TRUlink 30535 User Manual

Usb 2.0 to dvi-i adapter
Hide thumbs Also See for 30535:
Table of Contents

Advertisement

Quick Links

Download this manual
U
G
SER
UIDE
USB 2.0
DVI-I A
TO
DAPTER
Model: 30535
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30535 and is the answer not in the manual?

Questions and answers

Related Manuals for TRUlink 30535

Summary of Contents for TRUlink 30535

  • Page 1 UIDE USB 2.0 DVI-I A DAPTER Model: 30535...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS Introduction..............................2 Features..............................3 System Requirements..........................4 Package Contents............................5 Device Overview............................6 Device Driver Installation on Windows 2000/XP Device Installation on Windows 2000/XP..................7 Verifying Device Driver on Windows 2000/XP.................19 Device Driver Un-Installation on Windows 2000/XP................21 Device Driver Installation on Windows Vista Device Installation on Windows Vista....................23 Verifying Device Driver on Windows Vista..................29 Device Driver Un-Installation on Windows Vista................31...

  • Page 3: Introduction

    NTRODUCTION Thank you for purchasing the USB 2.0 to DVI-I Adapter. This product will allow you to easily expand your PC’s display capabilities via an available USB port. No need to open your computer case or install a special graphics card – this cable-based adapter uses a simple connection to provide support for a secondary monitor.

  • Page 4: Features

    EATURES Supports display resolutions up to VGA: 1920 x 1200 / DVI: 1600 x 1200 Supports the multiple display devices on one PC Multi graphics display modes – Primary, Extended, Mirror and Rotation USB 2.0 compliant and Plug-and-Play USB connectivity VGA and DVI outputs compliant...

  • Page 5: System Requirements

    YSTEM EQUIREMENTS Pentium 4 / Celeron Family, AMD K6 / Athlon / Duron Family. 1.0GHz or higher processor Single Display Setup: 256MB RAM or higher; Multi-Display Setup: 512MB RAM or higher-(Higher memory recommended for optimal performance) Available USB 2.0 port Windows 2000 SP4 / Windows XP SP2 / Windows Vista...

  • Page 6: Package Contents

    ACKAGE ONTENTS USB 2.0 to DVI-I Adapter USB 2.0 cable DVI to VGA adapter (for VGA capable displays) CD (User Manual, Driver and Utility) Quick Installation Guide...

  • Page 7: Device Overview

    EVICE VERVIEW DVI-I Female Port Power LED Indicator USB Mini-B Port DVI to VGA Adapter...

  • Page 8: Device Installation On Windows 2000/Xp

    ® 2000/XP EVICE NSTALLATION ON INDOWS Please note the following information before installation: Do not plug the USB 2.0 to DVI-I Adapter to your PC or Notebook while executing the set-up or un- installation program. The AC power adapter is required for the external USB Hub. Please note that the driver allows up to 6 USB 2.0 to DVI-I Adapters on one PC.
  • Page 9 ® 2000/XP EVICE NSTALLATION ON INDOWS Step 1 Insert the Driver CD into the CD-ROM drive; the setup program should be launched automatically. If setup program does not begin automatically, click Start, Run and double click “D:\Setup.exe” (where D: is the path of your CD-ROM drive).
  • Page 10 ® 2000/XP EVICE NSTALLATION ON INDOWS Step 3 License Agreement; please read it and select “I accept the terms of the license agreement.” Click “Next” to accept the License Agreement. Step 4 The Microsoft Software Installation Certificate warning dialogue box will be displayed on Windows XP several times.
  • Page 11 ® 2000/XP EVICE NSTALLATION ON INDOWS Step 5 Click “Finish” to exit the Driver Wizard. Step 6 Select “Yes, I want to restart my computer now” and click “Finish” to complete the driver installation. Note: If you are installing multiple USB 2.0 to DVI Adapters select No, I will restart my computer later at this step and refer to page 14 of this manual for further instructions.
  • Page 12 ® 2000/XP EVICE NSTALLATION ON INDOWS Step 7 Connect the external display device (monitor/projector) to the DVI connector of USB 2.0 to DVI-I Adapter and switch it on. Then plug the USB 2.0 to DVI-I Adapter into an available USB 2.0 port of your PC or Notebook.
  • Page 13 ® 2000/XP EVICE NSTALLATION ON INDOWS Step 7 It will show the Hardware Installation Wizard, please select “No, not this time” and click “Next” to continue. Step 8 Select “Install the software automatically (Recommended)”. Click “Next” to continue.
  • Page 14 ® 2000/XP EVICE NSTALLATION ON INDOWS Step 9 Please select “Continue Anyway” to continue with the device driver installation (this may appear several times). This will not affect the device driver installation and the device usage. Step 10 Click “Finish” to exit the Hardware Wizard of the USB 2.0 to DVI-I Adapter and you are now ready to use the product.
  • Page 15 ® 2000/XP EVICE NSTALLATION ON INDOWS Step 11b. USB 2.0 DVI-I A NSTALLATION OF ULTIPLE DAPTERS a. Please select “No, I will restart my computer later.” and click “Finish” to continue the installation of next USB 2.0 to DVI-I Adapter.
  • Page 16 ® 2000/XP EVICE NSTALLATION ON INDOWS b. Connect another display device to the DVI connector of the next USB 2.0 to DVI-I Adapter and switch it on. Then plug the USB 2.0 to DVI-I Adapter into next available USB 2.0 port of your PC or Notebook. c.
  • Page 17 ® 2000/XP EVICE NSTALLATION ON INDOWS d. Select “Install the software automatically (Recommended) and click “Next” to continue. e. Please select “Continue Anyway” to continue with the device driver installation. It will not affect the device driver installation and the device usage.
  • Page 18 ® 2000/XP EVICE NSTALLATION ON INDOWS f. Click “Finish” to exit the Hardware Wizard of the 2 2.0 to DVI-I Adapter. g. If you wish to install additional USB 2.0 to DVI-I Adapter, please follow the procedure of a~ f again.
  • Page 19 ® 2000/XP EVICE NSTALLATION ON INDOWS h. Otherwise, please select “Yes, I want to restart my computer now.” and click “Finish” to complete the driver installation. After you reboot the computer, the extended display will be shown on the display device.

  • Page 20: Verifying Device Driver On Windows 2000/Xp

    ® 2000/XP ERIFYING EVICE RIVER NSTALLATION ON INDOWS The following procedure allows you to verify the device driver installation. Right click “My Computer” → “Properties” → “Hardware” → “Device Manager”. Double click “Display adapters”, and “Universal Serial Bus controllers”. USB 2.0 DVI-I A INGLE DAPTER...
  • Page 21 ® 2000/XP ERIFYING EVICE RIVER NSTALLATION ON INDOWS USB 2.0 DVI-I A ULTIPLE DAPTER NSTALLATION ON THE COMPUTER...

  • Page 22: Device Driver Un-Installation On Windows 2000/Xp

    ® 2000/XP EVICE RIVER NSTALLATION ON INDOWS Please make sure the USB 2.0 to DVI-I Adapter is unplugged from your PC or Notebook before executing the device driver un-installation program. Step 1 Start menu: Click “Start” → “Control Panel” → “Add or Remove Programs”.
  • Page 23 ® 2000/XP EVICE RIVER NSTALLATION ON INDOWS Step 2 Unplug the USB 2.0 to DVI-I Adapter and click “OK” to continue. Step 3 Select “Yes, I want to restart my computer now” and click “Finish” to reboot. After reboot, you will complete the driver un-installation.

  • Page 24: Device Installation On Windows Vista

    ® V ® EVICE NSTALLATION ON INDOWS ISTA Please note the following information before installation: Do not plug the USB 2.0 to DVI-I Adapter to your PC or Notebook while executing the set-up or un- installation program. The AC power adapter is required for the external USB Hub. Please note that the driver allows up to 6 USB 2.0 to DVI-I Adapters on one PC.
  • Page 25 ® V ® EVICE NSTALLATION ON INDOWS ISTA Step 1 Insert the Driver CD into the CD-ROM drive; the setup program should be launched automatically. If setup program does not begin automatically, click Start, Run and double click “D:\Setup.exe” (where D: is the path of your CD-ROM drive).
  • Page 26 ® V ® EVICE NSTALLATION ON INDOWS ISTA Step 3 License Agreement; please review it and check “I accept the terms of the license agreement.” Click “Next” to accept the License Agreement. Step 4 Windows Security warning dialogue box under Windows Vista, it will not affect the device driver installation and usage the device.
  • Page 27 ® V ® EVICE NSTALLATION ON INDOWS ISTA Setup is searching for installed features… Step 5 Click “Finish” to exit the Driver Wizard.
  • Page 28 ® V ® EVICE NSTALLATION ON INDOWS ISTA Step 6 USB 2.0 DVI-I A NSTALLATION OF INGLE DAPTER Please select “Yes, I want to restart my computer now.” and click “Finish” to complete the driver installation. Note: If you wish to install additional USB 2.0 to DVI Adapters, select No, I will restart my computer later, and refer to Step 8 on the next page.
  • Page 29 ® V ® EVICE NSTALLATION ON INDOWS ISTA Step 8 (optional) USB 2.0 DVI-I A NSTALLATION OF ULTIPLE DAPTERS a. Please select “No, I will restart my computer later.” And click “Finish” to continue the next installation. b. Connect another external display device to the DVI connector of next USB 2.0 to DVI-I Adapter and switch it c.

  • Page 30: Verifying Device Driver On Windows Vista

    ® V ® ERIFYING EVICE NSTALLATION ON INDOWS ISTA The following procedure allows you to verify the device driver installation. Right click “Computer” → “Properties” → “Device Manager”. Double click “Display adapters”, and “Universal Serial Bus controllers”.
  • Page 31 ® V ® ERIFYING EVICE NSTALLATION ON INDOWS ISTA...

  • Page 32: Device Driver Un-Installation On Windows Vista

    ® V ® EVICE RIVER NSTALLATION ON INDOWS ISTA Please make sure the USB 2.0 to DVI-I Adapter is unplugged to your PC or notebook before executing the device driver un-installation program. Step 1 Start menu: Please click “Start” → “Control Panel”...
  • Page 33 ® V ® EVICE RIVER NSTALLATION ON INDOWS ISTA Step 3 Select “Yes, I want to restart my computer now” and click “Finish” to reboot. After reboot, you will complete the driver un- installation.

  • Page 34: Function Description

    UNCTION ESCRIPTION This section describes the main functions provided by the USB 2.0 to DVI-I Adapter. - It can support a LCD or CRT monitor, and it supports four kinds of selections, Primary, Extended, Mirror and Rotate by “UD” icon.
  • Page 35 UNCTION ESCRIPTION - The resolution supports from 800x600 x16 bit and up-to 1920x1200 x16 bit. - The resolution can be modified via the system tray or Display Properties.
  • Page 36 UNCTION ESCRIPTION “Primary” Mode The system’s main graphics adapter will automatically switch to act as the secondary graphics adapter and the main screen will now work as the extended desktop. The monitor connected to the USB 2.0 to DVI-I Adapter will now act as the primary Windows desktop. Please be advised that some display utility and drivers that shipped with certain AGP and built-in display adapters may prevent this option from working on some systems.
  • Page 37 UNCTION ESCRIPTION “Extended” Mode (Default) By default, the monitor connected to USB 2.0 to DVI-I Adapter will work as, “Extended Desktop” which extends the primary Windows desktop of your system. You can change the relative position of this extended desktop under the Display Properties.
  • Page 38 UNCTION ESCRIPTION “Mirror” Mode By setting this mode, the Windows desktop will be mirrored/replicated to the secondary CRT/LCD monitor. The screen resolution setting on the secondary monitor will follow the primary screen’s resolution. For example, if the primary resolution is 1024x768x32bit, and the secondary monitor’s resolution will be the same.
  • Page 39 UNCTION ESCRIPTION “OFF” Mode This option disables the USB 2.0 to DVI-I Adapter on the system.

  • Page 40: Supported Common Display Resolution

    UPPORTED OMMON ISPLAY ESOLUTION Aspect Ratio Resolution 16:10 1920 * 1200 16:9 1920 * 1080 16:10 1680 * 1050 16, 32 16, 32 16:10 1440 * 900 16, 32 16, 32 16:10 1280 * 800 16, 32 16, 32 15:9 1280 * 768 16, 32 16, 32...

  • Page 41: Technical Specifications

    ECHNICAL PECIFICATIONS Operating System Windows 2000/XP/Vista PCB Version UDA200 Version:1.1 USB 2.0 Cable Length: 100± 5 cm, ( mini B-A type) DVI connector DVI-I (DVI Digital & Analog) Dual Link ( female) Case Material Power Source Bus Powered Monitor Refresh Frequency 60, 70, 75 &...

  • Page 42: Questions & Answers

    & A UESTIONS NSWERS This section describes the common Q&A regarding to the installation or operation of the USB 2.0 to DVI-I Adapter. Q: Why can’t I make the USB 2.0 DVI-I Adapter the primary display? A: Some video cards ship their product with a utility that prevent other video cards from being set as the primary card. Check the bottom right hand corner taskbar for the utility.

  • Page 43: Troubleshooting Tips

    ROUBLESHOOTING The following troubleshooting tips may help if you are experiencing any difficulties using our device. - Check to make sure that all connectors are plugged in correctly. - Make sure that the USB port that you are using is USB 2.0. - Try a different USB 2.0 port and/or computer - Check to see that the monitor is connected correctly and the power is ON.

  • Page 44: Regulatory Compliance

    EGULATORY OMPLIANCE This equipment has been tested and found to comply with FCC rules Part 15 Subpart B § 15.109/15.107 Class B. Operation is subject to the following two conditions: • This device may not cause harmful interference • This device must accept any interference received, including interference that may cause undesired operation.

  • Page 45: Cables To Go One Year Warranty

    ™ O ABLES ARRANTY At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device.

  • Page 46: Important Safety Information

    MPORTANT AFETY NFORMATION ! Do not plug the unit in any outlet that does not have enough current to allow the switch to function. Refer to the specifications in this manual for power level of the unit. ! Liquid: If this unit or its corresponding power adapter has had liquid spilled on or in it, do not attempt to use the unit. Do not attempt to use this product in an outdoor environment as elements such as rain, snow, hail, etc.
  • Page 48 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.cablestogo.com . 1.0.4.9.09...
