- Page 1 UICK TART UIDE VGA A IRELESS DAPTER Model: 81657...
- Page 2 NTRODUCTION Thank you for purchasing the TruLink™ Wireless USB To VGA Adapter Kit. This Quick Start Guide will assist you in setting up your unit properly. For instructions on adjusting settings and product specification information, please refer to the User Guide which is included in the package. We...
- Page 3 EATURES Supports high resolution UXGA video of 1600 x 1200 at distances up to 10 metres Works in both extended desktop and mirror screen modes Supports native mode for playback of high resolution video Up to six computers can share one wireless display ...
- Page 4 YSTEM EQUIREMENTS Microsoft® Windows® XP 32-bit with Service Pack 3 or higher or Microsoft® Vista® 32-bit/64-bit VGA cable to connect from the Wireless VGA Device Adapter to your display device...
-
Page 5: Package Contents
ACKAGE ONTENTS Wireless USB Host Adapter for your computer Wireless VGA Device Adapter for your display Two (2) Dipole Antennae (one for each adapter) 1 m USB A Male/Mini-B Male Cable USB Extender with Cradle ... -
Page 6: Device Overview
EVICE VERVIEW USB H IRELESS DAPTER Link: Data Connection Indicator LED is solid when transfer device is connected. LED blinks when data is being transferred. PWR: Power LED is solid when powered by the PC. -
Page 7: Wireless Vga Device Adapter
EVICE VERVIEW VGA D IRELESS EVICE DAPTER VGA : VGA Activity Indicator LED is solid when display cable is connected. LED blinks when data is being transferred. PWR: Power Indicator LED is solid when power is applied. 3. -
Page 8: Software /Device Installation
OFTWARE EVICE NSTALLATION IMPORTANT NOTE: If installing on Windows XP, Service Pack 3 (SP3) is required. Verify that this has been installed before installing the Wireless USB To VGA Adapter Kit software. Before installing the software, make sure that the Wireless USB Host Adapter and the Wireless VGA Device Adapter are not connected to the computer and the Wireless VGA Device Adapter is switched on. - Page 9 OFTWARE EVICE NSTALLATION 2 -D USB H RIVER NSTALLATION FOR THE IRELESS DAPTER Your Wireless USB to VGA Adapter Kit has been pre-associated for you, meaning the Wireless USB Host Adapter will automatically recognise the Wireless VGA Device Adapter upon being switched on. After software installation, you should see the Wireless USB Manager icon in your Windows icon tray.
- Page 10 OFTWARE EVICE NSTALLATION After you connect the Host Adapter to your computer, Windows will automatically install the Wireless USB Host Adapter and you should get a successful install message in your icon tray as shown in the below figure. Figure: Successful Install Message...
-
Page 11: Device Installation
OFTWARE EVICE NSTALLATION 3 – D VGA D EVICE NSTALLATION FOR THE IRELESS EVICE DAPTER 1. Connect the other dipole antenna to the Wireless VGA Device Adapter. Switch your display device on (i.e. monitor, projector, television). Using a VGA cable, connect the Wireless VGA Device Adapter to your display device, and then plug in the power adapter to the Wireless VGA Device Adapter. - Page 12 After the Activity Indicators come on, the TruLink DisplayLink Manager utility will activate and install an icon in the Windows icon tray. Your TruLink Wireless USB To VGA Adapter Kit is now fully functional and you are ready to use it.
- Page 14 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.c2g.com . 2.1.04.02.12...
