MSB Technology Nelson LINK DAC III User Manual page 12

This upgrade installs in most digital products and provides a 192 kHz audio output compat-
ible with the LINK III family of DACs. Installs in DVD-A players, standard DVD, CD,
LD players as well as DSS systems. All sources are upsampled to 192 kHz. Multichannel
output also possible on DTS and Dolby Digital equipped players.
The GOLD LINK DAC provides an unparalleled sound experience with virtually any
available digital source. Four internal stereo DA converters give improved signal-to-noise
and channel separation characteristics, providing outstanding signal quality to your
preamplifier. The Gold has little output filtering for the best possible sound, electromagnetic
shielding of all the key components and high performance, high slew rate operational
amplifiers. This DAC delivers incredible "focus" and depth of soundstage to the listening
environment. Includes the same upgrade features as the Nelson DAC.
This 46 bit - 384 kHz sign magnitude R2R ladder DAC with four independent discrete
converters goes way beyond any other DAC. It can handle greater resolution and higher
sampling frequencies than any existing format, for maximum S/N and channel isolation. The
Platinum upsamples lower sampling rate sources to 24 bit - 96 kHz. It has up to 5 digital
inputs (ATT glass, Toslink optical, Coaxial SP/DIF, Balanced AES/EBU and MSB Net-
work) as well as balanced and single-ended analog outputs. Selectable digital filter response
(interpolation and slope) give you complete control. The painstaking detail, care and phe-
nomenal sound you demand from a high-end DAC.
The Professional Analog-to-Digital Converter does for your analog system what the LINK
DAC does for your digital system. Use it to create high resolution digital audio CDs or
DVDs from your vinyl. The MSB PAD allows you to convert analog sources to a variety
of noise resistant digital audio formats for input to your PC, recorder, equalizer/processor,
or digital playback system for the cleanest possible sound! The balanced professional inputs
and output of this product make it a cost effective addition to any studio, large or small. The
balanced analog, dedicated phono and standard line level inputs are selected from the front
panel. The PAD outputs 44.1, 48, 88.2 and 96 kHz sampling frequencies with a staggering
120 dB dynamic range.
6 RCA to DB-25
Digital Audio
AC3-RF
Audio - Triple Shielded
S-Video - 2m
Video
Toslink Optical 1m - also 2m, 15m
Red Hawk Optical 1m - also 3m, 20m
MSB Custom Digital
- for LD
