EZ-0011
LED Evaluation Board for 78K0/IB2 PFC
Target device
78K0/IB2
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
website (http://www.renesas.com).
www.renesas.com
User's Manual
Rev.1.00
Jun 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ-0011 and is the answer not in the manual?

Questions and answers

Summary of Contents for Renesas EZ-0011

  • Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
  • Page 2 Renesas Electronics. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an application categorized as “Specific”...
  • Page 3: Safety Precautions

    Safety Precautions This document explains matters to be noted for safe use of this evaluation board. Be sure to read this document before using this evaluation board. Symbols Used This document used the following symbols for matters to be observed for the safe use of the unit. The symbols are followed by a brief explanation of the possible extent of problems which may occur if the notices are not observed.
  • Page 4 Warnings Display on Product Danger Do not use this board in the purpose except the evaluation of MCU. This board is developed for Power electronics engineer and it use is only for MCU evaluation. This board does not take safety measures or anti-EMI measures required for lighting equipment and power supply unit. Do not use this board in other countries outside Japan.
  • Page 5 Cautions Display on Product Caution To prevent damage due to static electricity, be careful of electrostatic charge when touching a metal part such as a connector. Electrostatic charge may cause failure. product...
  • Page 6 How to Use This Manual Purpose This manual is intended to give users an understanding of the basic specifications and correct usage of the EZ-0011. Organization This manual is divided into the following sections. • OVERVIEW • SPECIFICATIONS • USING EZ-0011 Related Documents Please use the following documents in conjunction with this manual.
  • Page 7: Table Of Contents

    2.1 Appearance ..........................10 2.2 Detailed Specifications ......................12 2.3 Customer-supplied Items ......................12 2.4 Settings of Major Switches and Connector Functions............13 CHAPTER 3 USING EZ-0011 ........................15 3.1 Preparation..........................15 3.1.1 Downloading software ........................15 3.1.2 Installing programming GUI for MINICUBE2 ..................15 3.1.3 Installing assembler, compiler, and integrated debugger ..............16...
  • Page 8: Chapter 1 Overview

    EZ-0011 CHAPTER 1 OVERVIEW CHAPTER 1 OVERVIEW The EZ-0011(LED Evaluation Board for 78K0/IB2 PFC) is an evaluation kit for LED control that uses the 78K0/IB2 microcontroller. This product operates with power supply of 100 - 240 VAC (50 [Hz]/60 [Hz]).
  • Page 9: Configuration Of This Product

    - DALI dimming mode - DMX512 dimming mode 1.4 Information on This Product And Related Products For information on this product and related products, visit the following URL of Renesas Electronics. URL: http://www2.renesas.com/micro/ja/solution/lighting/download.html R20UT0702EJ0100 Rev. 1.00 Page 9 of 30...
  • Page 10: Chapter 2 Specifications

    EZ-0011 CHAPTER 2 SPECIFICATIONS CHAPTER 2 SPECIFICATIONS This chapter describes the specifications of this product. 2.1 Appearance Figure 2-1. Appearance of Main Unit (1/2) (a) Appearance of the main unit Housing screw Main unit top panel - Housing screws are...
  • Page 11 EZ-0011 CHAPTER 2 SPECIFICATIONS (2/2) Figure 2-1. Appearance of Main Unit (c) Main unit right side DALI communication DALI/DMX512 Power switch connector changeover switch DMX512 AC power communication supply connector connector Power indicator LED (d) Board appearance (interior of the main unit)
  • Page 12: Detailed Specifications

    Using nonconforming items or items that do not satisfy the ratings may cause failure, heat generation, fire, or electric shock. For the circuit diagram of the EZ-0011, refer to APPENDIX A CIRCUIT DIAGRAM. R20UT0702EJ0100 Rev. 1.00 Page 12 of 30...
  • Page 13: Settings Of Major Switches And Connector Functions

    EZ-0011 CHAPTER 2 SPECIFICATIONS 2.4 Settings of Major Switches and Connector Functions Table 2-1 Power Switch Setting Power switch Power ON Power OFF Table 2-2 DALI/DMX512 Changeover Switch Setting Position Communication interface selected DALI DALI communication interface DMX512 communication interface...
  • Page 14 EZ-0011 CHAPTER 2 SPECIFICATIONS Table 2-4 Dimming Switch Setting and Microcontroller Connection Destination Port Note Switch Function Destination port Starting of auto-tuning Dimming setting for LED channel 1 Dimming setting for LED channel 2 Dimming setting for LED channel 3 Note The switch functions are the functions in the program created with the software auto generation tool Applilet EZ for HCD.
  • Page 15: Chapter 3 Using Ez-0011

    •Windows device driver for the EZ board •DALI master controller GUI •DMX512 master controller GUI Please download the software from the respective download pages for the EZ-0011 and EZ-0008 at the following URL. URL: http://www2.renesas.com/micro/ja/solution/lighting/download.html 3.1.2 Installing programming GUI for MINICUBE2 To write programs to the 78K0/IB2 on this product, the programming GUI for MINICUBE2 (QB-Programmer) is required.
  • Page 16: Installing Software Auto Generation Tool Applilet Ez For Hcd

    Files generated by his application can also be used as sample programs. Install it to the PC in the following steps. Caution To use this software, the assembler (RA78K0) and complier (CC78K0) are required. <1> Download the Applilet EZ for HCD from the download page for the EZ-0011. <2> Decompress the compressed file AppliletEZforHCD_VxxxJ.zip, and execute the installer file AppliletEZforHCD_VxxxJ.msi.
  • Page 17: Writing

    EZ-0011 CHAPTER 3 USING EZ-0011 3.2 Writing This section describes how to write a generated program (hex file) to the 78K0/IB2 installed on this product. 3.2.1 Starting write <1> Set the mode selection switch of MINICUBE2 to M2 (select the 78K0 microcontroller), and set the power supply selection switch to T (use the power supply of the target system).
  • Page 18: Operation

    EZ-0011 CHAPTER 3 USING EZ-0011 3.3 Operation This section describes how to operate the program written to this product. For information on how to write a program, refer to "3.2 Writing." 3.3.1 Steps when communication is not used <1> Make sure that the power supply of the main unit is off, and connect the load to the LED output connector.
  • Page 19: Steps When Communication Is Used

    EZ-0011 CHAPTER 3 USING EZ-0011 3.3.2 Steps when communication is used This product has the DALI communication and DMX512 communication circuits. By using the serial interface UART6/DALI incorporated on the 78K0/IB2, slave operation of DALI communication and DMX512 communication can be achieved.
  • Page 20 EZ-0011 CHAPTER 3 USING EZ-0011 Danger Do not touch to the high voltage area of the board. Touching the board by tools or body while power is being supplied cause product failure or electric shock. Do not touch with wet hands.
  • Page 21: On-Chip Debug

    EZ-0011 CHAPTER 3 USING EZ-0011 3.4 On-chip Debug The 78K0/IB2 installed on this product supports the on-chip debug function. MINICUBE2 is required for on-chip debugging. This section describes the procedure for on-chip debugging. <1> Make sure that the power supply of the main unit is off, and connect MINICUBE2 to the main unit.
  • Page 22 EZ-0011 CHAPTER 3 USING EZ-0011 Figure 3-5. Linker Option Setting Cautions 2. When performing debugging with the on-chip debug function, be careful of the positions and timing for step executions and breaks. Stopping the PFC circuit or Buck converter abruptly may damage the circuit elements on the board due to overvoltage or overcurrent, resulting in smoke or fire in the worst case.
  • Page 23: Appendix A Circuit Diagram

    EZ-0011 APPENDIX A CIRCUIT DIAGRAM APPENDIX A CIRCUIT DIAGRAM R20UT0702EJ0100 Rev. 1.00 Page 23 of 30 Jun 20, 2011...
  • Page 24: Appendix B Parts List

    EZ-0011 APPENDIX B PARTS LIST APPENDIX B PARTS LIST Table B-1. Parts List (1/4) Part Part No. Item name Manufacturer Model No. or Drawing No. Photocoupler Renesas Electronics PS2561AL-1 Photocoupler Renesas Electronics PS2561AL-1 Photocoupler Renesas Electronics PS2561AL-1 Power MOSFET Renesas Electronics...
  • Page 25 EZ-0011 APPENDIX B PARTS LIST Table B-1. Parts List (2/4) Part Part No. Item name Manufacturer Model No. or Drawing No. Fuse holder cover BULGIN 12760 Fuse (AC250[V]1.6[A]) Littlefuse 021701.6HXP Power supply IC Power Integrations LNK613DG-TL Common mode choke UF1717V-201Y1R6-01...
  • Page 26 EZ-0011 APPENDIX B PARTS LIST Table B-1. Parts List (3/4) Part Part No. Item name Manufacturer Model No. or Drawing No. Chip type resistor RK73H2ATTD2200F Chip type resistor RK73H2ATTD10R0F Chip type resistor RK73H2ATTD2200F Chip type resistor RK73B2ATTD3R3J Chip type resistor...
  • Page 27 EZ-0011 APPENDIX B PARTS LIST Table B-1. Parts List (4/4) Part Part No. Item name Manufacturer Model No. or Drawing No. Rectifying diode Shindengen Electric Manufacturing D1N60 Rectifying diode Shindengen Electric Manufacturing D1N60 Schottky Barrier diode Shindengen Electric Manufacturing D1FJ10...
  • Page 28 REVISION HISTORY EZ-0011 User’s Manual Rev. Date Description Page Summary ⎯ 1.00 Jun 20, 2011 First Edition issued C - 1...
  • Page 29 EZ-0011 User’s Manual Publication Date: Rev.1.00 Jun 20, 2011 Published by: Renesas Electronics Corporation...
  • Page 30 EZ-0011 R20UT0702EJ0100...
