Do not disconnect the battery if the vehicle has an anti-theft coded radio. If equipped
with an airbag, avoid disconnecting the battery if possible.
I I M M P P O O R R T T A A N N T T ! ! Please read this entire installation guide before beginning the installa-
tion. The installation of this security system requires interfacing with many of the vehi-
cle's systems. Many new vehicles use low-voltage or multiplexed systems which can
be damaged by low resistance testing devices, such as test lights or logic probes. Test
all circuits with a high-quality digital multi-meter before making the connections.
IM M P P O O R R T T A A N N T T ! ! Many airbag systems will display a diagnostic code through their warn-
ing light after they lose power. Disconnecting the battery requires this code to be
erased, a procedure that can require a trip to the dealer.

before beginning the installation:

Check with the customer to determine the integrated LED/Valet switch location.
Remove the domelight fuse. This prevents accidentally draining the battery.
Roll down a window to avoid being locked out of the car.

after the install:

Test all functions. The "Using Your System" section of the Owner's Guide is very
helpful when testing.
When testing, don't forget that this system is equipped with Nuisance Prevention
™
NPC can bypass both instant trigger zones, making them seem to stop working.
Carefully reassemble the under-dash trim panels.
Inspect the engine compartment for tools that may have been left behind.

tools required

This is a general list of tools required to complete the installation of this security sys-
tem in most vehicles. Some vehicles may require additional tools.
Digital multi-meter
Wire cutters/strippers
4
®
Circuitry.
Nutdriver and/or socket set
Panel removal tool
