TRUlink 29594 User Manual

Wireless usb to audio kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U
G
SER
UIDE
W
USB
A
K
IRELESS
TO
UDIO
IT
Model: 29594
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 29594 and is the answer not in the manual?

Questions and answers

Related Manuals for TRUlink 29594

Summary of Contents for TRUlink 29594

  • Page 1 UIDE IRELESS UDIO Model: 29594...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS Introduction..............................2 Features..............................3 System Requirements..........................4 Package Contents............................5 Device Overview Wireless USB Host Adapter.......................6 Wireless Audio Device Adapter…………………………………………………………………………….7 Software/Device Installation........................8 Using the Wireless USB to Audio Kit......................15 Frequently Asked Questions........................19 Technical Specifications..........................20 Cables To Go Warranty..........................21 Important Safety Information........................22 Appendix Association with other devices......................23 Cable Association Procedure......................24...

  • Page 3: Introduction

    NTRODUCTION Thank you for purchasing the TruLink™ Wireless USB to Audio Kit. The TruLink USB to Audio Kit includes everything you need to wirelessly stream audio from your computer to a remote sound system, projector or television. Utilizing Ultra-Wide Band technology, the USB to Audio Kit enables secure, in- room wireless connectivity at distances up to 30 feet between the computer and the audio device.

  • Page 4: Features

    EATURES In-room wireless connectivity up to 30 feet Audio conversion from USB to 3.5mm stereo Up to six computers can share one wireless audio device* Ultra-Wide Band operates in the frequency on 3.1GHz to 4.8GHz (WiMedia™ Band Group 1) Certified Wireless™ USB 1.0 compliant WiMedia 1.0 MAC &...

  • Page 5: System Requirements

    YSTEM EQUIREMENTS Microsoft® Windows® XP 32-bit with Service Pack 3 or higher or Microsoft® Vista® 32-bit/64-bit...

  • Page 6: Package Contents

    ACKAGE ONTENTS Wireless USB Host Adapter for your computer Wireless Audio Device Adapter for your audio device Two (2) Dipole Antennas (one for each adapter) 3ft USB A Male/Mini-B Male Cable USB Extender with Cradle One (1) AC Power Adapter (cord approx. 4ft) User Guide Quick Start Guide Driver CD w/Electronic User Guide...

  • Page 7: Device Overview

    EVICE VERVIEW USB H IRELESS DAPTER 1. Link: Data Connection Indicator • LED is solid when transfer device is connected • LED blinks when data is being transferred 2. PWR: Power • LED is solid when powered by the PC...

  • Page 8: Wireless Audio Device Adapter

    EVICE VERVIEW IRELESS UDIO EVICE DAPTER 1. Activity Indicator • LED is solid when display cable is connected. • LED is blinking when data is being transferred. 2. PWR: Power Indicator • LED is solid when power is applied. 3. PWR plug •...

  • Page 9: Software/Device Installation

    OFTWARE EVICE NSTALLATION IMPORTANT NOTE: • If installing on Windows XP, Service Pack 3 (SP3) is required. Verify that this has been installed before installing the Wireless USB to Audio Kit software. • Before installing the software, make sure that the Wireless USB Host Adapter and Wireless Audio Device Adapter are not connected to the computer.
  • Page 10 OFTWARE EVICE NSTALLATION This will take you to the TruLink Wireless USB to Audio Kit InstallShield Wizard. Click “Next” to go to proceed with the install. Read and accept the Wireless USB software License Agreement by clicking “Yes”.
  • Page 11 OFTWARE EVICE NSTALLATION After the software installs, your installation is complete and you can hit the “Finish” button to exit the wizard. Important: reboot/restart if prompted.
  • Page 12 OFTWARE EVICE NSTALLATION ONNECT IRELESS UDIO EVICE DAPTER 1. Connect one of the included dipole antennas to the Wireless Audio Device Adapter. 2. Connect the Wireless Audio Device Adapter 3.5mm Stereo Audio Input to your PC audio speakers, sound system, projector or television using the appropriate cable or adapter types. Plug in the power adapter to the Wireless Audio Device Adapter and opposite end into an AC outlet.
  • Page 13 OFTWARE EVICE NSTALLATION 3 -D USB H RIVER NSTALLATION FOR THE IRELESS DAPTER Your Wireless USB to Audio Kit has been pre-associated for you, meaning the Wireless USB Host Adapter will automatically recognize the Wireless Audio Device Adapter upon being powered and its successful driver installation.
  • Page 14 OFTWARE EVICE NSTALLATION After you connect the Wireless USB Host Adapter to your computer, Windows will automatically install it and you should get a successful install message in your icon tray such as this figure shows. Figure: Successful Install Message...
  • Page 15 Activity Indicators will light up on the devices. The TruLink DisplayLink Manager utility (Figure: TruLink DisplayLink Manager) will activate and install an icon in the Windows icon tray. The TruLink Wireless USB to Audio Kit is now fully functional and you are ready to use it.

  • Page 16: Using The Wireless Usb To Audio Kit

    SING THE IRELESS UDIO Wireless USB Manager The Wireless USB Manager is simple and easy to use interface to manage your Wireless USB devices and control your Wireless USB Host Adapter settings. The Wireless USB Manager can be accessed via Wireless USB Manager Icon in the Windows tray (Figure: Wireless USB Manager Icon).
  • Page 17 SING THE IRELESS UDIO The V menu will give the option of what type of devices you wish to display (All Devices, Connected Devices and Not Connected Devices). The O menu will give the option to launch Host Settings window and turn the Wireless USB Host PTIONS Adapter radio on or off.
  • Page 18 SING THE IRELESS UDIO To manage the Wireless USB Host Adapter settings, either select “Host Settings” in the “Option” menu of the Wireless USB Manager application or right click on the Wireless USB Manager icon in the Windows tray. (Figure: Host Settings – General) ENERAL TAB 1.
  • Page 19 SING THE IRELESS UDIO (Figure: Host Settings – Advanced) DVANCED TAB 1. Channel selection: this function allows you to set manually a radio channel for the wireless communication (combination of Band Group and Channel). For optimal performance, the automatic setting is recommended. Figure: Host Settings - Advanced...

  • Page 20: Frequently Asked Questions

    REQUENTLY SKED UESTIONS My Wireless USB Host Adapter is plugged into my computer and my Wireless Audio Device Adapter is powered but I do not hear anything out of my speakers. What’s wrong? Check the Wireless USB Manager to see if there is an icon for your Wireless Audio Device Adapter. If there is no icon, try unplugging and then plugging in your Wireless USB Host Adapter to reload the Wireless Audio Device Adapter.

  • Page 21: Technical Specifications

    ECHNICAL PECIFICATIONS Systems Information Operating System Support: Microsoft XP 32-bit; Microsoft Vista 32-bit/64-bit Operating Range: Up to 30 feet (10 meters) PHY Data Rate: 53.3Mbps, 80Mbps, 106.6Mbps, 160Mbps,200Mbps, 320Mbps, 400Mbps, 480Mbps Frequency: 3.1GHz to 4.8GHz (WiMedia Band Group 1) RF Modulation Type: QPSK/DCM Number of Channels: 7 Channels (3 FFI + 4 TFI) USB Specification: Certified Wireless USB 1.0...

  • Page 22: Cables To Go Warranty

    ™ W ABLES ARRANTY TATEMENT At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device.

  • Page 23: Important Safety Information

    MPORTANT AFETY NFORMATION ! Do not plug the unit in any outlet that does not have enough current to allow the device to function. Refer to the specifications in this manual for power level of the unit. ! Liquid: If this unit or its corresponding power adapter has had liquid spilled on or in it, do not attempt to use the unit. Do not attempt to use this product in an outdoor environment as elements such as rain, snow, hail, etc.

  • Page 24: Appendix

    SSOCIATION ROCESS If you purchase additional Certified Wireless USB host adapters, such as the TruLink Wireless USB Host Adapter (part #29578), you will need to associate them with your Wireless Audio Device Adapter. Refer to your Wireless USB device documentation for more information on its settings for association or try...

  • Page 25: Cable Association Procedure

    Cable association steps. Examples/Figures shown are used with the association of the TruLink Wireless Audio Device Adapter (Part # 29595) when used with the TruLink Wireless USB Host Adapter (part #29578). This process will vary by manufacturer of your Wireless USB host adapter.
  • Page 26 Associated Certified Wireless USB Devices will appear as icons in the Wireless USB Manager. When the Wireless USB devices are connected, the icon will appear in color (Figure: TruLink Wireless Audio Device Adapter Connected). Figure: TruLink Wireless Audio Device Adapter...

  • Page 27: Pin Association Procedure

    PIN association steps: Examples/Figures shown are used with the association of the TruLink Wireless Audio Device Adapter (Part # 29595) when used with the TruLink Wireless USB Host Adapter (part # 29578). This process will vary by manufacturer of your Wireless USB host adapter.
  • Page 28 PPENDIX 2. The Wireless USB Host Adapter will search for the Wireless Audio Device Adapter within its range. Note that this operation can take up to 20 seconds (Figure: Discovery Mode in Process). Figure: Discovery Mode in Process 3. Once the Wireless USB Host Adapter and the Wireless Audio Device Adapter have exchanged security information, the following dialog will appear.

  • Page 29: Pin Change Procedure

    PPENDIX 4. Enter the PIN of the Wireless Audio Device Adapter (4-digit PIN) and click Accept Association (Note: the default PIN is “1234”). The Wireless Audio Device Adapter and Wireless USB Host Adapter are now associated and ready for operation. HANGE ROCEDURE The default PIN setting for the Wireless Audio Device Adapter is “1234”.
  • Page 30 PPENDIX While the program is searching for the device, connect the USB cable between your Wireless Audio Device Adapter and any available USB port on your computer.
  • Page 31 PPENDIX 4. Click Install this driver software anyway. 5. To change pin, click “Change PIN”...
  • Page 32 6. If your PIN is valid, a window displaying your new PIN will appear. Press OK. Your PIN has been successfully changed. IMPORTANT: please exit the Trulink PIN Utility application (Exit button as shown on figure in step 5) before unplugging the USB cable between your Wireless Audio Device...
  • Page 34 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.cablestogo.com . 1.0.6.30.09...
