Summary of Contents for Vivotek IZ7151
-
Page 2: Warning Before Install
Warning Before Install Power off the Network Camera Keep the Network Camera away as soon as it is found smoking or from water. If the Network Camera smelt unusual. is wet, power off immediately. Contact your distributor when such Contact your distributor when such cases happen. - Page 3 Do not place the Network Camera Do not touch the Network Camera on unsteady surfaces. when it's lightening. Do not disassemble the Network Do not drop the Network Camera. Camera. Do not insert any object into the Network Camera, such as needles. EN - 2...
-
Page 4: Check Package Contents
Check Package Contents IZ7151 Power adapter Camera stand Screws and top mounting stand Quick installation guide Software CD Warranty card EN - 3... -
Page 5: Physical Description
Physical Description Front panel Built-in Microphone Status LED Back panel External/Internal Microphone switch Microphone in Audio out Ext. Int. Audio Ethernet 10/100 Power cord socket RJ45 socket Ethernet 1 2 3 4 5 6 7 8 RESET General I/O Indented reset button terminal block EN - 4... -
Page 6: Hardware Installation
Hardware Installation Mounting the camera 1. Attach the top mounting stand to the camera using the supplied screws. 2. Fasten the camera stand to the wall / ceiling. 3. Secure the camera to the camera stand. 4. Position the camera with the lens facing the desired monitoring area. EN - 5... -
Page 7: Network Deployment
Network Deployment General Connection (without PoE) 1. Connect the camera to a switch via Ethernet cable. 2. Connect the supplied power cable from the camera to a power outlet. Ethernet switch EN - 6... -
Page 8: Power Over Ethernet (Poe)
Power over Ethernet (PoE) When using a PoE-enabled switch The camera is PoE-compliant, allowing transmission of power and data via single Ethernet cable. See the following illustration to connect the camera to a PoE- enabled switch via Ethernet cable. PoE switch When using a non-PoE switch Use a PoE power injector (optional) to connect between the camera and a non- PoE switch. -
Page 9: Assigning Ip Address
"Next" button to continue the program. Installation Wizard 2 3. The program will search the VIVOTEK Video Receivers, Video Servers or Network Cameras on the same LAN. 4. After searching, the main installer window will pop up. Click on the MAC that matches the one labeled on the bottom of your device to connect the Internet Explorer to the Network Camera. -
Page 10: Retrieving Images
Retrieving Images For further setup, please refer to user's manual on the software CD. EN - 9...
