- Page 1 UIDE USB H IRELESS UB AND DAPTER USB D IRELESS EVICE DAPTER Model: 29570 (4-port Hub) /29571 (1-port Device Adapter)
-
Page 2: Table Of Contents
ABLE OF ONTENTS Introduction..............................2 Features..............................3 System Requirements..........................4 Package Contents............................5 Device Overview Wireless USB Adapter........................6 Wireless USB Hub..........................7 Wireless USB Device Adapter......................8 Software/Device Installation........................9 Using the Wireless USB Kit........................16 Technical Specifications..........................21 Cables To Go One Year Warranty......................22 Important Safety Information........................23 FCC Statement............................24 Appendix Cable association with other devices....................25 Cable Association Procedure......................26... -
Page 3: Introduction
NTRODUCTION Thank you for purchasing the TruLink™ Wireless USB Hub and Adapter Kit. This product utilizes the latest in wireless technology, so you can connect USB enabled devices such as printers, external hard drives, and digital cameras up to 30 feet away. With a highly secure connection you can use this product in settings such as corporate offices, classrooms, or in your home office/entertainment system. -
Page 4: Features
EATURES Full support for printers, scanners, cameras, MP3 players, external hard drives, and other USB peripherals Access and device-sharing support for as many as three associated computers Certified by the USB-IF, guaranteeing connectivity with all Certified Wireless USB™ products Based on Ultra Wide Band technology, providing speedy data transfer and low power consumption Convenient plug-and-play connectivity, with simple software installation and setup... -
Page 5: System Requirements
YSTEM EQUIREMENTS Microsoft® Windows® XP or Microsoft® Vista® 32-bit... -
Page 6: Package Contents
ACKAGE ONTENTS Wireless USB Host Adapter for your computer Wireless USB Hub for your USB devices Two (2) Dipole Antennas (for USB Adapter and USB Hub) 3ft USB A Male/Mini-B Male Cable USB Extender with Cradle One (1) Power Adapter User Manual Quick Start Guide Driver CD... -
Page 7: Device Overview
EVICE VERVIEW USB H IRELESS DAPTER 1. Link: Data Connection Indicator • LED is solid when transfer device is connected • LED blinks when data is being transferred 2. PWR: Power • LED is solid when powered by the PC... -
Page 8: Wireless Usb Hub
EVICE VERVIEW USB H )-29570 IRELESS PORT 1. PWR: Power Indicator • LED is solid when power is applied 2. 1-2-3-4: USB Status Indicator • Illuminated number/symbol indicates the USB port/s that is currently synced with a USB enabled device 3. -
Page 9: Wireless Usb Device Adapter
EVICE VERVIEW USB D )-29571 IRELESS EVICE DAPTER PORT 1. PWR: Power Indicator • LED is solid when power is applied. 2. PWR plug • Power adapter socket 3. USB A port • Connect a USB enabled device 4. USB (mini-B) connector •... -
Page 10: Software/Device Installation
OFTWARE EVICE NSTALLATION IMPORTANT NOTE: • If installing on Windows XP, Service Pack 2 (SP2) is required. Verify that this has been installed before installing the Wireless USB Hub and Adapter Kit software. • Before installing the software, make sure that the Wireless USB Host Adapter and Wireless USB Hub Adapter are not connected to the computer, and the Wireless USB Hub Adapter is not powered. - Page 11 OFTWARE EVICE NSTALLATION This will take you to the TruLink Wireless USB Kit InstallShield Wizard. Click “Next” to go to proceed with the install. Read and accept the Wireless USB Kit software License Agreement by clicking “Yes”.
- Page 12 “Finish” button to exit the wizard. Important: reboot/restart if prompted. Step 2-Driver Installation for the Wireless USB Host Adapter 1. Open the Wireless USB Manager by double-clicking the icon on the icon tray at the bottom of your desktop. Figure: TruLink Wireless USB Manager...
- Page 13 OFTWARE EVICE NSTALLATION The Wireless USB Manager will open and instruct you on what to do next. Figure: Getting Started Screen 2. Make sure the antenna is connected to the Wireless USB Host Adapter. 3. Plug the Wireless USB Host Adapter into any available USB port on your computer. You also have the option to connect the Wireless USB Host Adapter to the USB Cradle provided in the package if you need to make the Adapter more mobile.
- Page 14 Successful Install message pop-up such as the following to let you know it was successful. Figure: Successful Install Message In the Wireless USB Manager, the TruLink Hub icon will appear in grey letting you know it is ready for connection.
- Page 15 Successful Install Message pop-up such as on page 13 verifying successful installation. On the Devices screen of the Wireless USB Manager, the TruLink Hub icon will be in color, indicating the Wireless USB Hub and Adapter Kit is active and ready Display: All Devices to use.
- Page 16 OFTWARE EVICE NSTALLATION You can now connect your USB enabled devices to the Wireless USB Hub (1-port as shown below) just as you would to your computer. Your devices will follow the same plug and unplug process so you may need to first eject your USB device from your PC before unplugging it from the Wireless USB Hub if you need to unplug it for any reason.
-
Page 17: Using The Wireless Usb Kit
USB K SING THE IRELESS USB M IRELESS ANAGER The Wireless USB Manager is simple and easy to use interface to manage your Wireless USB devices and control your Wireless USB Host Adapter settings. The Wireless USB Manager can be accessed via Wireless USB Manager Icon in the Windows tray (Figure: Wireless USB Manager Icon). - Page 18 USB K SING THE IRELESS The V menu will give the option of what type of devices you wish to display (All Devices, Connected Devices and Not Connected Devices). The O menu will give the option to launch Host Settings window and turn the Wireless USB Host PTIONS Adapter radio on or off.
- Page 19 USB K SING THE IRELESS To manage the Wireless USB Host Adapter settings, either select “Host Settings” in the “Option” menu of the Wireless USB Manager application or right click on the Wireless USB Manager icon in the Windows tray. (Figure: Host Settings –...
- Page 20 USB K SING THE IRELESS (Figure: Host Settings – Advanced) DVANCED TAB 1. Channel selection: this function allows you to set manually a radio channel for the wireless communication (combination of Band Group and Channel). For optimal performance, the automatic setting is recommended. Figure: Host Settings - Advanced...
- Page 21 USB K SING THE IRELESS USB H SING YOUR IRELESS UB IN WIRED Your Wireless USB Hub can also be used wired mode. Make sure the position of the WIRELESS/WIRED switch is in the WIRED position. Plug the USB cable between your computer and the Wireless USB Hub. The function is the same as the wireless mode but data will be transferred through the cable and not use the Wireless USB Host Adapter.
-
Page 22: Technical Specifications
ECHNICAL PECIFICATIONS Operating System Support Microsoft XP 32-bit; Microsoft Vista 32-bit PHY Data Rate 53.3Mbps, 80Mbps, 106.6Mbps, 160Mbps, 200Mbps, 320Mbps, 400Mbps, 480Mbps Operating Range Up to 30 feet (10 meters) Frequency 3.1GHz to 4.8GHz (WiMedia Band Group 1) Number of Channel 7 channels (3 FFI + 4 TFI) RF Modulation Type QPSK/DCM... -
Page 23: Cables To Go One Year Warranty
™ W ABLES ARRANTY TATEMENT At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device. -
Page 24: Important Safety Information
MPORTANT AFETY NFORMATION ! Do not plug the unit in any outlet that does not have enough current to allow the device to function. Refer to the specifications in this manual for power level of the unit. ! Liquid: If this unit or its corresponding power adapter has had liquid spilled on or in it, do not attempt to use the unit. Do not attempt to use this product in an outdoor environment as elements such as rain, snow, hail, etc. -
Page 25: Fcc Statement
FCC S TATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device is authorized under 47 CFR 15.519 (the FCC Rules and Regulations). -
Page 26: Appendix
PPENDIX ABLE ASSOCIATION WITH OTHER DEVICES SSOCIATION ONCEPT In order to establish a secure wireless connection, both the Wireless USB Host Adapter and the Wireless USB devices must exchange information about each other. This is done via cable or pin association. Note that your Wireless USB kit has been pre-associated for your convenience and the process described below has been done for you. -
Page 27: Cable Association Procedure
ABLE SSOCIATION ROCEDURE Cable association steps: Examples/Figures shown used with the association of the TruLink Wireless USB to VGA Adapter 1. Make sure that the Wireless USB Manager is running. Check your Windows tray for the Wireless USB Manager icon (Figure: Wireless USB Manager). - Page 28 (Figure: Wireless VGA Adapter and TruLink Hub Connected). Figure: Wireless VGA Adapter and TruLink Hub Connected Note: You may rename or delete the Wireless USB Device Adapter by right-clicking the device icon in the...
-
Page 29: Pin Association Procedure
PPENDIX SSOCIATION ROCEDURE Pin association steps: Examples/Figures shown used with the association of the TruLink Wireless USB to VGA Adapter 1. Make sure your Wireless USB Device Adapter is powered on and your Wireless USB Host Adapter is connected to your computer. Click the “Discovery Mode”... - Page 30 PPENDIX 2. The Wireless USB Host will search for any available Wireless VGA Adapter within its range. Note that this operation can take up to 20 seconds (Figure: Discovery Mode in Process). Figure: Discovery Mode in Process 3. Once the Wireless USB Host Adapter and the Wireless VGA Adapter have exchanged security information, the following dialog will appear.
-
Page 31: Pin Change Procedure
PPENDIX 4. Enter the PIN of the Wireless VGA Adapter (4-digit PIN) and click Accept Association. The Wireless VGA Adapter and Wireless USB Host Adapter are now associated and ready for operation. HANGE ROCEDURE The default PIN setting for the Wireless USB Hub is “1234”. This section gives you the instructions to change the PIN to another 4-Digit value. - Page 32 PPENDIX Make sure the WIRELESS/WIRED switch on your Wireless VGA Adapter is in the WIRELESS position and the power cable is plugged in your Wireless VGA Adapter. Connect the USB cable between your Wireless VGA Adapter and any available USB port on your computer.
- Page 33 PPENDIX 4. Click Install this driver software anyway. 5. To change pin, click “Change PIN”...
- Page 34 7. If your PIN is valid, a Window displaying your new PIN will appear. Press OK. Your PIN has been successfully changed. IMPORTANT: please exit the Trulink PIN Utility application (Exit button as shown on figure in step 5) before unplugging the USB cable between your Wireless VGA Adapter and...
- Page 35 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.cablestogo.com . 2.0.4.28.09...
