4. Maintenance and Safety

Please read the following information carefully before use.

4.1 Maintenance

Please observe the following items with regard to instrument storage and use:
(1) Keep the instrument dry: Do not place the product in a humid environment.
(2) Avoid temperature extremes: Temperature extremes (moving the instrument from a very
cold to a very warm environment, for example) will cause internal condensation. Keep the
instrument packaged when not in use.
(3) Avoid drop or shock to the instrument.
(4) Shut off the instrument before switching off the power supply or before removing the
battery.
(5) Do not subject the lens to a strong source (the sun, for example) for long periods of time.
(6) Handle SD Card and movable parts carefully and avoid contact with the camera lens.
(7) When not in use, switch off the power supply and remove battery (or unplug power cable)
and store in a dry place with excellent ventilation. Do not expose the instrument in an
environment lower than -5°C or higher than 50°C.
(8) Store the MC200 in its protective sleeve or original packaging when not in use.
4.2

Specifications

Sensing Element
Lens
Auxiliary Source
LCD
SD Memory Card
Communication
Magnification
Connection
Lithium Battery
USB Power Supply
Electrical Consumption 4V/360mA
Dimensions
Weight
Operational Conditions
2 million pixels CMOS
High-sensitivity Lens
Ultra-bright white LED x 8
2.8" TFT Color LCD
2 G Byte SD Card
USB 1.1 full speed and AV Terminal
Optical Zoom 1x~ 10 x (continuous) and 40 x; 5 x Digital Zoom
DC IN Terminal (mini USB connector)
Model: NP-120; Voltage: 3.7 V; Battery Capacity: 1800mAh
Output: 5.0/1A DC; Input: 100-240V 50/60Hz)
129 × 67 × 28 mm (5.1 x 2.6 x 1.1")
120g (4.2 oz.); 160g. (5.6 oz) with battery
Temperature: -5°C to 50°C (23°F to 122°F)
Relative Humidity: 85% (Non-condensing)
19 MC200-EU-EN V2.1 07/13
