innovair INVERTER DELUXE Series Service Manual

Split-type air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Deluxe Series
Service Manual
Split-Type Air Conditioner
IAwARNINGI
These instructions are intended as an aid to qualified licensed service personnel for proper
installation, adjustment and operation of this unit. Read these instructions thoroughly before
attempting installation or operation. Failure to follow these instructions may result in improper
installation, adjustment, service or maintenance possibly resulting in fire, electrical shock,
property damage, personal injury or death.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INVERTER DELUXE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for innovair INVERTER DELUXE Series

Summary of Contents for innovair INVERTER DELUXE Series

  • Page 1 Deluxe Series Service Manual Split-Type Air Conditioner IAwARNINGI These instructions are intended as an aid to qualified licensed service personnel for proper installation, adjustment and operation of this unit. Read these instructions thoroughly before attempting installation or operation. Failure to follow these instructions may result in improper installation, adjustment, service or maintenance possibly resulting in fire, electrical shock, property damage, personal injury or death.
  • Page 2 This manual is for professional maintenance personnel only...

  • Page 3: Table Of Contents

    CONTENTS Part I : Technical Information ..................1 1. Summary ........................1 1-1 Appearance ..........................1 1-2 Model List ..........................2 2. Outline Dimension Diagram ..................2 3. Function and Control ....................4 Remote Control ..........................4 4. Refrigerant System Diagram ..................9 4-1 Cooling Only ..........................

  • Page 4: Part I : Technical Information

    Service Manual DELUXE Inverter Part I : Technical Information 1. Summary 1-1 Appearance  Indoor Unit DELUXE 17 & 18 DELUXE 20  Outdoor Unit 24K/34K Note: The outdoor grille can be replaced.

  • Page 5: Model List

    Service Manual DELUXE Inverter 1-2 Model List MODEL MODEL DIN13C23A20 DIN13C13A17 DIN13C23A17 DIN18C23A20 DIN18C23A17 DIN24C23A20 LIN13H14A17 DIN24C23A17 DIN13C13A18 LIN13H24A17 DIN13C23A18 LIN18H24A17 DIN18C23A18 LIN24H24A17 DIN24C23A18 LIN36H23A17 2. Outline Dimension Diagram The following data is for reference only and the actual size may vary. Indoor Unit ...
  • Page 6 Service Manual DELUXE Inverter Outdoor Unit  Unit Size Base footing center size Package Size Cooling Capacity W1(W2)×H×D(mm) A×B(mm) W×H×D(mm) 730(780)×545×285 540×280 850×620×370 800(860)×545×315 545×315 920×620×400 825(880) × 655 × 310 540 × 335 945 × 725 × 435 900(950)×700×350 630×350 1020×770×430 Note:...

  • Page 7: Function And Control

    Service Manual DELUXE Inverter 3. Function and Control 1) Remote Controller Instructions ★ Read these instructions carefully so that you can use the air-conditioner safely and correctly. ★ Keep these instructions so that you refer to them at any time. ...
  • Page 8 Service Manual DELUXE Inverter N ote: Most remote controls contain the same function buttons. Depending on the model, they may be slightly different. 1. “ON/OFF” button You can start or stop the air-conditioner by pressing this button. 2. “SPEED” button You can select fan speed as the following: 3.
  • Page 9 Service Manual DELUXE Inverter per pressing, to enable your required timer. c. Press "TIMER" button again, to set the timer off function. 7. “DISPLAY” button You can make the LCD screen work or not by pressing this button. 8. “ ”...
  • Page 10 Service Manual DELUXE Inverter (the cooling only A/C only runs under fan mode), the internal fan runs for three minutes with weak wind before stop. The purpose of this function is to dry the inside of the evaporator and to prevent the evaporator from going moldy due to water deposition and thus dispersing strange smell.
  • Page 11 Service Manual DELUXE Inverter 2) Introduction for mode settings ★Fix batteries 1. Slide open the cover according the direction indicated by arrowhead. 2. Introduce two brand new batteries (7#)position the batteries to right electric poles (+&-). 3. Attach the back cover. ★Automatic operation mode 1.

  • Page 12: Refrigerant System Diagram

    Service Manual DELUXE Inverter on the display screen doesn't flare, batteries need to be replaced. 9. If reset phenomenon occurs on pressing the button of the remote controller the electric quantity is deficient and new batteries need to be used. 10.

  • Page 13: Cooling & Heating

    Service Manual DELUXE Inverter 4-2 Cooling & Heating  Cooling Mode Indoor Unit Outdoor Unit  Cooling Cycle Indoor heat exchanger Steam-gas of low pressure Compressor (Evaporation) (Compression) Liquid of low 4-way valve pressure (Heat pump only) (also a little gas) Gas of high pressure &...
  • Page 14 Service Manual DELUXE Inverter Indoor Unit Outdoor Unit  Heating Cycle Gas of high pressure & temperature Indoor heat exchanger Compressor (Evaporation) (Compression) 4-way valve Super cooled liquid of (Heat pump only) low pressure Steam-gas of low pressure Super cooled liquid of high pressure Capillary Outdoor heat exchanger...

  • Page 15: Part Ii : Installation And Maintenance

    Service Manual DELUXE Inverter Part II : Installation and Maintenance 5. Main Tools for Installation and Maintenance w w w . i n n o v a i r . c o m...

  • Page 16: Installation

    Service Manual DELUXE Inverter 6. Installation 6-1 Notes for Installation Important Notices  Before installation, please contact with local authorized maintenance center. If unit is not installed by the authorized maintenance center, the malfunction may not be solved due to discommodious contact.

  • Page 17: Installation Of Indoor Unit

    Service Manual DELUXE Inverter  The minimum clearance between the air conditioner and the combustibles is 1.5 m.  The power cable enables communication between the indoor and outdoor units. You must first choose the right cable size before preparing it for connection. Grounding Requirements ...
  • Page 18 Service manual DELUXE Inverter Mounting plate  1. The wall for installation of the indoor unit shall be hard and firm, so as to prevent vibration. 2. Use the "+" type screw to fasten the peg board, horizontally mount the peg board on the wall, and ensure the lateral horizontal and longitudinal vertical.
  • Page 19 Service Manual DELUXE Inverter Tightening torque table The size of pipe(mm) Torque(N·m) Φ6/Φ6.35 15～25 Φ9 /Φ9.5 2 35～40 Φ12/Φ12.7 45～60 Φ15.88 73～78 Φ19.05 75～80  Wrap the Piping 1. Use the insulation sleeve to wrap the joint part the indoor unit and connection pipe, then use insulating material to pack and seal insulation pipe to prevent condensation of water on the joint part.

  • Page 20: Installation Of Outdoor Unit

    Service Manual DELUXE Inverter Wiring Diagram NOTE: ※ This manual includes the wiring guide for a certain type of A/C. There is always a possibility that some wiring diagrams are not included. ※ The diagrams are for reference only. If the wiring from your A/C equipment is entirely different with this wiring diagram, please refer to the detailed wiring diagram adhered on the unit which you purchased.
  • Page 21 Service Manual DELUXE Inverter  Selection of Installation location  Install the connection pipe Connect the Outdoor Unit with Connecting Pipe: Aim the counterbore of the connecting pipe at the stop valve, and tighten the Taper nut with fingers. Then tighten the Taper nut with a torque wrench.
  • Page 22 Service Manual DELUXE Inverter  Wiring Connection 1. Loosen the screws and remove the cover of the E-parts unit. 2. Connect the cables respectively to the corresponding terminals of the terminal board of the outdoor unit (see the wiring diagram),and if there are signals connected to the plug, just conduct butt joint.
  • Page 23 Service Manual DELUXE Inverter  Expelling the air ★Outdoor unit refrigerant discharging method After the pipe side connection is complete, proceed as follows. ★Vacuum Pumping Method (R410A refrigerant evacuation must use the vacuum pumping method) Before working on the air conditioner, remove the cover of the stop valve(gas and liquid valves)and be sure to retighten it afterward.
  • Page 24 Service Manual DELUXE Inverter  Outdoor condensation drainage (heat pump type only) When the unit is heating, the condensing water and defrosting water can be out reliably through the drain house. Installation： Install the outdoor drain elbow in Φ25 hole on the base plate, and join the drain hose to the elbow, so that the waste water formed in the outdoor unit can be drained out to a proper plate.

  • Page 25: Maintenance

    Service Manual DELUXE Inverter ※Install batteries in remote control. ★ Test Operation method ① Turn on the power and push the ON/OFF switch button of the remote controller to start the air conditioner. ② Select COOL, HEAT (not available on cool-only models), SWING and other operation modes with the remote controller and see if the operation is ok.
  • Page 26 Service Manual DELUXE Inverter Main external control panel and module panel communication error Outdoor EE error Recirculated sensor error（four-way valve switch error） Cabinet internal fan error (see E4 for troubleshooting) Function protection prompt of frequency See the Error List conversion external machine Example: Cause: explain the principle of the specific error.
  • Page 27 Service Manual DELUXE Inverter （1）E1- internal temperature sensor error Cause: The detection of short circuit or open circuit of internal temperature sensor during the inspection of main control panel in the internal machine, Explanation of indicated by “internal temperature sensor error”. error Inspection path: Sensor→Sensor wire→Connectors→Main internal control panel...
  • Page 28 Service Manual DELUXE Inverter （2）E2 -external coil sensor error Cause: The detection of short circuit or open circuit of external coil sensor during the inspection of main external control panel, indicated by “external Explanation of coil sensor error”. error Inspection path: Sensor→Sensor wire→Connectors→Main external control panel Tools required Multimeter, 20KΩ...
  • Page 29 Service Manual DELUXE Inverter （3）E3 -internal coil sensor error Cause: The detection of short circuit or open circuit of internal coil sensor during the inspection of main internal control panel, indicated by “internal coil Explanation of sensor error”. error Inspection path: Sensor→Sensor wire→Connectors→Main internal control panel Tools required Multimeter, 5KΩ...
  • Page 30 Service Manual DELUXE Inverter （4）E4 -Internal fan motor error of wall mounted air conditioner（PG motor） Cause: PG motor is equipped with speed feedback signal line. When the feedback signal of speed is not received by the main internal control panel, it has no way to recognize the rotating speed of motor, which will be indicated as “Internal fan error”.
  • Page 31 Service Manual DELUXE Inverter (5) E4- Internal motor fan error of wall mounted air conditioner (DC motor) Cause: The internal fan of some highly energy efficient models is DC motor using a green plug through which the main internal control panel can drive the motor and sense the current rotational speed feedback.
  • Page 32 Service Manual DELUXE Inverter (6) E4- Sliding door error of floor standing Cause: For the model with upper and lower sliding doors, the position of trap door is sensed via the upper and lower photoelectric switches. When the sliding door closes, it will move upward until the upper photoelectric switch senses the sliding door;...
  • Page 33 Service Manual DELUXE Inverter (7) E5(5E) -Internal and external communication error Cause: The frequency converter needs internal and external communication. When the communication is not effective, the internal and external units will indicate “internal and external communication error”. Three elements are related to communication: “main internal control panel", "connecting cable"...
  • Page 34 Service Manual DELUXE Inverter (8) F0- External DC fan error (3-core terminal motor) Cause: Our frequency changing external unit uses the 3-lead-wire DC motor, or “externally driven DC motor” for short, after 2012. It has no speed feedback circuit but 3 drive lead wires and its driving principle is similar to that of the Explanation of compressor.
  • Page 35 Service Manual DELUXE Inverter (9) F1 -Module protection error Cause: The power module is the part that makes the compressor work. It can protect the machine in time when overcurrent, overvoltage or overheat occurs and stops the compressor from working. It will, at the same time, send “shutdown request” to the Explanation of module panel.
  • Page 36 Service Manual DELUXE Inverter (10) F2- PFC protection error Cause: PFC board is a component of the inverter air conditioner for power factor correction and voltage boosting. When the PFC board cannot perform power calibration as normal because of overcurrent and overvoltage, it will Explanation of indicate “PFC protection error”...
  • Page 37 Service Manual DELUXE Inverter (11) F3- Compressor out-of-step error Cause: The module panel will constantly test the current of lead wires of the compressor and calculate the position of the rotator of the compressor when driving the compressor to work. When the compressor deviates far from the normal operating status , it will indicate “compressor out-of-step error”...
  • Page 38 Service Manual DELUXE Inverter (12) F4- Exhaust sensor error Cause: The main external control panel will indicate “exhaust sensor error” and send it to the main internal control panel when it detects short circuit or open Explanation of circuit of the exhaust sensor. error Inspection path: Exhaust sensor→Sensor wire→Connectors→Main external control panel...
  • Page 39 Service Manual DELUXE Inverter (13) F5 -Compressor top head sensor error Cause: The compressor top head sensor is a compressor top head temperature protection switch most of the time. It keeps closed (short circuit) when the compressor temperature is normal and switches off (open circuit) when the Explanation of temperature is too high.
  • Page 40 Service Manual DELUXE Inverter （14）F6- external temperature sensor error Cause: The detection of short circuit or open circuit of external termperature sensor during the inspection of main external control panel, indicated by Explanation of "external termperature sensor error". error Inspection path: Sensor→Sensor wire→Connectors→Main external control panel Tools required Multimeter, 15KΩ...
  • Page 41 Service Manual DELUXE Inverter （15）F7-OVP or UVP error Cause: All the inverter air conditioners are equipped with voltage inspection circuits but different models of machines have different locations for the voltage inspection (on the module panel or main external control panel). When the supply voltage is lower than 135V or higher than 275V, the inspection circuit would detect over or under Explanation of voltage protection signal and send it to the main external control panel and the main...
  • Page 42 Service Manual DELUXE Inverter （16）F8-main external control panel and module panel communication error（exclusive of external machine of single panel） Cause: Only the models with the module panels separated with the main external control panels may have this error. When the machine is running normally, the module panel and the main external control panel communicate and coordinate with each other yet when the communication is off, the main external control panel can raise an alarm of...
  • Page 43 Service Manual DELUXE Inverter （17）F9- outdoor EE error Cause: Many parameters need to be preset for the running of the external unit of the air conditioner and such parameters are placed in a data storage 8-feet chip, which is called "EEPROM" or "EE" for short. The motor on the main external control panel can only work after reading the data stored in EE and if not read, the alarm "outdoor EE error"...
  • Page 44 Service Manual DELUXE Inverter （18）FA- recirculated sensor error (only models of electronic expansion valves are involved) Cause: The recirculated sensors are only used on machine models of electronic expansion valves and the back temperature value is considered as the basis for adjustment of the electronic expansion valve and to determine if the four-way valve is changing to its normal position during heating.
  • Page 45 Service Manual DELUXE Inverter （19）Function protection prompt of frequency conversion external machine Cause: During the regular functioning of the air conditioner, for some nonfaulted status, it may need the compressor to shut down or limit or lower the frequency so as to protect the normal operation of the entire cooling system (eg.

  • Page 46: Common Parameters

    Service Manual DELUXE Inverter 7-2 Common Parameters 1． Display error code of indoor unit: fix speed air conditioners only involve E1, E2, E3 and E4 Error Error Name Probable Trouble Location Code Internal room temperature Internal room temperature sensor, main internal control sensor error panel External coil sensor error...
  • Page 47 Service Manual DELUXE Inverter 2. Display error code of outdoor unit's indicator lights: Display by the 3 LED indicator lights on the control panel of the outdoor unit: ○ for off; ● for on; ★ for flashing. Error Name Probable Trouble Location Normal (outdoor ○...
  • Page 48 Service Manual DELUXE Inverter Internal coil sensor ● ○ Internal coil sensor, main internal control panel. ★ error Mechanical jam of fan, internal fan, main internal ○ ★ ● Indoor fan error control panel. Refer to tooling ○ ○ display for other Entire set of external controller.
  • Page 49 Service Manual DELUXE Inverter ② Check the connecting cord between indoor unit and outdoor unit to see if it is properly connected. The connection must be done according to the wiring diagram, please also notice that even different models may have the connecting cord of the same specification. Please check if the marks at the connecting terminal and the marks on the cord can match, otherwise, the air- conditioner will not work normally.
  • Page 50 Service Manual DELUXE Inverter  Fault Diagnosis by Symptom ①No Power Display (1) Items a) Check if the input voltage is correct. b) Check if the AC power supply connection is correct. c) Check if the output voltage of the manostat L7805 (IC2) is correct. (2) Trouble shooting procedure...
  • Page 51 Service Manual DELUXE Inverter ②The Indoor Fan Motor Does Not Work (1) Items a) Check if the indoor fan motor is connected correctly to the connector (CN8). b) Check if the AC input voltage is correct. c) Check if the IC of indoor fan motor is connected correctly to the connector (CN2). d) Check if the connector of indoor fan motor is connected correctly to the connector (CN8).
  • Page 52 Service Manual DELUXE Inverter ③The Outdoor Unit Does Not Work (1) Items a) Check if the input voltage is correct. b) Check if the wire connection of the outdoor connection terminal is correct. (2) Trouble shooting procedure...
  • Page 53 Service Manual DELUXE Inverter ④The Step Motor Does Not Work (1) Items a) Check if the input voltage is correct? b) Check if the step motor controlling the up-down movement firmly connected to Cn2? (2) Trouble shooting procedure w w w . i n n o v a i r . c o m...
  • Page 54 Service Manual DELUXE Inverter ⑤Heating Mode Works But No Hot Air Blows (1) Check if the set temperature is lower than the indoor temperature. (2) Check if the indoor PCB is connected to the terminal correctly.
  • Page 55 Service Manual DELUXE Inverter ⑥ Remote Control Does Not Work Trouble shooting procedure w w w . i n n o v a i r . c o m...

  • Page 56: Removal Procedure

    Service Manual DELUXE Inverter 8. Removal Procedure Stop operation of the air conditioner and remove the power cord before repairing the unit. 8-1 Indoor Unit  ASW-12C5A2/JAR1DI -B8、ASW-H12C5B2/JAR1DI -B7 Parts Procedure Diagram 1) Turn off the power, hold the middle panel with middle finger...
  • Page 57 Service Manual DELUXE Inverter Loosen the screws of the Medium medium frame wiring cover frame wiring with screwdriver，remove the cover electric box cover. Use thumb to open the middle Decorative frame remove panel decorative plate. Left and right Remove left and right terminal terminal board board...
  • Page 58 Service Manual DELUXE Inverter 1) Take all the connector PCB upper side out. (Including Power cord) Electrical 2) Detach the outdoor unit Parts connection wire from (Main PCB) terminal block. 3) If pulling the main PCB up, it will be taken out. Remove axial sleeve of louver Air vent, link, bend the air vent outwards...
  • Page 59 Service Manual DELUXE Inverter Remove the screw of the motor Motor press press plate and then remove the plate press plate. 1) Loosen fixing screws and detach the motor holder. 2) Loosen fixing screw of fan Fan Motor motor. (with a M6 wrench) &...
  • Page 60 Service Manual DELUXE Inverter  ASW-12C5A3/JAR1DI -C0、ASW-12C4A2/JAR1DI -C2 ASW-H12C5A3/JAR1DI -C0 Parts Procedure Diagram 3) Turn off the power, hold the middle panel with middle finger. Front Panel 4) Open the panel upwards, remove the panel fixing shaft, and remove the panel. Remove axial sleeve of air louver, bend...
  • Page 61 Service Manual DELUXE Inverter Use thumb to open the middle Decorative frame remove panel decorative plate. Left and right Remove left and right terminal terminal board board Press screw cover firmly on the middle frame , the mark Screw cover becomes unlocked, then...
  • Page 62 Service Manual DELUXE Inverter Remove axial sleeve of louver Air vent, link, bend the air vent outwards louver link and then remove the air vent and louver link. Pipeline Remove the Pipeline clamp. clamp Mounting Remove the Mounting plate. plate 1) Loosen affixed earth screws of right side.
  • Page 63 Service Manual DELUXE Inverter 1) Loosen affixed screws and detach the motor holder. 2) Loosen affixed screw of fan Fan Motor motor. (with a M6 wrench) & 3) Detach the fan motor from Cross Fan the fan. 4) Detach the fan from the left holder bearing.
  • Page 64 Service Manual DELUXE Inverter  ASW-18E3A2/JAR1DI -B8、ASW-18E1A2/J*R1DI -C0 ASW-H18E3B2/JAR1DI -B8 Parts Procedure Diagram 5) Turn off the power, hold the middle panel with middle finger Front Panel 6) open the panel upwards, remove the panel affixed shaft, and remove the panel. Remove axial sleeve of air louver, bend...
  • Page 65 Service Manual DELUXE Inverter Use thumb to open the middle Decorative frame remove panel decorative plate. Left and right Remove left and right terminal terminal board board Press screw cover firmly on the middle frame , the mark Screw cover becomes unlocked, then...
  • Page 66 Service Manual DELUXE Inverter Remove axial sleeve of louver air vent, link, bend the air vent outwards louver link and then remove the air vent and louver link. Pipeline Remove the Pipeline clamp. clamp Mounting Remove the Mounting plate. plate 1) Loosen affixed earth screws of right side.
  • Page 67 Service Manual DELUXE Inverter Remove the screw of the motor Motor press press plate and then remove the plate press plate. 1) Loosen affixed screws and detach the motor holder. 2) Loosen affixed screw of fan Fan Motor motor. (with a M6 wrench) &...
  • Page 68 Service Manual DELUXE Inverter  ASW-24F8B2/JAR1DI -B8、ASW-24F8A2/JAR1DI -C4 ASW-H24F8B2/JAR1DI -B8 Parts Procedure Diagram 7) Turn off the power, hold the middle panel with middle finger, Front Panel 8) open the panel upwards, remove the panel affixed shaft, and remove the panel. Remove axial sleeve of air louver, bend...
  • Page 69 Service Manual DELUXE Inverter Loosen the clasps of the medium medium frame , remove the frame medium frame. 1) Take all the connector of PCB upper side out.(Including Power cord) Electrical 2) Detach the outdoor unit Parts connection wire from (Main PCB) terminal block.
  • Page 70 Service Manual DELUXE Inverter Remove the screw of the motor Motor press press plate and then remove the plate press plate. 1) Loosen affixed screws and detach the motor holder. 2) Loosen affixed screw of fan Fan Motor motor. (with a M6 wrench) &...

  • Page 71: Outdoor Unit

    Service Manual DELUXE Inverter 8-2 Outdoor Unit Part Procedure Diagram Turn off the power , remove connection screws among top cover plate, front panel top cover and right side panel, then remove the top cover. Control box Remove the control box cover cover Remove connection screws between the panel grille...
  • Page 72 Service Manual DELUXE Inverter Remove connection screws connecting the front panel with the chassis and the motor Front panel support , and remove the front panel. Remove connection screws Connecting E-part cover the right side panel, then remove the E-part cover.
  • Page 73 Service Manual DELUXE Inverter Remove the nut fixing the blade and then Axial flow remove the axial flow blade. blade Remove the tapping screws that affix the Outer motor motor, pull out the lead-out wire and remove the motor. Loosen the wire and disconnect the Electric box terminal.
  • Page 74 Service Manual DELUXE Inverter Remove the tapping screws fixing the Motor motor support . Lift motor support to support remove it. Remove 2 connection screws Connecting reactor the partition board, remove the reactor. Loosen the screws of the partition board， Partition then lift and pull the partition board to board...
  • Page 75 Service Manual DELUXE Inverter Remove connection screws connecting the left side left side support plate with the valve support plate support, then remove the left side support plate. After the unit is discharged, Unscrew the Pipeline fastening nut of the 4-way Valve Assy coil assembly and remove the pipeline assembly.
  • Page 76 Service Manual DELUXE Inverter Loosen 1 footing screws of valve plate, Valve plate remove the valve plate. Loosen 3 footing screws of compressor, Compressor Remove and remove the compressor. Loosen 2 fixing screws Connecting condenser chassis, and remove the condenser. Last remaining chassis.

  • Page 77: Appendix

    Service Manual DELUXE Inverter Appendix Common Sensor R-T Analysis Table Temperature sensor R-T analysis table （15K ） Sensor standard resistance：15KΩ±3% B:B(25/50)=3950K±2％Reference temperature：25（℃） MCU_A/D exchange ±3LSB（at10bit） Series (sampling) resistor：10（KΩ）±1％ (except disk sensor) Single chip (A/D reference voltage) supply voltage：5V Temp Resistance（KΩ） MCU Input voltage（V）...
  • Page 78 Service Manual DELUXE Inverter 36.41 38.25 40.14 0.989 1.036 1.086 34.68 36.39 38.16 1.030 1.078 1.128 33.05 34.64 36.29 1.072 1.120 1.170 31.50 32.99 34.52 1.114 1.163 1.214 30.03 31.42 32.84 1.158 1.207 1.258 10.0 28.64 29.94 31.26 1.203 1.252 1.304 11.0 27.32...
  • Page 79 Service Manual DELUXE Inverter 48.0 5.532 5.812 6.101 3.094 3.162 3.231 49.0 5.319 5.593 5.875 3.138 3.207 3.275 50.0 5.115 5.382 5.659 3.181 3.251 3.319 51.0 4.919 5.180 5.450 3.225 3.294 3.362 52.0 4.732 4.987 5.251 3.267 3.336 3.405 53.0 4.553 4.802 5.060...
  • Page 80 Service Manual DELUXE Inverter 90.0 1.258 1.360 1.470 4.354 4.401 4.446 91.0 1.219 1.319 1.426 4.370 4.417 4.462 92.0 1.181 1.279 1.384 4.387 4.433 4.477 93.0 1.145 1.241 1.343 4.403 4.448 4.491 94.0 1.110 1.204 1.304 4.418 4.463 4.505 95.0 1.077 1.168 1.266...
  • Page 81 Service manual DELUXE Inverter 135.0 144.9 155.5 0.299 0.323 0.348 127.9 137.1 147.0 0.315 0.340 0.366 121.2 129.8 138.9 0.333 0.358 0.385 114.9 122.9 131.4 0.350 0.376 0.404 108.9 116.4 124.3 0.369 0.396 0.424 103.3 110.3 117.7 0.388 0.416 0.445 98.00 104.5 111.4...
  • Page 82 Service Manual DELUXE Inverter 15.54 16.10 16.66 1.864 1.916 1.970 14.88 15.43 15.98 1.913 1.966 2.022 14.25 14.79 15.33 1.962 2.017 2.074 13.65 14.18 14.71 2.011 2.068 2.127 13.08 13.59 14.12 2.061 2.119 2.179 12.53 13.04 13.55 2.111 2.170 2.231 12.01 12.51 13.01...
  • Page 83 Service manual DELUXE Inverter 2.748 2.940 3.138 3.797 3.864 3.931 2.657 2.844 3.037 3.826 3.893 3.959 2.569 2.751 2.940 3.855 3.921 3.986 2.485 2.662 2.846 3.884 3.949 4.013 2.403 2.577 2.756 3.911 3.976 4.039 2.325 2.494 2.669 3.938 4.002 4.064 2.250 2.415 2.585...
  • Page 84 Service manual DELUXE Inverter 392.2 408.8 425.8 0.059 0.062 0.065 370.7 386.1 0.062 0.065 0.069 350.5 364.8 379.6 0.066 0.069 0.072 331.5 344.9 358.6 0.069 0.073 0.077 313.7 326.2 0.073 0.077 0.081 296.9 308.6 320.5 0.078 0.081 0.085 281.2 303.2 0.082 0.086 0.090...
  • Page 85 Service manual DELUXE Inverter 42.95 43.88 44.82 0.506 0.521 0.535 41.12 42.03 42.95 0.526 0.541 0.557 39.38 40.27 41.17 0.546 0.562 0.578 37.73 38.59 39.47 0.567 0.584 0.601 36.15 37.85 0.588 0.606 0.624 34.64 35.47 36.3 0.611 0.629 0.647 33.21 34.02 34.83 0.633...
  • Page 86 Service manual DELUXE Inverter 7.479 7.775 8.079 1.923 1.981 2.039 7.224 7.512 7.809 1.963 2.022 2.081 6.979 7.26 7.549 2.004 2.063 2.123 6.743 7.017 7.299 2.044 2.104 2.165 6.516 6.783 7.059 2.085 2.146 2.208 6.298 6.558 6.827 2.126 2.187 2.250 6.088 6.342 6.603...
  • Page 87 Service manual DELUXE Inverter 1.797 1.895 1.997 3.583 3.645 3.707 1.746 1.841 1.941 3.612 3.674 3.734 1.696 1.789 1.887 3.640 3.702 3.762 1.648 1.739 1.834 3.668 3.729 3.788 1.602 1.69 1.784 3.695 3.756 3.814 1.556 1.643 1.734 3.722 3.782 3.840 1.513 1.598 1.687...
