Icom IC-756PROIII Service Manual page 69

[CHASSIS PARTS]
REF. ORDER
DESCRIPTION
NO. NO.
J3 6510001920 Connector 1490R
J5 6510000370 Connector MR-DS
J6 6510000370 Connector MR-DS
W15 8900007152 Cable OPC-699B
EP1 6910000340 Sheet P101 KD
EP2 6910000310 Insulation plate B312D
MF1 2710000630 Fan FBA08T12HC
SP1 2510000760 Speaker SM-77KY0208
MP1 8410002322 1876 heatsink (A)-2
MP2 8110005932 1876 T-cover-2
MP3 8110007101 2178 L-cover-1
MP4 8510012530 2178 A-plate
MP5 8510010730 1876 B-plate
MP6 8510010740 1876 C-plate
MP7 8510010751 1876 D-plate-1
MP8 8930041351 1876 MAIN stand-1
MP9 8930041341 1876 SUB stand-1
MP11 8930002910 Rubber foot (B)
MP12 8930002910 Rubber foot (B)
MP13 8930029730 1413 fan holder
MP15 8930037001 1691 earth plate-1
MP16 8930018520 TR clip (A)
MP17 8930035240 1546 TR-B clip
Screw BiH M3 × 8 ZK
MP20 8810005770
Screw BiH M3 × 8 ZK
MP21 8810005770
Screw PH BT M3 × 8 NI-ZU
MP22 8810008660
Screw PH BT M3 × 8 NI-ZU
MP23 8810008660
Screw PH BT M3 × 8 NI-ZU
MP24 8810008660
Screw PH BT M3 × 8 NI-ZU
MP25 8810008660
Screw PH BT M3 × 8 NI-ZU
MP26 8810008660
Screw PH BT M3 × 8 NI-ZU
MP27 8810008660
Screw PH BT M3 × 8 NI-ZU
MP28 8810008660
Screw PH M3 × 6 ZK
MP29 8810004430
Screw PH M3 × 6 ZK
MP30 8810004430
Screw PH BT M3 × 8 NI-ZU
MP31 8810008660
Screw PH BT M3 × 8 NI-ZU
MP32 8810008660
Screw PH BT M3 × 8 NI-ZU
MP33 8810008660
Screw PH BT M3 × 8 NI-ZU
MP34 8810008660
Screw PH BT M3 × 8 NI-ZU
MP35 8810008660
Screw PH BT M3 × 8 NI-ZU
MP36 8810008660
Screw PH BT M3 × 8 NI-ZU
MP37 8810008660
Screw PH BT M3 × 8 NI-ZU
MP38 8810008660
Screw PH BT M3 × 8 NI-ZU
MP39 8810008660
Screw PH BT M3 × 8 NI-ZU
MP40 8810008660
Hex head bolt M5 ×18 NI (+)
MP41 8810008160
MP42 8830000210 Nut M5 NI BS
MP43 8830000360 Wing nut M5 NI
MP44 8850000150 Flat washer M5 NI BS
MP45 8850000440 Spring washer M5 NI
Setscrew A M3 × 8
MP46 8810003170
Setscrew A M3 × 8
MP47 8810003170
Screw PH M4 ×18
MP48 8810000420
Screw FH BT M3 × 6 NI-ZU
MP49 8810009310
MP50 8930048120 Shield tape (A)
MP51 8930042690 Rubber foot (L)
MP53 8010001060 Carrying handle assembly
Screw PH FH M4 × 12 CR BS
MP54 8810003080
MP57 8930027900 Sponge (DD)
MP58 8930038820 Alumi sheet V
MP59 8930001170 Earth spring (A)
Setscrew A M3 × 6
MP61 8810003160
Setscrew A M3 × 6
MP63 8810003160
MP65 8930043281 Sponge (EW)-1
MP66 8930043800 Double coated tape (S)
MP67 8930029050 Himelon sheet AL
[CHASSIS PARTS]
REF. ORDER
QTY. DESCRIPTION
NO. NO.
1 MP68 8930032130 Himelon sheet AQ
1 MP69 8930029050 Himelon sheet AL
1 MP70 8930008670 Sponge (AQ)
MP71 8930043490 Sponge (FB)
1 MP72 8930007840 Himelon sheet K
MP73 8930043600 Sponge (FE)
1 MP74 8930043480 Sponge (FA)
1 MP75 8930041160 Himelon sheet BO
MP76 8930037830 Sponge (ED)
1 MP77 8930007840 Himelon sheet K
MP79 8930035240 1546 TR-B clip
1 MP80 8930027940 1126 TR-B clip
MP81 8930017260 758 module earth spring
1 MP83 8930043090 Sponge (EV)
1 MP85 8930049130 Shield tape (D)
1 MP86 8930052101 Shield sponge (C)-1
1 MP88 8930054550 Insulation plate GL
1 MP89 8930052271 Shield sponge (D)-1
1 MP90 8930052271 Shield sponge (D)-1
1 MP91 8930050050 Sponge (GJ)
2 MP92 8930043090 Sponge (EV)
2 MP100 8930064530 Thermally sheet (AT)
2 MP104* 8930017260 758 module earth spring
2 MP105 8930064840 Shield sponge (AO)
1
2
1
[MAIN-A UNIT]
1
11
REF. ORDER
6 DESCRIPTION
NO. NO.
4
J351 6450000140 Connector HSJ0807-01-010
11
J661 6510023670 Connector TCS4480-01-4151
3
J662 6510023660 Connector TCS4470-01-4151
6
J681 6450001490 Connector HLJ7001-01-3010
2
J691 6450001130 Connector JPJ2042-01-110
2
J701 6450000140 Connector HSJ0807-01-010
2
2
BT3501 3020000110 Lithium battery CR2032
2
4
MP1 8930014140 Earth spring (D)
7
MP2 8510012880 2178 A-shield cover assembly
5
MP3 8510012780 2178 A-shield case
4
MP5 8930032290 Sponge (DQ)
4
MP6 8930014140 Earth spring (D)
8
MP7 8930014140 Earth spring (D)
7
MP8 8930014140 Earth spring (D)
4
MP9* 8510000230 220 shield case
1
MP10* 8510000241 220 shield case cover -1
1
MP11* 8930004070 Earth spring (C)
1
1
1
3
[DSP-A BOARD]
1
4
REF. ORDER
DESCRIPTION
4
NO. NO.
4
MP1 8510012573 2178 DSP case-3
4
MP2* 8930057311 Shield sponge (I)-1
2
MP5 8930043440 Sponge (EY)
2
MP6 8930052890 Shield tape (G)
1
MP7 8930027700 Insulation sheet (E)
2
2
1
1
[CTRL-A UNIT]
2
REF. ORDER
2
DESCRIPTION
NO. NO.
1
1 MP1 8510002020 MIX shield case
1
6 - 4
[PLL UNIT]
REF. ORDER
QTY.
NO. NO.
2 MP1 8930014140 Earth spring (D)
1 MP51* 8510000230 220 shield case
2 MP101* 8510010760 1876 DDS case
1 MP102 8510010770 1876 DDS cover
2 MP103* 8510005330 Coil case
1 MP151* 8510012550 2178 DDS case
1 MP152 8510012580 2178 DDS cover
1 MP201 8510012540 2178 VCO case
2 MP202 8510011520 2072 VCO cover
4 MP203 8510011710 2072 VCO shield plate
Setscrew A M2.6 × 5
1 MP204 8810003960
1 MP301 8510005980 724 shield case
1 MP302 8510005990 724 shield case cover
1 MP401 8510010760 1876 DDS case
2 MP402 8510010770 1876 DDS cover
1 MP403* 8510005330 Coil case
1 MP451* 8510012550 2178 DDS case
1 MP452 8510012580 2178 DDS cover
1 MP501 8510012540 2178 VCO case
1 MP502 8510011520 2072 VCO cover
1 MP503 8510011710 2072 VCO shield plate
1 MP601 8510005980 724 shield case
(for PLL unit) 1 MP602 8510005990 724 shield case cover
1 MP701* 8510005980 724 shield case
MP702 8510005990 724 shield case cover
MP801 8510012550 2178 DDS case
MP802 8510012580 2178 DDS cover
MP803 8510012400 2177 D/A case
MP901* 8510005980 724 shield case
QTY. MP902 8510005990 724 shield case cover
1
1
1
[RF-B UNIT]
1
1 REF. ORDER
NO. NO.
1
MP1001* 8510016730 2178 1MIX case
MP1002* 8510016720 2178 1MIX cover
1
MP1201* 8510016730 2178 1MIX case
1 MP1202* 8510016720 2178 1MIX cover
MP1451* 8510012400 2177 D/A case
1
1 MP1751* 8510005150 602 shield case
1 MP1752* 8510005160 602 shield case cover
MP1755* 8510005150 602 shield case
1
1 MP1756* 8510005160 602 shield case cover
1 MP1801* 8510005150 602 shield case
MP1802* 8510005160 602 shield case cover
1
1 MP1851* 8510005150 602 shield case
1 MP1852* 8510005160 602 shield case cover
MP2100* 8510016550 2178 SCOPE case
MP2101* 8510016560 2178 SCOPE cover
MP2102* 8930014140 Earth spring (D)
QTY.
[TUNER-A UNIT]
1
1 REF. ORDER
NO. NO.
4
1 MF1 2710000460 Motor MP28GA
1 MF2 2710000460 Motor MP28GA
MP1 8930041090 1876 A-angle
Screw PH BT M3 × 8 NI-ZU
MP2 8810008660
Screw FH M3 × 6 ZK
MP3 8810009060
MP4 8930041110 1876 B-angle
Screw FH M3 × 6 ZK
QTY. MP5 8810009060
MP6 8820000880 1528 screw
1
MP7 8930030111 1414 plate-1
MP8 8950003200 Universal couplings UJ6-5
MP9 8930051580 2178 tuner plate
[ACCESSORIES]
REF. ORDER
DESCRIPTION QTY.
NO. NO.
1 F1 5210000090
1 F2 5210000060
1
1 W1 8900006490
1
1 MC1 7700000540
1
1
Screw abbreviations BT, B0: Self-tapping
1
1
8
1
1
1
Note *: Refer to SECTION 8.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
4
1
2
4
2
2
1
DESCRIPTION QTY.
Fuse FGB 30A 2
Fuse FGB 5A 1
Cable OPC-025 D 1
Microphone HM-36 1
PH: Pan head FH: Flat head
BiH: Binding head ZK: Black
BS: Brass NI: Nickel
CR: Chrome NI-ZU: Nickel-Zinc
