Quick Installation Guide
Package Contents
IMBA-Q454 package includes the following items:
1 x IMBA-Q454 Single Board Computer
2 x Dual RS-232 cable with bracket
6 x SATA cable
1 x Mini Jumper Pack
1 x I/O Shielding
1 x Utility CD
1 x QIG (Quick Installation Guide)
) ,' ( - ! )
IMBA-Q454
Version 1.0
Feb. 12, 2009
©2006 Copyright by IEI Technology corp.
All rights reserved.
.
/
0
* ) '
$
1
Advertisement
Table of Contents
Related Manuals for IEI Technology IMBA-Q454
Summary of Contents for IEI Technology IMBA-Q454
-
Page 1: Quick Installation Guide
IMBA-Q454 Quick Installation Guide Version 1.0 Feb. 12, 2009 Package Contents IMBA-Q454 package includes the following items: 1 x IMBA-Q454 Single Board Computer 2 x Dual RS-232 cable with bracket 6 x SATA cable 1 x Mini Jumper Pack 1 x I/O Shielding... -
Page 2: Specifications
Specifications CPU: Intel® Core ! " # $ % System Chipset: Intel® Q45+ ICH10DO BIOS: AMI BIOS label System memory: 4 x 240pin Dual-Channel DDR2 800/667 MHz SDRAM DIMMs support up to 8GB Ethernet: PCIe interface Intel® 82567LM GbE controller(iAMT 5.0 support) PCIe interface Intel®... -
Page 3: Ordering Information
Please make sure to switch off the ATX power supply prior to disconnect the ATX connector. Incorrect usage may cause permanently damage to the IMBA-Q454. 3) If the IMBA-Q454 fails to boot due to improper usage, please clear the CMOS by disconnect the battery from the connector. -
Page 4: Jumpers Setting And Connectors
Jumpers setting and Connectors LABEL FUNCTION J_CMOS1 CMOS state setting jumper KB_MS1 External PS/2 KB/MS Connector 3IN1_DSUB1 External VGA/COM1/LPT connectors LAN1_USB01 External LAN And USB Connectors LAN2_USB23 AUDIO_CV1 External Audio Connector FP_AUDIO1 Front Audio Connector SPDIF1 Internal SPDIF Connector COM2 ~ 6 Internal Serial Port Connectors (RS-232) JSPI1 Flash SPI ROM connector... - Page 5 J_CMOS1 : Clear CMOS Setup J_CMOS1 DESCRIPTION Keep CMOS Setup (default)* (Normal Operation) Short 2-3 Clear CMOS Setup JTPM1 &JTPM2 : Enable iTPM JTPM1 JTPM2 DESCRIPTION Short Short Enable iTPM (default*) (default*) Short Open Disable iTPM Open Short Open Open FP_AUDIO1 : Front Audio Connector PIN NO.
- Page 6 COM2 ~ COM6 : Internal Serial Port Connectors (RS-232) DESCRIPTION DESCRIPTION DCD# DSR# RTS# CTS# DTR# F_PANEL1 : PWR RST Buttons ' / 2 ¢ ¢ ¢ ¢ £ £ £ £ PIN DESCRIPTION PIN DESCRIPTION Power LED+ Speaker+ Power LED Speaker Power LED- PWRBTN+...
- Page 7 JSPI1 : SPI Flash Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION 3.3V CS0# PCIE_12V1: PCIe Power Source Connector BAT1 : PIN NO. DESCRIPTION Coin battery holder VCC +5V DESCRIPTION BAT+ BAT-(GND) VCC +12V CPU12V1 : CPU POWER Source Connector PIN NO. DESCRIPTION PIN NO.
- Page 8 Board Layout: Jumper and Connector Locations...
