ON STAINLESS STEEL. DAMAGE TO THE HARDWARE WILL RESULT. 2470 CENTER CONSOLE 12-2...
  • Page 85 The anodized aluminum used on your Pursuit was coated with a metal protector called Aluma Guard at the factory. Aluma Guard is a nonabrasive marine metal protector that protects anodized aluminum, stainless steel, brass, and chrome.

  • Page 86: Upholstery, Canvas And Enclosures

    • Dry soil, dust and dirt - Remove with a soft cloth. • Dried on dirt - Wash with a soft cloth dampened with water. 2470 CENTER CONSOLE 12-4...
  • Page 87 The T-top enclosure must be removed when transporting the boat. Canvas enclosures are not designed to withstand the extreme wind pressure encountered while trailering and will be damaged. Always remove and properly store the enclosure before trailering or having your boat transported by truck. 2470 CENTER CONSOLE 12-5...

  • Page 88: Bilge

    If you have any questions about the clear curtains used on your boat, please contact the Pursuit Customer Relations Department. The T-top enclosure must be removed when trailering. Canvas enclosures are not designed to withstand the extreme wind pressure encountered while trailering and will be damaged.

  • Page 89: Lay-Up And Storage

    Your dealer or the engine manufacturer can provide additional information on fuel degradation and fuel stabilizers recommended for your engine. For more recommendations for your specific area, check with your local Pursuit dealer. • Drain water from the freshwater system.
  • Page 90 • Make sure the cradle is well supported and placed on a level surface with the bow high enough to provide proper drainage of the bilge. • Make sure the engines are in the down position. 2470 CENTER CONSOLE 13-2...
  • Page 91 SO THEY ARE NOT PUTTING PRESSURE ON THE LIFTING STRAKES AND ARE PROVID- ING ENOUGH SUPPORT FOR THE HULL. HULL DAMAGE RESULTING FROM IMPROPER CRADLE OR TRAILER SUPPORT IS NOT COVERED BY THE PURSUIT WARRANTY. Preparing The Boat For Storage •...

  • Page 92: Winterizing

    After the antifreeze has been added to the holding tank, open the overboard discharge valve and activate the macerator pump until the antifreeze solution is visible at the discharge thru hull. Note: Make sure you follow the marine toilet manufacturer's winterizing instructions exactly. 2470 CENTER CONSOLE 13-4...
  • Page 93 Proper storage is very important to prevent serious damage to the boat. If the boat is to be stored indoors, make sure the building has enough ventilation. It is very important that there is enough ventilation both inside the boat and around the boat. 2470 CENTER CONSOLE 13-5...

  • Page 94: Recommissioning

    Pump the antifreeze from the fresh and raw water systems and flush several times with freshwater. • Check and lubricate the steering system. • Clean and wash the boat. • Install all upholstery, cushions and canvas. 2470 CENTER CONSOLE 13-6...
  • Page 95 This insures that the cooling pump is operating. • Carefully monitor the gauges and check for leakage and abnormal noises. • Operate the boat at slow speeds until the engine temperature stabilizes and all systems are operating normally. 2470 CENTER CONSOLE 13-7...
  • Page 96 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...
  • Page 97 Chapter 14: Chapter 14: Chapter 14: Chapter 14: Chapter 14: SCHEMATICS 2470 CENTER CONSOLE 14-1...

  • Page 98: Single Engine 12-Volt Wiring Schematic

    Single Engine 12-Volt Wiring Schematic...

  • Page 99: Hydraulic Steering System

    Helm Hydraulic Lines Steering Cylinder Hydraulic Steering System...

  • Page 100: Twin Engine Fuel System

    Fuel Filters Oil Tanks Fuel Fill Fuel Vent Fuel Tank Anti-siphon Valve Primer Bulbs Oil Fills Twin Engine Fuel System...

  • Page 101: Single Engine Fuel System

    Fuel Filter Oil Tank Fuel Fill Fuel Vent Fuel Tank Anti-siphon Valve Primer Bulb Oil Fill Single Engine Fuel System...

  • Page 102: Freshwater System

    Pressure Pump Water Fill Vent Sink Freshwater Tank Spray Head Freshwater System...

  • Page 103: Raw Water System - Macerator

    Head Pump-out Vent Y-Valve Overboard Macerator Discharge Washdown Pump Livewell Head Strainer Holding Tank Livewell Pump Raw Water Intakes Raw Water Intakes Hose Connector Raw Water System - Macerator...

  • Page 104: Raw Water System - Without Macerator

    Head Pump-out Vent Y-Valve Overboard Discharge Washdown Pump Livewell Head Strainer Holding Tank Livewell Pump Raw Water Intakes Raw Water Intakes Hose Connector Raw Water System - Without Macerator...

  • Page 105: Drainage System

    Thru-hull Drain Scupper Bilge Pump Fishbox Drain Baitwell Drain Fishbox Drain Sink Drain Console Cooler Drain Baitwell Overflow Baitwell Cabin Drain Light Rope Locker Drain Scupper Drainage System...
  • Page 106 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 CENTER CONSOLE...

  • Page 107: Glossary Of Terms

    Bilge Pump: A pump that removes water that collects in the bilge. Boarding: Entering or climbing into a boat. Boarding Ladder: Set of steps temporarily fitted over the side of a boat to assist persons coming aboard. 2470 CENTER CONSOLE...
  • Page 108 Compartment: The interior of a boat divided off by bulkheads. Cradle: A framework designed to support a boat as she is hauled out or stored. Cutlass Bearing: A rubber bearing in the strut that supports the propeller shaft. 2470 CENTER CONSOLE...
  • Page 109 Freeboard: The height from the waterline to the lowest part of the deck. alley: The kitchen of a boat. Grab Rail: Hand-hold fittings mounted on cabin tops or sides for personal safety when moving around the boat, both on deck and below. 2470 CENTER CONSOLE...
  • Page 110 A nautical mile is equal to one minute of latitude: 6076 feet. Knots times 1.15 equals miles per hour. Miles per hour times .87 equals knots. ay-up: To decommission a boat for the winter (usually in northern climates). Leeward: The direction toward which the wind is blowing. 2470 CENTER CONSOLE...
  • Page 111 Eye: A deck fitting consisting of a metal eye permanently secured to the boat. Pier: A structure which projects out from the shoreline. Piles or Piling: A long column driven into the bottom to which a boat can be tied. 2470 CENTER CONSOLE...
  • Page 112 Rudder: A moveable flat surface that is attached vertically at or near the stern for steering. ea anchor: An anchor that does not touch the bottom. Provides drag to hold the bow in the most favorable position in heavy seas. 2470 CENTER CONSOLE...
  • Page 113 Superstructure: Something built above the main deck level. Swamps: When a boat fills with water from over the side. Swimming Ladder: Much the same as the boarding ladder except that it extends down into the water. 2470 CENTER CONSOLE...
  • Page 114 Windlass: A winch used to raise and lower the anchor. Windward: Toward the direction from which the wind is coming. acht Basin: A protected facility primarily for recreational small craft. Yaw: When a boat runs off her course to either side. 2470 CENTER CONSOLE...

  • Page 115: Maintenance Log

    Appendix B: Appendix B: Appendix B: Appendix B: Appendix B: MAINTENANCE LOG Service/Repairs Date Hours Dealer 2470 CENTER CONSOLE...
  • Page 116 MAINTENANCE LOG Service/Repairs Date Hours Dealer 2470 CENTER CONSOLE...
  • Page 117 MAINTENANCE LOG Date Dealer Service/Repairs Hours 2470 CENTER CONSOLE...
  • Page 118 MAINTENANCE LOG Date Dealer Service/Repairs Hours 2470 CENTER CONSOLE...
  • Page 119 MAINTENANCE LOG Service/Repairs Date Hours Dealer 2470 CENTER CONSOLE...
  • Page 120 MAINTENANCE LOG Date Dealer Service/Repairs Hours 2470 CENTER CONSOLE...

  • Page 121: Boating Accident Report

    [ ] Yes [ ] No Adjusted [ ] Yes [ ] No NAME AND ADDRESS OF OWNER OF DAMAGED Sized [ ] Yes [ ] No PROPERTY Include any comments of PFD’s under ACCIDENT DESCRIPTION on other side of form 2470 CENTER CONSOLE...

  • Page 122: Boating Accident Report

    Causes based on (check one) Name of Reviewing Office Date Received [ ] This report [ ] Investigation and this report [ ] Investigation [ ] Could not be determined Primary Cause of Accident Secondary Cause of Accident Reviewed By 2470 CENTER CONSOLE...

Table of Contents
