  • Page 1 2470 WALKAROUND OWNER’S MANUAL FISHING BOATS 3901 St. Lucie Blvd. Ft. Pierce, Florida 34946 2470 WALKAROUND Print Date 8/98...
  • Page 2 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 3: Safety Information

    IMPORTANT NOTE: Your boat uses internal combustion engines and flammable fuel. Every precaution has been taken by Pursuit Fishing Boats to reduce the risks associated with possible injury and damage from fire or explosion, but your own precaution and good maintenance procedures are neces- sary in order to enjoy safe operation of your boat.
  • Page 4 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...
  • Page 5 Dear Pursuit 2470 Walkaround Owner: All of us at Pursuit are pleased that you have selected one of our products as your boat. As I’m sure you’ve discovered during the selection and decision process, your Pursuit has been designed, engineered and built with care and precision.
  • Page 6 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 7: Boat Information

    MODEL: SERIAL #: GVRW: DEALER PURSUIT NAME: PHONE: DEALER/PHONE: REPRESENTATIVE: SALESMAN: ADDRESS: SERVICE MANAGER: ADDRESS: Pursuit Fishing Boats reserves the right to make changes and improvements in equipment, design and vendored equipment items, at any time without notification. 2470 WALKAROUND...
  • Page 8 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 9: Important Information

    IMPORTANT INFORMATION Warranty and Warranty Registration Cards The Pursuit Limited Warranty Statement is included with your boat. It has been written to be clearly stated and easily understood. If you have any questions after reading the warranty, please contact the Pursuit Customer Relations Department.
  • Page 10 Limited Warranty, you should contact your Pursuit dealer to arrange for the necessary repair. If you are not near your dealer or another authorized Pursuit dealer or the dealer fails to remedy the cause of the problem, then contact the Pursuit Customer Relations Department within 15 days.
  • Page 11 U.S. Power Squadrons, United States Coast Guard Auxiliary, State Boating Authorities and the American Red Cross offer excellent boating educational programs. These courses are worthwhile even for experienced boaters to sharpen your skills or bring you up to date on current rules and 2470 WALKAROUND...
  • Page 12 Coast Guard jurisdiction. These agencies may also require additional equipment that is not required by the Coast Guard. Your dealer or local boating authority can provide you with additional information for the equipment requirements for your boating area. 2470 WALKAROUND...

  • Page 13: Table Of Contents

    Trim Tabs ................2-4 Control Systems Maintenance ..........2-5 Fuel System Chapter 3: Chapter 3: Chapter 3: Chapter 3: Chapter 3: General ................... 3-1 Outboard Fuel System ............3-3 Fueling Instructions ............... 3-3 Fuel System Maintenance ............3-5 2470 WALKAROUND viii...
  • Page 14 Chapter 7: Cockpit Drainage ..............7-1 Hard Top and Radar Arch Drains .......... 7-1 Bilge Drainage ............... 7-2 Fishbox and Storage Compartment Drainage ......7-3 Sink and Livewell Drains ............7-3 Rope locker Drain ..............7-3 Maintenance................7-3 2470 WALKAROUND...
  • Page 15 Rules of the Road ..............10-1 10.3 Pre-Cruise System Check ............10-3 10.4 Operating Your Boat .............. 10-5 10.5 Grounding and Towing ............10-7 10.6 Water Skiing ................10-8 10.7 Fishing ................... 10-9 10.8 Trailering Your Boat ............. 10-9 2470 WALKAROUND...
  • Page 16 Upholstery, Canvas and Enclosures ........13-4 13.3 Cabin Interior ................13-6 13.4 Bilge ..................13-6 Chapter 14: Seasonal Maintenance Chapter 14: Chapter 14: Chapter 14: Chapter 14: 14.1 Lay-up and Storage ..............14-1 14.2 Winterizing ................14-4 14.3 Recommissioning ..............14-6 2470 WALKAROUND...
  • Page 17 Raw Water System - No Macerator ............ 15-7 Raw Water System - With Macerator ..........15-8 Drainage System ................. 15-9 Appendix A: Glossary of Terms ............A-1 Appendix B: Maintenance Log ............. B-1 Appendix C: Boating Accident Report ..........C-1 2470 WALKAROUND...
  • Page 18 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 19: Chapter 1: Propulsion System

    PROPULSION SYSTEM 1.1 General The Pursuit 2470 Walkaround is designed to be powered with either a single outboard engine or twin outboard engines. Outboard motors use an oil injection system. Oil is automatically injected in the engine(s) and mixed at the proper ratio from oil tank(s) located in the stern of the boat.

  • Page 20: Drive Systems

    DO NOT PAINT THE OUTBOARD MOTORS WITH ANTIFOULING PAINTS DE- SIGNED FOR BOAT HULLS. MANY OF THESE PAINTS CAN CAUSE SEVERE DAMAGE TO THE ENGINES. CONTACT YOUR PURSUIT DEALER OR ENGINE MANUFACTURER FOR INFORMATION ON THE PROPER PAINTING PROCE- DURES.

  • Page 21: Engine Cooling System

    The propellers convert the engine’s power into thrust. They come in a variety of styles, diameters and pitches. The one that will best suit the needs of your Pursuit will depend somewhat on your application and expected average load. Propeller sizes are identified by two numbers stamped on the prop in sequence.

  • Page 22: Engine Instrumentation

    The instrumentation is unique to the type of outboard motors installed on your Pursuit. Some or all of the following gauges may be present. Tachometer...
  • Page 23 If you have a fuel management system installed on your boat, please refer to the engine or fuel management manual for information on that system. 2470 WALKAROUND...
  • Page 24 The ignition switches should be sprayed periodically with a contact cleaner/lubricant. The ignition switches and all instruments, controls, etc. should be protected from the weather when not in use. Excessive exposure can lead to gauge and ignition switch difficulties. 2470 WALKAROUND...

  • Page 25: Chapter 2: Helm Control Systems

    The helm on your Pursuit is designed for a binnacle style control with a single lever for each engine that operates as a gear shift and a throttle. General operation will include a position for neutral (straight up and down), a forward position (the 1st detente forward of neutral), and a reverse position (the 1st detente aft of neutral).

  • Page 26: Engine Stop Switch

    If the engine will not start, slight movement of the shift lever may be necessary to locate the neutral position and disengage the safety cutout switch. Control or cable adjustments may be required to correct this condition should it persist. See your Pursuit dealer for necessary control and cable adjustments.

  • Page 27: Steering System

    A slight clicking sound may be heard as the wheel is turned. This sound is the opening and closing of valves in the helm unit and is normal. Refer to the manufacturer owner’s manual for specific information on the steering system. 2470 WALKAROUND...

  • Page 28: Trim Tabs

    2.7 Trim Tabs Pursuit uses a dual toggle switch to control the trim tabs. The switch is labeled and controls bow up and down movements. It also controls starboard and port up and down movements. Bow up and bow down will control the hull planing attitude while port and starboard up and down provides control for the hull listing.

  • Page 29: Control Systems Maintenance

    The trim tab fluid should be checked often. Keep the fluid level between the marks on the trim tab pump reservoir. If your Pursuit will be left in saltwater for extended periods, it may be necessary to install zinc anodes on the trim tab planes to prevent galvanic corrosion. Refer to the trim tab owner’s manual for additional maintenance information and fluid specifications.
  • Page 30 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 31: Chapter 3: Fuel System

    Twin Engine Fuel System 3.1 General The gasoline fuel system used in Pursuit boats is designed to meet or exceed the requirements of the U.S. Coast Guard, the Boating Industry Association, and The American Boat and Yacht Council in effect at the time of manufacture.
  • Page 32 ATTEMPT TO PUMP IT OUT YOURSELF. WATER AND WASTE PUMPS ARE NOT DESIGNED TO PUMP FUEL AND A FIRE OR EXPLOSION COULD RESULT. CON- TACT YOUR DEALER OR THE PURSUIT CUSTOMER RELATIONS DEPARTMENT FOR ASSISTANCE IN HAVING THE FUEL PROFESSIONALLY REMOVED.

  • Page 33: Outboard Fuel System

    3.2 Outboard Fuel System The fuel system on the Pursuit 2470 Walkaround has one fuel tank. The fuel tank is mounted in the center of the bilge and has one or two withdrawal lines equipped with anti-siphon valves where the fuel lines attach to the fuel tank. This valve prevents gasoline from siphoning out of the fuel tank should a line rupture.
  • Page 34 Remove the nozzle. Install and tighten the fuel cap. Be careful not to overtighten the cap. Check the fuel compartment and below the deck for fuel odors. If you smell fuel, do not start the engine. 2470 WALKAROUND...

  • Page 35: Fuel System Maintenance

    Since the fuel pick up tube is very near the bottom of the tank, phase separation can cause the engine to run very poorly or not at all. This condition is more severe with methyl alcohol and 2470 WALKAROUND...
  • Page 36 DO NOT DRAIN ANY FUEL INTO THE BILGE. THIS COULD LEAD TO A FIRE OR EXPLOSION. AFTER THE FILTER ELEMENT HAS BEEN CHANGED, PRIME THE FUEL SYSTEM AND CHECK ALL FITTINGS FOR LEAKS BEFORE AND AFTER STARTING THE ENGINE. 2470 WALKAROUND...

  • Page 37: Chapter 4: Electrical System

    Chapter 4: ELECTRICAL SYSTEM 4.1 General Your Pursuit is equipped with a 12-volt DC electrical system that draws current from on-board batteries. The 12-volt batteries in your boat are usually the lead-acid type. They will require maintenance similar to those found in automobiles. The batteries are located in the stern bilge, below the bench seat and removable fishbox.
  • Page 38 Otherwise, it is recommended that one selector switch be set on battery # 1 and the other switch be on battery # 2 when the engines are operating. 2470 WALKAROUND...
  • Page 39 5 to ten minutes for approximately 2 seconds. If the pump senses water, it will continue to pump until the water is completely discharged, if it does not sense water, it will immediately shut off. The electrical drain during the check cycle is negligible and will not affect 2470 WALKAROUND...
  • Page 40 Additional switch panels may be located in various locations in the cockpit and helm area of the boat. Most of these panels are equipped with one switch and one circuit breaker. The following is a description of additional panels that may be on your Pursuit and the accessories they control: Baitwell Switch This switch activates the baitwell circulating pump that supplies water to the baitwell.

  • Page 41: Electrical System Maintenance

    Keep the battery tops clean and dry. Dirt and water can conduct electricity from one post to the other causing the battery to discharge. 2470 WALKAROUND...
  • Page 42 AT LEAST ANNUALLY AND CLEANED AS REQUIRED. DO NOT ALLOW CORRO- SION TO BUILD ON CONNECTIONS. THE ELECTRICAL SYSTEM ALWAYS SHOULD BE DISCONNECTED FROM THE POWER SOURCE BEFORE INSPECTING OR SERVICING THE SYSTEM. NEVER SERVICE ANY COMPONENT OF AN ELECTRICAL SYSTEM WHILE IT IS ENER- GIZED. 2470 WALKAROUND...

  • Page 43: Chapter 5: Freshwater System

    WASTE TANK, DO NOT ATTEMPT TO PUMP IT OUT YOURSELF. WATER AND WASTE PUMPS ARE NOT DESIGNED TO PUMP FUEL AND A FIRE OR EXPLOSION COULD RESULT. CONTACT YOUR DEALER OR THE PURSUIT CUSTOMER RELA- TIONS DEPARTMENT FOR ASSISTANCE IN HAVING THE FUEL PROFESSIONALLY REMOVED AND COMPONENTS OF THE FRESHWATER SYSTEM REPLACED AS NECESSARY.

  • Page 44: Freshwater System Operation

    The batteries must be properly maintained and charged. Operating the pressure pump from a battery with a low charge could lead to pump failure. Add a commercially available potable water conditioner to the water tank(s) to keep them fresh. 2470 WALKAROUND...
  • Page 45 THE BATTERIES MUST BE PROPERLY CHARGED. OPERATING THE FRESHWA- TER PUMP FROM A BATTERY WITH A LOW CHARGE MAY LEAD TO A PUMP FAILURE. 2470 WALKAROUND...
  • Page 46 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 47: Chapter 6: Raw Water System

    Note: It may be necessary to reprime the raw water system if the system is not used for an extended period and at the time of launching. 2470 WALKAROUND...

  • Page 48: High Pressure Washdown

    Washdown Hose Connector ALWAYS TURN THE RAW WATER PUMP SWITCH TO THE “OFF” POSITION WHEN LEAVING THE BOAT UNATTENDED. DO NOT RUN THE HIGH PRESSURE PUMP DRY FOR EXTENDED PERIODS AS DAMAGE TO THE PUMP WILL RESULT. 2470 WALKAROUND...

  • Page 49: Livewell

    This should be checked frequently and cleaned as necessary. Note: Do not use the livewell as a dry storage area when it is not in use. Sea water could accidently be delivered to the livewell from the thru hull and damage equipment stored there. 2470 WALKAROUND...

  • Page 50: Raw Water System Maintenance

    THE BATTERIES MUST BE PROPERLY CHARGED. OPERATING ANY PUMPS FROM A BATTERY WITH A LOW CHARGE MAY LEAD TO A PUMP FAILURE. THE RAW WATER SYSTEM MUST BE PROPERLY WINTERIZED PRIOR TO WIN- TER LAY-UP. SEE SECTION ON WINTERIZING. 2470 WALKAROUND...

  • Page 51: Chapter 7: Drainage Systems

    Drainage System 7.1 Cockpit Drainage Your Pursuit has two scupper drains located on each side of the hull, near the waterline, to provide drainage for the cockpit. Water is channeled away from all opening hatches by a gutter or drain rail system.

  • Page 52: Bilge Drainage

    CERTAIN BULKHEAD AREAS ARE SEALED IN ACCORDANCE WITH U.S. COAST GUARD REGULATIONS THAT WERE IN EFFECT AT THE DATE OF MANUFAC- TURE OF THE BOAT. ANY MODIFICATIONS TO THESE BULKHEADS SHOULD BE IN ACCORDANCE WITH THE U.S. COAST GUARD REGULATIONS. 2470 WALKAROUND...

  • Page 53: Fishbox And Storage Compartment Drainage

    Flush all gravity drains with fresh water to keep them clean and free flowing. • Clean and flush the fishboxes and livewells with soap and fresh water or a bilge cleaner after each use to keep them clean and fresh. 2470 WALKAROUND...
  • Page 54 ALL DRAINS AND PUMPS MUST BE PROPERLY WINTERIZED BEFORE WINTER LAY-UP. NEVER USE HARSH CHEMICAL DRAIN CLEANERS IN MARINE DRAIN SYSTEMS. PERMANENT DAMAGE TO THE HOSES AND FITTINGS MAY RESULT. 2470 WALKAROUND...

  • Page 55: Cabin Ventilation

    To open the vent, release the locking T-handle and open the vent to the desired position. Lock the vent in place by turning the T-handle 1/4 turn. The friction of the T-handle in the guide will hold the vent in that position. Windshield Vent 2470 WALKAROUND...

  • Page 56: Carbon Monoxide And Ventilation

    “Carbon Monoxide Detector” in the Safety Equipment Chapter of this manual, and the owner’s manual supplied by the CO detector manufacturer for operation instructions and additional information regarding the hazards and symptoms of carbon monoxide poisoning. 2470 WALKAROUND...

  • Page 57: Maintenance

    . Use a soft cloth and mild soap and water for routine cleaning. Solvents and products containing ammonia can permanently damage acrylic glass. Please refer to the Routine Maintenance chapter for more information on the proper maintenance for acrylic plastic glass 2470 WALKAROUND...
  • Page 58 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 59: Chapter 9: Safety Equipment

    Immediately throttle the engine back to idle. • Shift the transmission to neutral. • Monitor the engine gauges to determine the cause of the problem. • If necessary, shut off the engine and investigate until the cause of the problem is found. 2470 WALKAROUND...

  • Page 60: Neutral Safety Switch

    9.4 Engine Stop Switch Your Pursuit is equipped with a engine stop switch and lanyard. When the lanyard is pulled it will engage the switch and shut off the engine. We strongly recommend that the lanyard be attached to the driver whenever the engine is running.
  • Page 61 Guard emphasizes that PFDs should be worn at all times when the vessel is underway. Throwable devices must be immediately available for use. All Pursuit boats must be equipped with at least one Type I, II or III PFD for each person on board, plus one throwable device (Type IV). Some states have special PFD requirements for children.
  • Page 62 50-70 times per minute is considered a distress signal. Fire Extinguishers At least one fire extinguisher is required on all Pursuit boats. Boats 26' and Fire Extinguisher larger may require two or three fire extinguishers. Coast Guard approved fire extinguishers are hand-portable, either B-I or B-II classification and have a specific marine type mounting bracket.

  • Page 63: Carbon Monoxide Detector

    (fog, rain, haze, etc.) Navigation lights are intended to keep other vessels informed of your presence and course. Your Pursuit is equipped with the navigation lights required by the U.S. Coast Guard at the time of manufacture. It is up to you to make sure they are operational and turned on when required.
  • Page 64 Anyone with these symptoms should immediately be moved to an area of fresh air. Have the victim breath deeply and seek immediate medical attention. 2470 WALKAROUND...

  • Page 65: First Aid

    Ask a medical professional about the supplies you should carry and the safe shelf life of prescription drugs or other medical supplies that may be in your first-aid kit. Replace questionably old supplies whether they have been used or not. 2470 WALKAROUND...

  • Page 66: Maximum Capacity Rating

    Flashlight & Batteries Mirror Searchlight Sunburn Lotion Tool Kit Ring Buoy Whistle or Horn Anchor Chart and Compass Boat Hook Spare Propeller Mooring Lines Food & Water Binoculars Sunglasses Marine Hardware Extra Clothing Spare Parts Spare Keys Portable Radio 2470 WALKAROUND...

  • Page 67: Chapter 10: Chapter

    OPERATION 10.1 General Before you start the engines on your Pursuit, you should have become familiar with the various component systems and their operation, and have performed a “Pre-Cruise System Check.” A thorough understanding of the component systems and their operation is essential to the proper operation of the boat.
  • Page 68 You should be familiar with these and any other markers used in your boating area. STORMS AND WAVE ACTION CAN CAUSE BUOYS TO MOVE. YOU SHOULD NOT RELY ON BUOYS ALONE TO DETERMINE YOUR POSITION. 2470 WALKAROUND 10-2...

  • Page 69: Pre-Cruise System Check

    • Check the bilge water level. Look for other signs of potential problems. Monitor for the scent of fuel fumes. • Test the automatic and manual bilge pump switches to make sure the system is working properly. 2470 WALKAROUND 10-3...
  • Page 70 Be sure the shift control is in the neutral position. • Be sure the emergency stop lanyard is attached to the operator and the stop switch. VAPORIZING LIQUID EXTINGUISHERS GIVE OFF TOXIC FUMES; USE ONLY COAST GUARD APPROVED FIRE EXTINGUISHERS. 2470 WALKAROUND 10-4...

  • Page 71: Operating Your Boat

    Alcohol reduces night vision, and the ability to distinguish red from green. YOU SHOULD NEVER OPERATE YOUR BOAT WHILE UNDER THE INFLUENCE OF ALCOHOL AND DRUGS. • Avoid sea conditions that are beyond the skill and experience of you and your crew. 2470 WALKAROUND 10-5...
  • Page 72 Raise the trim tabs to the full “UP” position. After Operation • If operating in saltwater, wash the boat and all equipment with soap and water. Flush the engines using freshwater. Please refer to the engine owner's manual for instructions on flushing your outboard engines. 2470 WALKAROUND 10-6...

  • Page 73: Grounding And Towing

    U.S. Coast Guard or a commercial towing company, to safely accomplish the towing task. THE MOORING CLEATS ON PURSUIT BOATS ARE NOT DESIGNED OR INTENDED TO BE USED FOR TOWING PURPOSES. THESE CLEATS ARE SPECIFICALLY DE- SIGNED AS MOORING CLEATS FOR SECURING THE BOAT TO A DOCK, PIER, ETC.

  • Page 74: Water Skiing

    Never leave a fallen skier alone in the water for any reason. For additional information on water skiing, including hand signals and water skiing manuals, contact the American Water Skiing Association in Winter Haven, Florida, 813-324-4341. 2470 WALKAROUND 10-8...

  • Page 75: Fishing

    Important Note: Your Pursuit is a heavy boat and care must be taken when selecting the trailer. We recommend that you use a bunk style trailer that incorporates a combination of heavy duty rollers, to support the keel and long bunks running under and parallel to the stringers to support the hull.
  • Page 76 PORT THE HULL. ALWAYS MAKE SURE THE TRAILER BUNKS AND ROLLERS ARE ADJUSTED SO THEY ARE NOT PUTTING EXCESSIVE PRESSURE ON THE LIFTING STRAKES AND ARE PROVIDING ENOUGH SUPPORT FOR THE HULL. HULL DAMAGE RESULTING FROM IMPROPER TRAILER SUPPORT IS NOT COV- ERED BY THE PURSUIT WARRANTY. 2470 WALKAROUND 10-10...
  • Page 77 Too little weight on the hitch will cause the rig to fishtail and will make controlling the tow vehicle difficult. Contact your Pursuit dealer or the trailer manufacturer for the correct weight on the hitch for your trailer. •...
  • Page 78 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 79: Chapter 11: Chapter 11: Exterior Equipment

    IMPORTANT: All fittings must be periodically inspected for loose fit, wear and damage. Any problems should be corrected immediately. PURSUIT BOATS ARE NOT EQUIPPED WITH HARDWARE DESIGNED FOR TOW- ING PURPOSES. THE MOORING CLEATS ARE NOT TO BE USED FOR TOWING ANOTHER VESSEL OR HAVING THIS BOAT TOWED.
  • Page 80 AND CLOTHING ARE KEPT CLEAR OF THE WINDLASS AND ANCHOR LINE DUR- ING OPERATION. DO NOT USE A WINDLASS AS A SOLE MEANS OF SECURING AN ANCHOR IN THE BOW PULPIT. ALWAYS SECURE THE ANCHOR LINE TO A CLEAT OR CHAIN BINDER BEFORE OPERATING YOUR BOAT. 2470 WALKAROUND 11-2...

  • Page 81: Hull

    11.2 Hull Swim Platform Your Pursuit is equipped with an integral swim platform and engine mounting system located in the stern of the boat. There is one inspection plate in the transom engine well to provide access to the stern bilge and engine mounting bolts. Always make sure this plate is secure before operating your boat.

  • Page 82: Cockpit Equipment

    ENGINE(S) ARE RUNNING. IN SOME SITUATIONS IT IS POSSIBLE TO ACCIDEN- TALLY ENGAGE THE ENGINE SHIFT AND THROTTLE CONTROL INTO GEAR AS THE HELM IS OPENING. THIS COULD RESULT IN LOSS OF CONTROL, DAMAGE TO THE BOAT, AND INJURY TO PASSENGERS. 2470 WALKAROUND 11-4...
  • Page 83 Install the ladder. Open the seat and snap the hatch lifter to the ball hinge fitting on the seat. Install the plastic end cap in the lifter ball hinge fitting to prevent the lifter from popping off the ball hinge. 2470 WALKAROUND 11-5...
  • Page 84 ALLOW PERSONS TO FALL OVERBOARD AND INTO BOAT PROPELLERS OR TO BE LOST IN OPEN WATER. ALWAYS CHECK TO MAKE SURE THE TRANSOM DOOR IS PROPERLY CLOSED AND LATCHED BEFORE STARTING THE ENGINES AND NEVER OPERATE THE BOAT UNDER POWER WITH THE TRANSOM DOOR OPEN. 2470 WALKAROUND 11-6...

  • Page 85: Chapter 12: Chapter 12: Interior Equipment

    FORE MODIFYING OR REMOVING THE PUMP OUT SYSTEM. THE PORTABLE HEAD MUST BE PROPERLY WINTERIZED BEFORE WINTER LAY-UP OR FOR COLD WEATHER USE. PLEASE REFER TO THE MANUFAC- TURER OWNER’S MANUAL FOR COLD WEATHER AND WINTERIZING INSTRUC- TIONS. 2470 WALKAROUND 12-1...

  • Page 86: Marine Head System

    When the macerator discharge pump is installed, the Y-valve will be used to select either the macerator discharge pump or the waste deck fitting to evacuate the holding tank. 2470 WALKAROUND 12-2...

  • Page 87: Cabin And V-Berth

    Daylight and fresh air is provided to this area by an overhead opening hatch. Additional lighting is provided by 12-volt lights on the forward bulkhead. 2470 WALKAROUND 12-3...
  • Page 88 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 89: Chapter 13: Chapter 13: Routine Maintenance

    Zincs should be checked monthly and changed when they are 75% of their original size. When replacing the anodes, make sure the contact surfaces are clean, shiny metal and free of paint and corrosion. Never paint over the anode. 2470 WALKAROUND 13-1...
  • Page 90 Anodized aluminum should be washed periodically with soap and water to keep it clean. If the boat is used in saltwater or polluted water, the aluminum should be washed with soap and water after each use. Saltwater allowed to remain on anodized aluminum will penetrate the anodized coating and attack the aluminum. 2470 WALKAROUND 13-2...
  • Page 91 The anodized aluminum used on your Pursuit was coated with a metal protector called Aluma Guard at the factory. Aluma Guard is a nonabrasive marine metal protector that protects anodized aluminum, stainless steel, brass, and chrome.

  • Page 92: Upholstery, Canvas And Enclosures

    Food grease and oily stains - Spray immediately using either Fantastik Cleaner or Tannery ® Car Care Cleaner , wiping with a soft cloth. Take care not to extend the area of contamination beyond its original boundary. Rinse with clean water. 2470 WALKAROUND 13-4...
  • Page 93 Do not operate engines, fuel consuming heaters or burners with the canvas enclosures closed. The cockpit must be open for legal ventilation and to prevent the possible accumulation of carbon dioxide fumes, which could be lethal. 2470 WALKAROUND 13-5...

  • Page 94: Cabin Interior

    Periodically check the bilge pumps for proper operation and clean debris from the strainers and float switches. Inspect all hoses, clamps and thru hulls for leaks and tightness on a regular basis and operate all thru hull valves at least once a month to keep them operating properly. 2470 WALKAROUND 13-6...

  • Page 95: Lay-Up And Storage

    Your dealer or the engine manufacturer can provide additional information on fuel degradation and fuel stabilizers recommended for your engine. For more recommendations for your specific area, check with your local Pursuit dealer. • Drain water from the freshwater system.
  • Page 96 The cradle must be specifically for boat storage. • Make sure the cradle is well supported and placed on a level surface with the bow high enough to provide proper drainage of the bilge. • Make sure the engines are in the down position. 2470 WALKAROUND 14-2...
  • Page 97 ARE ADJUSTED SO THEY ARE NOT PUTTING PRESSURE ON THE LIFTING STRAKES AND ARE PROVIDING ENOUGH SUPPORT FOR THE HULL. HULL DAMAGE RESULTING FROM IMPROPER CRADLE OR TRAILER SUPPORT IS NOT COVERED BY THE PURSUIT WARRANTY. Preparing The Boat For Storage •...

  • Page 98: Winterizing

    After the antifreeze has been added to the holding tank, open the overboard discharge valve and activate the macerator pump until the antifreeze solution is visible at the discharge thru hull. Note: Make sure you follow the marine toilet manufacturer's winterizing instructions exactly. 2470 WALKAROUND 14-4...
  • Page 99 Proper storage is very important to prevent serious damage to the boat. If the boat is to be stored indoors, make sure the building has enough ventilation. It is very important that there is enough ventilation both inside the boat and around the boat. 2470 WALKAROUND 14-5...

  • Page 100: Recommissioning

    • Pump the antifreeze from the fresh and raw water systems and flush several times with freshwater. • Check and lubricate the steering system. • Clean and wash the boat. • Install all upholstery, cushions and canvas. 2470 WALKAROUND 14-6...
  • Page 101 This insures that the cooling pump is operating. • Carefully monitor the gauges and check for leakage and abnormal noises. • Operate the boat at slow speeds until the engine temperature stabilizes and all systems are operating normally. 2470 WALKAROUND 14-7...
  • Page 102 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...
  • Page 103 Chapter 15: SCHEMATICS 2470 WALKAROUND 15-1...

  • Page 104: Single Engine 12-Volt Wiring Schematic

    Single Engine 12-Volt Wiring Schematic 2470 WALKAROUND 15-2...

  • Page 105: Hydraulic Steering System

    Helm Hydraulic Lines Steering Cylinder Hydraulic Steering System...

  • Page 106: Twin Engine Fuel System

    Twin Engine Fuel System...

  • Page 107: Single Engine Fuel System

    Single Engine Fuel System...
  • Page 108 2470 WALKAROUND 15-6...

  • Page 109: Raw Water System - No Macerator

    Raw Water System (No Macerator)

  • Page 110: Raw Water System - With Macerator

    Raw Water System (With Macerator)
  • Page 111 2470 WALKAROUND 15-9...
  • Page 112 THIS PAGE WAS LEFT BLANK INTENTIONALLY 2470 WALKAROUND...

  • Page 113: Appendix A: Glossary Of Terms

    Bilge: The bottom of the boat below the flooring. Bilge Pump: A pump that removes water that collects in the bilge. Boarding: Entering or climbing into a boat. Boarding Ladder: Set of steps temporarily fitted over the side of a boat to assist persons coming aboard. 2470 WALKAROUND...
  • Page 114 Compartment: The interior of a boat divided off by bulkheads. Cradle: A framework designed to support a boat as she is hauled out or stored. Cutlass Bearing: A rubber bearing in the strut that supports the propeller shaft. 2470 WALKAROUND...
  • Page 115 Freeboard: The height from the waterline to the lowest part of the deck. alley: The kitchen of a boat. Grab Rail: Hand-hold fittings mounted on cabin tops or sides for personal safety when moving around the boat, both on deck and below. 2470 WALKAROUND...
  • Page 116 A nautical mile is equal to one minute of latitude: 6076 feet. Knots times 1.15 equals miles per hour. Miles per hour times .87 equals knots. ay-up: To decommission a boat for the winter (usually in northern climates). Leeward: The direction toward which the wind is blowing. 2470 WALKAROUND...
  • Page 117 Eye: A deck fitting consisting of a metal eye permanently secured to the boat. Pier: A structure which projects out from the shoreline. 2470 WALKAROUND...
  • Page 118 Rudder: A moveable flat surface that is attached vertically at or near the stern for steering. ea anchor: An anchor that does not touch the bottom. Provides drag to hold the bow in the most favorable position in heavy seas. 2470 WALKAROUND...
  • Page 119 Superstructure: Something built above the main deck level. Swamps: When a boat fills with water from over the side. Swimming Ladder: Much the same as the boarding ladder except that it extends down into the water. 2470 WALKAROUND...
  • Page 120 Windlass: A winch used to raise and lower the anchor. Windward: Toward the direction from which the wind is coming. acht Basin: A protected facility primarily for recreational small craft. Yaw: When a boat runs off her course to either side. 2470 WALKAROUND...

  • Page 121: Appendix B: Maintenance Log

    Appendix B: MAINTENANCE LOG Service/Repairs Date Hours Dealer 2470 WALKAROUND...
  • Page 122 MAINTENANCE LOG Service/Repairs Date Hours Dealer 2470 WALKAROUND...
  • Page 123 MAINTENANCE LOG Date Dealer Service/Repairs Hours 2470 WALKAROUND...
  • Page 124 MAINTENANCE LOG Date Dealer Service/Repairs Hours 2470 WALKAROUND...
  • Page 125 MAINTENANCE LOG Service/Repairs Date Hours Dealer 2470 WALKAROUND...
  • Page 126 MAINTENANCE LOG Date Dealer Service/Repairs Hours 2470 WALKAROUND...

  • Page 127: Appendix C: Boating Accident Report

    [ ] Yes [ ] No Adjusted [ ] Yes [ ] No NAME AND ADDRESS OF OWNER OF DAMAGED Sized [ ] Yes [ ] No PROPERTY Include any comments of PFD’s under ACCIDENT DESCRIPTION on other side of form 2470 WALKAROUND...
  • Page 128 Causes based on (check one) Name of Reviewing Office Date Received [ ] This report [ ] Investigation and this report [ ] Investigation [ ] Could not be determined Primary Cause of Accident Secondary Cause of Accident Reviewed By 2470 WALKAROUND...

Table of Contents
