TRUlink 29573 User Manual

Wireless vga device adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

U
G
SER
UIDE
W
VGA D
A
IRELESS
EVICE
DAPTER
Model: 29573
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 29573 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRUlink 29573

Summary of Contents for TRUlink 29573

  • Page 1 UIDE VGA D IRELESS EVICE DAPTER Model: 29573...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS Introduction..............................2 Features..............................3 System Requirements..........................4 Package Contents............................5 Device Overview............................6 Software/Device Installation........................7 Using the Wireless VGA Device Adapter....................14 Frequently Asked Questions........................19 Video Playback Tips..........................21 Technical Specifications..........................22 Cables To Go One Year Warranty......................23 Important Safety Information........................24 Appendix Association with other devices......................25 Cable Association Procedure......................26 PIN Association Procedure......................28 PIN Change Procedure........................30...

  • Page 3: Introduction

    NTRODUCTION Thank you for purchasing the TruLink™ Wireless VGA Device Adapter. This product utilizes the latest in wireless technology, so you can display video and images from a PC on a remote monitor, projector, or television up to 30 feet away through the use of a compatible Wireless USB host adapter (sold separately).

  • Page 4: Features

    EATURES Supports high resolution UXGA video of 1600x1200 at distances up to 30ft Works in both extended desktop and dual monitor/clone screen modes Supports native mode for playback of high resolution video Supports video streaming at up to 720p Based on Ultra Wide Band technology, providing low power consumption Certified Wireless USB 1.0 compliant...

  • Page 5: System Requirements

    YSTEM EQUIREMENTS Microsoft® Windows® XP 32-bit with Service Pack 3 or higher Microsoft® Vista® 32-bit/64-bit Microsoft Windows 7 32-bit/64-bit VGA cable to connect from the Wireless VGA Device Adapter to your display device Minimum Requirements (Office, Productivity, and Web applications) Windows XP- Processor: 1.66GHz Atom or Celeron Ram: 512MB...

  • Page 6: Package Contents

    ACKAGE ONTENTS Wireless VGA Device Adapter One (1) Dipole Antenna 3ft USB A Male/Mini-B Male Cable One (1) Power Adapter (cord approx. 4ft) Pin-Association Stickers Quick Start Guide Driver CD w/Electronic User Guide...

  • Page 7: Device Overview

    EVICE VERVIEW VGA D IRELESS EVICE DAPTER 1. VGA : VGA Activity Indicator • LED is solid when display cable is connected. • LED is blinking when data is being transferred. 2. PWR: Power Indicator • LED is solid when power is applied. 3.

  • Page 8: Software/Device Installation

    OFTWARE EVICE NSTALLATION IMPORTANT NOTE: • If installing on Windows XP, Service Pack 3 (SP3) is required. Verify that this has been installed before installing the Wireless VGA Device Adapter software. • Before installing the software, if using a Wireless USB host adapter make sure that it and the Wireless VGA Device Adapter are not connected to the computer and the Wireless VGA Device Adapter is not powered.
  • Page 9 OFTWARE EVICE NSTALLATION This will take you to the TruLink Wireless USB Kit InstallShield Wizard. Click “Next” to go to proceed with the install. Read and accept the Wireless USB software License Agreement by clicking “Yes”.
  • Page 10 OFTWARE EVICE NSTALLATION Read and accept the License Agreement for the DisplayLink software. After the software installs, your installation is complete and you can hit the “Finish” button to exit the wizard. Important: reboot/restart if prompted.
  • Page 11 OFTWARE EVICE NSTALLATION 2 (I USB H F NECESSARY RIVER NSTALLATION FOR THE IRELESS DAPTER SOLD SEPARATELY 1. Install your Wireless USB host adapter if you have not already done so. Please refer to your Wireless USB host adapter instructional guide or you may try to contact the manufacturer for the proper driver installation process.
  • Page 12 EVICE DAPTER The TruLink Wireless VGA Device Adapter supports two association methods: Cable Association and Pin Association. Only one of these methods is necessary to complete installation. The instructions below describe steps for both methods, and how to use this adapter in Wired Mode. Please note that Pin Association is only recommended if using with a TruLink Wireless USB Host Adapter.
  • Page 13 NSTALLATION SSOCIATION For Pin Association, it is strongly recommended that you use a TruLink Wireless USB Host Adapter, as some other Wireless USB host adapters may not support the feature. To pin associate with the TruLink Wireless USB Host Adapter, please do the following: 1.
  • Page 14 3. If prompted to Accept Association, please do so, and then disconnect the USB cable. The function is the same as the wireless mode but data will be transferred through the USB cable and not use the Wireless USB host adapter. You are now ready to use your TruLink Wireless VGA Device Adapter.

  • Page 15: Using The Wireless Vga Device Adapter

    ISPLAY ETTINGS The TruLink Wireless VGA Device Adapter hosts a number of various settings so that you may configure your image to the way you need it. After you have properly installed the USB to VGA Adapter, an icon representing a monitor will appear in your Windows icon tray.
  • Page 16 VGA D SING THE IRELESS EVICE DAPTER NOTE: By default, your monitor will be set for the best resolution and will extend your screen to the right. Figure: Display Settings Menu...
  • Page 17 VGA D SING THE IRELESS EVICE DAPTER ESCRIPTIONS Screen Resolution This allows adjustment for your video’s display capable screen resolutions. Please note that if all the options appear from the range of 640x480~1680x1050, your monitor will most likely only accept what its maximum capability is.
  • Page 18 Your Wireless USB host adapter/s will have to go through the association process before they can be used with the TruLink Wireless VGA Device Adapter. For more information about the association process, please refer to Appendix – Association with other devices.
  • Page 19 VGA D SING THE IRELESS EVICE DAPTER USB H IRELESS DAPTER ESET To erase all Wireless USB host adapters associated to your Wireless VGA Device Adapter, hold down the “RESET” button for 10 seconds. This will cause the Wireless VGA Device Adapter to erase all Wireless USB host adapters that have been associated from its list.

  • Page 20: Frequently Asked Questions

    Manager appear in color when it is connected. Still not connected? Try adjusting the resolution from the TruLink DisplayLink manager. Some displays such as television type displays can be recognized as a default monitor and therefore your PC may set it as a default 1280x1024 which can be too high for the monitor.
  • Page 21 REQUENTLY SKED UESTIONS Why is my video choppy? If you are experiencing choppy video, try changing the channel (please refer to your Wireless USB host adapter settings for this) or move in your computer closer to the display. I see a blue screen or my desktop background on my display connected with the Wireless VGA Device Adapter, but no icons.

  • Page 22: Video Playback Tips

    IDEO LAYBACK We only recommend playing back video in “Extend” mode. Don’t switch between “Mirror” and “Extended” modes while video is being played on the wireless display. Doing this can confuse the video player which may cause it to stop its playback. We recommend stopping playback, and then switching viewing modes if needed.

  • Page 23: Technical Specifications

    ECHNICAL PECIFICATIONS Operating System Support Microsoft XP 32-bit; Microsoft Vista 32-bit/64-bit; Windows 7 32-bit/64-bit Operating Range Up to 30 feet (10 meters) PHY Data Rate 53.3Mbps, 80Mbps, 106.6Mbps, 160Mbps, 200Mbps, 320Mbps, 400Mbps, 480Mbps Frequency 3.1GHz to 4.8GHz (WiMedia Band Group 1) RF Modulation Type QPSK/DCM Interface...

  • Page 24: Cables To Go One Year Warranty

    ™ W ABLES ARRANTY TATEMENT At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device.

  • Page 25: Important Safety Information

    MPORTANT AFETY NFORMATION ! Do not plug the unit in any outlet that does not have enough current to allow the device to function. Refer to the specifications in this manual for power level of the unit. ! Liquid: If this unit or its corresponding power adapter has had liquid spilled on or in it, do not attempt to use the unit. Do not attempt to use this product in an outdoor environment as elements such as rain, snow, hail, etc.

  • Page 26: Appendix

    SSOCIATION ROCESS If you purchase additional Certified Wireless USB Host Adapters, such as the TruLink Wireless USB Host Adapter, you will need to associate them with your Wireless VGA Device Adapter. Refer to your Wireless USB device documentation for more information on its settings for association or try contacting the...

  • Page 27: Cable Association Procedure

    ROCEDURE Cable association steps: Examples/Figures shown used with the association of the TruLink Wireless VGA Device Adapter when used with the TruLink Wireless USB Host Adapter. This process will vary by manufacturer of your Wireless USB host adapter. 1. Make sure that the Wireless USB host adapter utility is running. Check your Windows tray for the Wireless USB Manager icon (Figure: Wireless USB Manager).
  • Page 28 (Figure: Wireless VGA Adapter and TruLink Hub Connected). Figure: Wireless VGA Adapter and TruLink Hub Connected Note: You may rename or delete the Wireless USB Device by right-clicking the device icon in the Wireless USB Manager and select “rename” or “delete”.

  • Page 29: Pin Association Procedure

    PPENDIX SSOCIATION ROCEDURE PIN association steps: Examples/Figures shown used with the association of the TruLink Wireless VGA Device Adapter when used with the TruLink Wireless USB Host Adapter. 1. Make sure your Wireless VGA Device Adapter is powered on and your Wireless USB host adapter is connected to your computer.
  • Page 30 PPENDIX 2. The Wireless USB host will search for the Wireless VGA Device Adapter within its range. Note that this operation can take up to 20 seconds (Figure: Discovery Mode in Process). Figure: Discovery Mode in Process 3. Once the Wireless USB host adapter and the Wireless VGA Device Adapter have exchanged security information, the following dialog will appear.

  • Page 31: Pin Change Procedure

    PPENDIX 4. Enter the PIN of the Wireless VGA Adapter (4-digit PIN) and click Accept Association. The Wireless VGA Adapter and Wireless USB Host Adapter are now associated and ready for operation. HANGE ROCEDURE The default PIN setting for the Wireless VGA Device Adapter is “1234”. This section gives you the instructions to change the PIN to another 4-Digit value.
  • Page 32 PPENDIX Make sure the WIRELESS/WIRED switch on your Wireless VGA Adapter is in the WIRELESS position and the power cable is plugged in your Wireless VGA Adapter. Connect the USB cable between your Wireless VGA Adapter and any available USB port on your computer.
  • Page 33 PPENDIX 4. Click Install this driver software anyway. 5. To change pin, click “Change PIN”...
  • Page 34 7. If your PIN is valid, a window displaying your new PIN will appear. Press OK. Your PIN has been successfully changed. IMPORTANT: please exit the Trulink PIN Utility application (Exit button as shown on figure in step 5) before unplugging the USB cable between your Wireless VGA Adapter and...
  • Page 36 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.cablestogo.com . 1.0.2.8.10...
