SERVICE MANUAL
Ver 1.0 2001.04
HCD-MG510AV are the Amplifier, CD player, Tape
Deck and Tuner section in MHC-MG510AV.
This stereo system is equipped with the Dolby* Pro Logic
Surround decoder.
* Manufactured under license from Dolby Laboratories.
Dolby , Pro Logic , and the double-D symbol ; are
trademarks of Dolby Laboratories. Confidential
unpublished works. '1992-1997 Dolby Laboratories.
All rights reserved.
Amplifier section
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
with 8 ohm loads both channels driven, from
120 – 10,000 Hz; rated 75 watts per channel
minimum RMS power, with no more than 10%
total harmonic distortion from 250 milliwatts to
rated output.
Front speaker:
Continuous RMS power output
75 + 75 watts
(8 ohms at 1 kHz,
10% THD)
Total harmonic distortion less than 0.09%
(8 ohms at 1 kHz,
40 watts)
Center speaker:
Continuous RMS power output
45 watts
(8 ohms at 1 kHz,
10% THD)
Rear speaker:
Continuous RMS power output
45 + 45 watts
(8 ohms at 1 kHz,
10% THD)
Sub woofer:
Continuous RMS power output
45 watts
(8 ohms at 100 Hz,
10% THD)
Sony Corporation
9-873-812-11
2001D0500-1
Home Audio Company
C 2001.4
Shinagawa Tec Service Manual Production Group
HCD-MG510AV
Model Name Using Similar Mechanism
CD Mechanism Type
CD
Section
Base Unit Name
Optical Pick-up Name
Model Name Using Similar Mechanism
TAPE
Section
Tape Transport Mechanism Type

SPECIFICATIONS

Inputs
VIDEO/MD IN (phono jacks):
voltage 250 mV/450 mV,
impedance 47 kilohms
5.1CH:
FRONT (phono jacks):
voltage 450 mV,
impedance 47 kilohms
REAR (phono jacks):
voltage 450 mV,
impedance 47 kilohms
CENTER (phono jack):
voltage 450 mV,
impedance 47 kilohms
SUB WOOFER (phono jack):
voltage 450 mV,
impedance 47 kilohms
Outputs
PHONES (stereo phone jack):
accepts headphones of
8 ohms or more
FRONT SPEAKER:
accepts impedance of 8 to
16 ohms
SURROUND SPEAKER REAR:
accepts impedance of 8 to
16 ohms
SURROUND SPEAKER CENTER:
accepts impedance of
8 ohms
SURROUND SPEAKER SUB WOOFER:
accepts impedance of
8 ohms
COMPACT DISC DECK RECEIVER
US Model
HCD-MG310AV
CDM64-K1BD44A
BU-K1BD44A
KSM-213BFN
HCD-MG310AV
CM8L6Z511A
CD player section
System
Compact disc and digital
audio system
Laser
Semiconductor laser
(λ = 780 nm)
Emission duration:
continuous
Frequency response
2 Hz – 20 kHz (±0.5 dB)
Wavelength
780 – 790 nm
Signal-to-noise ratio
More than 90 dB
Dynamic range
More than 90 dB
OPTICAL OUT (CD)
(Square optical connector jack, rear panel)
Wavelength
660 nm
Output Level
–18 dBm
Tape player section
Recording system
4-track 2-channel stereo
Frequency response
40 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassette
±0.15% W.Peak (IEC)
Wow and flutter
0.1% W.RMS (NAB)
±0.2% W.Peak (DIN)
– Continued on next page –

Advertisement

Table of Contents
loading

Summary of Contents for Sony HCD-MG510AV

  • Page 1: Specifications

    HCD-MG510AV SERVICE MANUAL US Model Ver 1.0 2001.04 HCD-MG510AV are the Amplifier, CD player, Tape Deck and Tuner section in MHC-MG510AV. This stereo system is equipped with the Dolby* Pro Logic Model Name Using Similar Mechanism HCD-MG310AV Surround decoder. * Manufactured under license from Dolby Laboratories.
  • Page 2 HCD-MG510AV SECTION 5 DIAGRAMS 5-1. BLOCK DIAGRAM – CD SERVO Section – FILTER DIGITAL SIGNAL PROCESSOR, DIGITAL FILTER, D/A CONVERTER IC101 (1/2) RF AMP, 56 53 FOCUS/TRACKING ERROR AMP IC103 DETECTOR CD +5V PCMD LRCK INTERFACE C2PO RFAC RFAC RFAC...
  • Page 3 HCD-MG510AV 5-2. BLOCK DIAGRAM – TUNER/TAPE DECK Section – TUNER PACK TUNER L-CH (Page 19) FM ANT L-CH FM 75Ω ANT GND R-CH R-CH AM ANT ANT GND TU-CLK TU-CE TUNED TUNED 5.1CH (Page 19) INPUT SELECT SWITCH IC306 PB AMP...
  • Page 4 HCD-MG510AV 5-3. BLOCK DIAGRAM – SURROUND Section – LOW-PASS SPE ANA (Page 21) FILTER IC304 (1/2) R-CH DOLBY PRO LOGIC SURROUND PROCESSOR R-CH IC301 L-CH (Page 18) WOOFER SWVOL SWIN TRIMMER, BAND-PASS SWVOL OUT VOLUME (Page 20) FILTER IC304 (2/2)
  • Page 5: Block Diagram - Amp Section

    HCD-MG510AV 5-4. BLOCK DIAGRAM – AMP Section – J503 PHONE J501 (1/2) FRONT L-CH DBFB AMP (Page 19) IC303 POWER AMP – FRONT SPEAKER IC501 IMPEDANCE R-CH USE 8Ω – RY501 MUTING MUTING OVER LOAD DBFB DBFB LEVEL Q517, 518...
  • Page 6: Block Diagram - Display/Power Supply Section

    HCD-MG510AV 5-5. BLOCK DIAGRAM – DISPLAY/POWER SUPPLY Section – GRID DRIVE LED DRIVE D703 – 707 Q721 – 723 Q713 – 717 LED DRIVE D708, 736, FL701 Q702 – 705, 718 D781, 782, 791 FLUORESCENT INDICATOR TUBE S701, 741 – 745,...
  • Page 7: Schematic Diagram - Cd Section

    HCD-MG510AV 5-7. SCHEMATIC DIAGRAM – CD Section – • • See page 35 for Waveforms. See page 23 for IC Block Diagrams. (Page 32) • Voltages and waveforms are dc with respect to ground The components identified by mark 0 or dotted under no-signal conditions.
  • Page 8: Schematic Diagram - Cd Motor/Sensor Section

    HCD-MG510AV 5-10. SCHEMATIC DIAGRAM – CD MOTOR/SENSOR Section – (Page 32) (Page 32) (Page 32) (Page 32) (Page 32) • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : CD...
  • Page 9: Schematic Diagram - Tc Section

    HCD-MG510AV 5-12. SCHEMATIC DIAGRAM – TC Section – • See page 39 for IC Block Diagram. (Page 30) • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : TAPE PLAY ) : REC...
  • Page 10: Schematic Diagram - Main Section

    HCD-MG510AV 5-13. SCHEMATIC DIAGRAM – MAIN Section (1/4) – (Page 37) (Page 31) (Page 29) (Page 32) • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : FM...
  • Page 11 HCD-MG510AV 5-14. SCHEMATIC DIAGRAM – MAIN Section (2/4) – (Page 41) (Page 30) (Page 45) (Page 37) (Page 32) (Page 33) • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : FM...
  • Page 12 HCD-MG510AV 5-15. SCHEMATIC DIAGRAM – MAIN Section (3/4) – • See page 39 for IC Block Diagram. (Page 30) (Page 31) (Page 41) (Page 24) (Page 33) (Page 27) (Page 27) (Page 27) (Page 27) (Page 27) • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions.
  • Page 13 HCD-MG510AV 5-16. SCHEMATIC DIAGRAM – MAIN Section (4/4) – • See page 35 for Waveforms. (Page 31) (Page 37) (Page 32) • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : FM ) : CD PLAY ] : TAPE PLAY ∗...
  • Page 14: Schematic Diagram - Main Amp Section

    HCD-MG510AV 5-19. SCHEMATIC DIAGRAM – MAIN AMP Section – (Page 33) (Page (Page 30) (Page 45) (Page 31) • Voltages and waveforms are dc with respect to ground The components identified by mark 0 or dotted under no-signal (detuned) conditions.
  • Page 15: Printed Wiring Board - Sub Amp Section

    HCD-MG510AV 5-20. PRINTED WIRING BOARD – SUB AMP Section – • 5-21. SCHEMATIC DIAGRAM – SUB AMP Section – See page 22 for Circuit Boards Location. SUB AMP BOARD (Page 37) 1-680-802- (11) MAIN AMP BOARD (Page 36) CN504 • Semiconductor Location Ref.
  • Page 16: Schematic Diagram - Display Section

    HCD-MG510AV 5-23. SCHEMATIC DIAGRAM – DISPLAY Section – • • See page 35 for Waveform. See page 39 for IC Block Diagram. (Page 32) (Page 31) (Page 43) • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions.
