LCD
Digital Color TV
Setup Guide
(Operating Instructions)
KDL-60EX703 / 60EX701 / 60EX700 / 55EX713 / 55EX711 / 55EX710 / 52EX703 / 52EX701
KDL-52EX700 / 46EX713 / 46EX711 / 46EX710 / 46EX703 / 46EX701 / 46EX700 / 40EX713
KDL-40EX710 / 40EX703 / 40EX700 / 32EX710 / 32EX700
4-178-827-15(1)
Setting up your TV
To watch TV
Additional Information
Sony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: www.sony.ca/support
United States
Canada
1.800.222.SONY
1.877.899.SONY
Please Do Not Return
the Product to the Store
Advertisement
Table of Contents
Related Manuals for Sony Bravia KDL-60EX703
Summary of Contents for Sony Bravia KDL-60EX703
- Page 1 Please Do Not Return the Product to the Store KDL-60EX703 / 60EX701 / 60EX700 / 55EX713 / 55EX711 / 55EX710 / 52EX703 / 52EX701 KDL-52EX700 / 46EX713 / 46EX711 / 46EX710 / 46EX703 / 46EX701 / 46EX700 / 40EX713 KDL-40EX710 / 40EX703 / 40EX700 / 32EX710 / 32EX700...
- Page 2 ® The BRAVIA Full HDTV Experience ® Thank you for choosing Sony! Your new BRAVIA • Receive over-the-air HD broadcasts with an HD- opens the door to the “Full HDTV Experience.” This quality antenna connected directly to the back of your document will help you get the most out of your TV.
-
Page 3: Table Of Contents
Table of Contents Checking the accessories......................4 Inserting batteries into the remote control ..................4 Setting up your TV Attaching the Table-Top Stand......................5 Connecting the TV.........................6 Securing the TV...........................10 Organizing the AC power cord ....................11 Running initial setup ........................11 Detaching the Table-Top Stand from the TV................12 Using a Wall-Mount Bracket ......................13 Installing the TV Against a Wall or Enclosed Area ..............13 To watch TV... -
Page 4: Checking The Accessories
Guidelines for Remote Control Checking the accessories • Point your remote control directly at the IR sensor located on your TV. AC power cord (1) • Make sure that no objects are blocking the Table-Top Stand (1)* path between the remote control and the IR (except KDL-60EX700/60EX701/60EX703 sensor on your TV. -
Page 5: Setting Up Your Tv
Setting up your TV Some TV models are packaged with a detached Attaching the Table-Top Table-Top Stand so you can mount your TV to a wall right away. If you are not mounting the Stand (except KDL-60EX700/60EX701/ TV to a wall, you will need to attach the 60EX703 models) Table-Top Stand. -
Page 6: Connecting The Tv
Connecting the TV The following chart shows the high-definition (HD) and standard-definition (SD) video formats supported by your BRAVIA TV inputs. * For supported PC formats refer to the i-Manual. Recommendation of the F type plug Projection of the inner wire from the connection part must be less than 1.5 mm. - Page 7 Shown with a Set Top Box with HDMI Shown with a Set Top Box with connection COMPONENT connection Set Top Box Set Top Box Cable System or VHF/UHF Antenna System Cable Antenna (Continued)
- Page 8 ® Shown with HD BRAVIA Sync™ Basic Connection *Rear of TV (Dish) HD Cable Box or HD Satellite Receiver *A/V Receiver SAT IN DVD IN VIDEO 2/BD IN OPT IN OPT IN COAX IN AUDIO IN AUDIO IN AUDIO IN VIDEO 1 FRONT R FRONT L...
- Page 9 Shown with PC Connection with SD VCR/DVD Rear of TV Notebook PC Splitter VCR/DVD Combo Cable/Antenna...
-
Page 10: Securing The Tv
(not supplied) Screw hole on the Table-Top Screw Stand (not supplied) Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV model name. • For United States call: 1-800-488-7669 or visit: www.sony.com/accessories • For Canada call: 1-877-899-7669... -
Page 11: Organizing The Ac Power Cord
Anchor the TV to the Wall Running initial setup Anchor the TV to the wall by using bolts, wall anchor and chain (or rope). POWER • Your TV is shipped with screws attached to the rear of the TV. (They are fastened in the screw holes for wall mounting.) Be sure to remove the upper two screws prior to anchoring the TV on a wall. -
Page 12: Detaching The Table-Top Stand From The Tv
Detaching the Table-Top Stand from the TV Remove only the screws marked with the TV. • KDL-32EX710/32EX700 models must remove the stand rear cover prior to detaching the Table- Top Stand. • Do not remove the Table-Top Stand for any reason other than to install corresponding accessories on the TV. -
Page 13: Using A Wall-Mount Bracket
For product protection and safety reasons, (6 cm) (10 cm) (10 cm) Sony strongly recommends that you use the Wall-Mount Bracket designed for your TV and the installation should be performed by a Sony dealer or licensed contractor. Leave at least this much space around the set. -
Page 14: To Watch Tv
To watch TV To watch programs Turn on the TV. Check the ENERGY SAVING GUIDE SWITCH setting is on (z). Press POWER on the TV or on the OPTIONS remote control to turn on the TV. (You HOME may use the 1 button located on the front or back of the remote control.) Select a TV channel. -
Page 15: To Use I-Manual
To use i-Manual Your BRAVIA TV comes with an on-screen manual. You can browse your i-Manual anytime you need to find the varieties of convenient functions. Press i-MANUAL. Press F/f/G/g/ to navigate and select items. i-Manual Welcome to i-Manual BRAVIA TV Features Watching TV Using the Home Menu Fun Features with Connected Equipment... -
Page 16: Additional Information
Press POWER on the TV to turn it off, disconnect the AC power cord, and inform your dealer or Sony service center of how the indicator flashes (number of flashes). When the STANDBY indicator is not flashing Check the items in the tables below. -
Page 17: How To Care For Your Bravia
How to Care for Your BRAVIA Safety is very important, please read and follow the safety documentation (Safety Booklet) separately provided. Unplug the TV and other connected equipment from the wall outlet before you begin cleaning your TV. • Wipe the LCD screen gently with a soft cloth. •... -
Page 18: Specifications
Specifications Model name KDL- 60EX703 52EX703 46EX703 40EX703 60EX701 52EX701 46EX701 32EX700 40EX700 60EX700 52EX700 46EX700 System Television system NTSC: American TV standard ATSC (8VSB terrestrial): ATSC compliant 8VSB QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality) Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69 Analog Cable: 1 - 135 / Digital Cable: 1 - 135... - Page 19 Model name KDL- 55EX713 46EX713 40EX713 55EX711 46EX711 32EX710 40EX710 55EX710 46EX710 System Television system NTSC: American TV standard ATSC (8VSB terrestrial): ATSC compliant 8VSB QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality) Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69 Analog Cable: 1 - 135 / Digital Cable: 1 - 135 Panel system LCD (Liquid Crystal Display) Panel...
- Page 20 Sufficient expertise is required for TV installations. Be equipment. sure to subcontract the installation to a Sony dealer or licensed contractor and pay adequate attention to safety Safety and Regulatory during the installation.
- Page 21 TV, visit: United States http://www.sony.com/tvsupport Software Canada http://www.sony.ca/support Updates: NOTE: If your TV is connected to the Internet, you can check for software updates by selecting Settings, Product Support and then Automatic Software Update. © 2010 Sony Corporation Printed in U.S.A.
-
Page 29: Important Safety Instructions
☐ Do not use a power line operating it further. damage to the TV and property. ☐ Use only an original Sony AC power cord Wall-Mount Bracket. When used batteries according to your local laws Do not throw anything at the operated TV set near water;... - Page 30 Le téléviseur ne doit jamais être exposé aux ☐ Ne placez pas d’ o bjets contenant des liquides, téléviseur, débranchez-le immédiatement et faites- Sony d’ o rigine pour votre téléviseur; aucune autre insecticide contenant des produits volatils. Prenez les mesures nécessaires afin d’ é viter ☐...
