- Page 1 Assembly Guide Model Numbers: 12601559 12601578 12601663 12601664 12601665 12601688 12601514 12601514-C1 ELECTRIC (English) 42804641 • 09/14/11...
- Page 2 A, B, C, Assembly: ASSEMBLY GUIDE CAUTION: For your safety, before operating, Read Product Guide & Outdoor Cooking Guide provided with this grill. *SAFETY First….. Grill components may have sharp edges. Be careful when handling grill parts during assembly. We suggest that you wear a sturdy pair of leather gloves while handling the grill parts. BEFORE You begin assembly of your grill….
- Page 3 Grill Parts Diagram ASSEMBLY GUIDE Key Qty Description Key Qty Description Key Qty Description Grease Tray Grease Tray Guide Grill Lid Hubcap — Hardware Pack Lower Body Warming Rack — Assembly Guide, English Controller — Assembly Guide, Spanish, optional Axle Element Assembly —...
- Page 4 GRILL CART Assembly ASSEMBLY GUIDE Fasteners Part – Cart Base – Front Leg Set – Rear Leg Set – Wheels Wheel Retaining – Hubcap Clip 1/4x20-1/2" 3/8-16 Nut (qty 2) screw (qty 2) (qty 4) Step 1 – Attach Front Leg Set (A2) to the Cart Base (A1) using 2 1/4-20 screws.
- Page 5 GRILL CART Assembly ASSEMBLY GUIDE Fasteners Part – Cart Bracket Wire Shelf – – Leg End Cap 1/4x20-2" screw (qty 4) 1/4-20 Nut 1/4-20 Nut (qty 4) #10x3/8" screw (qty 2) Step 3 - Carefully turn the Cart Assembly over and allow it to rest on the tops of the leg assemblies.
- Page 6 GRILL BODY Assembly ASSEMBLY GUIDE Fasteners Part Qty. – Lower Body – Wind Shield 10-24x3/8" screw – Grill Lid (qty 3) 10-24 Nut Fiber Washer 1/4-20 Nut 1/4-20x3/4" (qty 10) (qty 5) (qty 2) Hinge screw Step 1 ASSEMBLY (qty 2) - Attach the Lower Body Assembly (B1) to the Cart Assembly by aligning the studs on the bottom of the Step 3 -...
- Page 7 GRILL FINAL Assembly ASSEMBLY GUIDE NOTE: The Cooking Grate may Part Qty. have sharp edges. Be very careful Cooking Grate C1 – when handling the Cooking Grate. C2 – Warming Rack You should wear gloves when C3 – Grease tray handling the Cooking Grate.
- Page 8 GRILL FINAL Assembly ASSEMBLY GUIDE Part Qty. Fasteners C4 – Controller C5 – Lid Handle 10-24x3/8" screw Fiber Washer (qty 2) (qty 2) NOTE: Be sure to press the controller into the receptacle as far as it will go. Route the controller cord BEHIND the towel bar as shown.
