UVP DigiDoc-It Set Up And Operating Instructions Manual page 8

DigiDoc-It Imaging System
Preview Window with Manual Focus

When satisfied with the previewed image, select Capture in the Camera Control Window
Optional Camera Setup (Image Acquisition)
If operating the camera in automatic mode is not sufficient for the application, try utilizing the manual mode to
gain additional camera control.

To access the camera dial, open the camera cap on top of the hood.

Set the camera mode dial button to M.
Camera set to M

Close and secure the camera cap on the hood.

A new camera window appears with additional options like the one below:
7
