MONTANA
Product Guide
Model 12301781
Tools needed for assembly:
Phillips Screwdriver
Adjustable Wrench
IMPORTANT: Fill out the product record information below.
Date Purchased
CAUTION:
Read and follow all safety statements, assembly instructions,
and use and care directions before attempting to assemble
and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal inside
homes, vehicles, or tents.
MADE IN CHINA
Importador: EVANS POWER EQUIPMENT, S.A. DE C.V.
Camino a Cóndor # 399, Col. El Castillo C.P.45680
El Salto, Jalisco, Mexico Tel. 0133 3668 2500
FOR OUTDOOR USE ONLY
© 2011 Char-Broil, LLC
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges. Wear
protective gloves if necessary.
CAUTION:
THIS UNIT IS HEAVY! DO NOT attempt to
assemble without a helper.
If you have any questions or Need
help during the Assembly, call 01800
00EVANS
• Columbus, GA 31902 •
Printed in China
42804934 -12301781 - 12/16/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 12301781 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Char-Broil 12301781

Summary of Contents for Char-Broil 12301781

  • Page 1: Product Record Information

    Camino a Cóndor # 399, Col. El Castillo C.P.45680 help during the Assembly, call 01800 El Salto, Jalisco, Mexico Tel. 0133 3668 2500 00EVANS 42804934 -12301781 - 12/16/11 © 2011 Char-Broil, LLC • Columbus, GA 31902 • Printed in China...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING Product Record Information ......1 FAILURE TO READ AND FOLLOW INSTRUCTIONS FOR Safety Symbols.

  • Page 3: Preparing To Use Your Grill

    Re-season your grates frequently, particularly when new. If rust occurs, it is an indication that the grates have not been seasoned enough or the seasoning has been burned off. Clean with a heavy brush like Char-Broil’s Brush Hawg. Reapply vegetable shortening and heat as indicated above to re-season the grates.

  • Page 4: Cooking Tips

    COOKING TIPS Building Your Fire Stack charcoal briquettes or wood into a pyramid-shaped pile on top of the charcoal grate. We recommend using 2 pound (approximately 30 briquettes) to start your fire, adding more as needed. If using lighter fluid, saturate the charcoal briquettes with lighter fluid and let it soak in for approximately 5 minutes.
  • Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.

  • Page 6: Warranty

    Producto / Product: Asador de carbon / Charcoal grill Modelo(s) / Model (s): 12301781 EVANS POWER EQUIPMENT, S.A. DE C.V. garantiza este producto por el término de 90 dias en todas sus partes y mano de obra contra cualquier defecto de fabricación y funcionamiento a partir de la fecha de la compra bajo las siguientes condiciones: 1.

  • Page 7: Parts List/ Parts Diagram

    PARTS LIST Key Qty Description Key Qty Description Smokestack Lid Assembly Adjuster Crank Handle Swing-Away Grate Lid Handle Cooking Grate Handle Seat Handle, F/Clean Out Door w/Latch Caster, Locking Air Damper Ash Pan Charcoal Pan w/Adjust Assembly Right Rear Leg Hinge Assembly Left Side Shelf Left Front Leg...

  • Page 8: Assembly

    ASSEMBLY FIRST, GET A HELPER! This unit is heavy and requires a second person for lifting and moving. NEXT, pick a suitable location to work. Open the carton and slit the corners so that the carton lays flat. This will give you a protective surface during assembly.
  • Page 9 Attach the Charcoal Pan Assembly to the inside front panel of the Firebox using (4) 1/4-20x1/2” Hex Bolts. Tighten securely with flat wrench provided. Charcoal Pan Assembly Firebox Front of Firebox 1/4-20x1/2” Hex Bolts NOTE: Mounting bracket with hole fits over threaded bushing Page 9...
  • Page 10 Attach Bottom Shelf to Legs using (4) 1/4-20x2 3/8” Screws. 1/4-20x2 3/8” Screws 1/4-20x2 3/8” Screws Turn grill upside down. Screw (2) Casters into Front/Rear Legs and tighten with Flat Wrench provided with grill. Caster Caster Page 10...
  • Page 11 Insert a small Hair Pin Clip into the hole at one end of the Axle. Slide a Large Flat Washer and a Wheel onto the Axle. Slide the Axle through the holes at the ends of the Legs. Slide the remaining Wheel onto the Axle. Slide a Large Flat Washer onto the Axle and secure with remaining Hair Pin Clip.
  • Page 12 Attach the Handle to the front of Ash Pan with (2) 1/4-20x1/2” Screws. Slide the Ash Pan into the bottom of the Firebox. Handle 1/4-20x1/2” Screw Firebox 1/4-20x1/2” Screw 1/4-20x1/2 Screws Attach Lid Handle and Handle Seats to the Lid using (2) 1/4-20x1/2” Screws. 1/4-20x1/2”...
  • Page 13 Attach (2) Hinge Assemblies to the rear of Lid using (4) 1/4-20x1 3/8” Screws and (4) 1/4-20 Flange Nuts. Note orientation shown in enlargement. 1/4-20x1 3/8” Screws 1/4-20x1 3/8” Screws Insert Smokestack Assembly through hole in Lid. Attach Smokestack Assembly to Lid using (2) 1/4-20x1/2” Screws and (2) 1/4-20 Flange Nuts.
  • Page 14 Place Lid Assembly onto Firebox Assembly while aligning holes in Hinge Assemblies with holes in Firebox Rear Panel. Attach (2) Hinges Assemblies to the rear of the Firebox Assembly using (4) 1/4-20x1 5/8” Screws. Lid Assembly 1/4-20x1 5/8” Screws 1/4-20x1 5/8” Screws Firebox Rear Panel Remove Flat Washer, Door Latch, Lock Washer and 3/8-16 Nut from Handle.
  • Page 15 Attach the Tool Hooks to the underside of the Side Shelf with Threaded Inserts using (3) 1/4-20x1/2” Screws. Attach this Side Shelf Assembly to grill Left Legs using (4) 1/4-20x5/8” Shoulder Screws. 1/4-20x1/2” Screws 1/4-20x5/8” Shoulder Screw Tool Hooks 1/4-20x1/2 Screws Side Shelf W/Threaded Inserts Attach other Side Shelf to Right Legs using (4) 1/4-20x5/8”...
  • Page 16 Screw Adjuster Crank through front of Firebox. Rotate Adjuster Crank clockwise until Adjuster Crank engages Crank Lever. Insert Hair Pin Clip into Adjuster Crank Shaft. Hair Pin Clip Crank Lever Adjuster Crank Front of Grill Body Adjuster Crank Shaft Insert straight wire of Swingaway Grid into one side of Lid and then into the other side. Insert angled wire into holes in Firebox.
  • Page 17 Place the (3) Cooking Grates into the firebox. The Cooking Grates will rest on the front and rear ledges of the firebox. Cooking Grates Lid omitted for clarity Remove Wingnut from Temperature Gauge. Insert Temperature Gauge through the hole in Lid and attach using Wingnut previously removed.

  • Page 18: Hardware List

    HARDWARE LIST Hardware is shown actual size. You may have spare hardware after assembly is complete. 1/4-20 x 2 3/8” Machine Screw Qty. 4 1/4-20 x 1 5/8” Machine Screw Qty. 4 1/4-20 x 1 3/8” Machine Screw Qty. 4 1/4-20 x 1/2”...
