ENGLISH

Install the bobbin

CAUTION: Moving parts.
To reduce the risk of injury, switch
off before servicing. Close before
operating the machine.
1. Remove the accessories compartment by pulling it leftwards. Then open
the bobbin case by pushing down the latch on the left on the cover. Pull
out the little latch on the bobbin case and pull the bobbin case straight
out of the machine.
2. Install the bobbin into the bobbin case.
3. Pull the thread into the groove in the bobbin case.
4. Now pull the thread under the tension spring and into the opening.
Leave about 15 cm of thread hanging out of the bobbin case. When you
pull the thread, the bobbin should spin clockwise.
5. Install the bobbin case back into the sewing machine, so that the pin
compartment back into place.
12
1
2
4
3
5
