Sony 40NX700 Setup Manual

Sony flat panel television user manual.
Hide thumbs

Advertisement

LCD
Digital Color TV
Setup Guide
(Operating Instructions)
KDL-60NX810 / 60NX801 / 60NX800 / 55NX811 / 55NX810 / 52NX800 / 46NX810 / 46NX800
KDL-46NX711 / 46NX710 / 46NX700 / 40NX711 / 40NX710 / 40NX700
Setting up your TV
To watch TV
Additional Information
Sony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: www.sony.ca/support
United States
Canada
1.800.222.SONY
1.877.899.SONY
Please Do Not Return
the Product to the Store
4-178-676-
(1)

Advertisement

Table of Contents

   Related Manuals for Sony 40NX700

   Summary of Contents for Sony 40NX700

  • Page 1 Digital Color TV Setup Guide (Operating Instructions) KDL-60NX810 / 60NX801 / 60NX800 / 55NX811 / 55NX810 / 52NX800 / 46NX810 / 46NX800 KDL-46NX711 / 46NX710 / 46NX700 / 40NX711 / 40NX710 / 40NX700 4-178-676- Setting up your TV To watch TV...
  • Page 2 Corporation. “XMB” and “xross media bar” are trademarks of Sony Corporation and Sony Computer Entertainment Inc. “PlayStation” is a registered trademark and “PS3” is a trademark of Sony Computer Entertainment Inc. ® DLNA , the DLNA Logo and DLNA ®...
  • Page 3: Table Of Contents

    ® The BRAVIA Full HDTV Experience Thank you for choosing Sony! Your new BRAVIA TV opens the door to the “Full HDTV Experience.” This document will help you get the most out of your Please take a moment to register your TV at: U.S.A.: http://productregistration.sony.com...
  • Page 4: Checking The Accessories

    (KDL-60NX801 and KDL-60/52/46NX800 only) Stand Rear Cover (1) Fixing screws for Table-Top Stand (M5 × 16) (4) Assembling Screws for Table-Top Stand (M5 × 16) (4) (KDL-40NX700 only) Black Spacers (4) (KDL-52/46NX800 only) Silver Spacers (4) (KDL-60NX801 and KDL-60NX800 only) Screws (M6 ×...
  • Page 5: Programming The Remote Control

    Follow the steps below to program your TV remote control. 1 Look for the code in the Manufacturer’s Code List (refer to i-Manual) that corresponds to the equipment you would like to operate with the Sony remote control. If more than one code is provided, try programming the first code listed.
  • Page 6: Setting Up Your Tv

    • Be careful to not pinch your hands or the AC power cord when you install the TV unit to the Table-Top Stand. For KDL-52/46NX800 and KDL-46/ 40NX700 Gently slide the TV unit onto the Table-Top Stand and align the screw holes.
  • Page 7 For KDL-55NX811, KDL-60/55/ 46NX810, KDL-46/40NX711 and KDL-46/40NX710 Align with the two dowels of the Table- Top Stand, and gently place the TV, checking the f mark is facing the front. Attach the TV and Table-Top Stand with the supplied screw and hexagon wrench.
  • Page 8 Adjusting the viewing angle (except 60-inch models) This TV can be adjusted within the angles shown below. For KDL-52/46NX800 and KDL-46/40NX700 0° Remove screw as shown. • Reverse the steps when readjusting the angle back to 0 degree. For KDL-55NX811, KDL-55/46NX810, KDL-46/40NX711 and KDL-46/40NX710 0°...
  • Page 9: Connecting The Tv

    Connecting the TV The following chart shows the high-definition (HD) and standard-definition (SD) video formats supported by your BRAVIA TV inputs. 720/24p format is supported by KDL-55NX811, KDL-60/55/46NX810, KDL-46/40NX711 and KDL-46/40NX710. For supported PC formats refer to the i-Manual. (Continued)
  • Page 10 Shown with a Set Top Box with HDMI connection Set Top Box Cable System or VHF/UHF Antenna System Shown with a Set Top Box with COMPONENT connection Set Top Box Cable Antenna...
  • Page 11 ® Shown with HD BRAVIA Sync™ Basic Connection *Rear of TV (Dish) Cable/ Antenna Shown with HD Basic Connection with Home Theater System Rear of TV Cable/ Antenna *A/V Receiver SAT IN DVD IN VIDEO 2/BD IN OPT IN OPT IN COAX IN AUDIO IN AUDIO IN AUDIO IN...
  • Page 12 Shown with PC Connection with SD VCR/DVD Side Panel Rear of TV Notebook PC Splitter VCR/DVD Combo Cable/Antenna...
  • Page 13: Securing The Tv

    An alternative way to secure the TV is with an optional Sony Support Belt Kit. Screw hole on the Table-Top Stand Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV model name. • For United States call: 1-800-488-7669 or visit: www.sony.com/accessories...
  • Page 14: Organizing The Ac Power Cord

    Anchor the TV to the wall by using bolts, wall anchor and chain (or rope). • KDL-60NX801, KDL-60/52/46NX800 and KDL- 46/40NX700 are shipped with screws attached to the rear of the TV. (They are fastened in the screw holes for wall mounting.) Be sure to remove the upper two screws prior to anchoring the TV on a wall.
  • Page 15: Running Initial Setup

    • Do not remove the Table-Top Stand for any reason other than to install corresponding accessories on the TV. For KDL-60NX801, KDL-60/52/ 46NX800 and KDL-46/40NX700 • The NX801/NX800/NX700 series models must remove the stand rear cover prior to detaching the Table-Top Stand.
  • Page 16: Using A Wall-mount Bracket

    Prepare the TV for the Wall-Mount Bracket before making cable connections. For product protection and safety reasons, Sony strongly recommends that you use the Wall-Mount Bracket designed for your TV and the installation should be performed by a Sony dealer or licensed contractor.
  • Page 17: To Watch Tv

    To watch TV To watch programs GUIDE OPTIONS HOME To use the TV features Press HOME to display TV Home Menu/ to access TV Settings and other ™ media and network related content. Settings Picture & Display Adjust the picture and screen settings Turn on the TV.
  • Page 18: To Use I-manual

    To use i-Manual Welcome to i-Manual BRAVIA TV Features Watching TV Introduces convenient features such as TV Guide, Favorites, etc. Using the Home Menu You can find how to customize your TV settings, etc. • Images and illustrations may differ from what you are watching on this TV. Your BRAVIA TV comes with an on-screen manual.
  • Page 19: Troubleshooting

    Press 1 (POWER) on the TV to turn it off, disconnect the AC power cord, and inform your dealer or Sony service center of how the indicator flashes (number of flashes). When the STANDBY indicator is not flashing Check the items in the tables below. (Also refer to “Troubleshooting” in the i-Manual.) If the problem persists, contact Sony Customer Support (information provided on the front cover).
  • Page 20: How To Care For Your Bravia

    How to Care for Your BRAVIA Safety is very important, please read and follow the safety documentation (Safety Booklet) separately provided. Unplug the TV and other connected equipment from the wall outlet before you begin cleaning your TV. • Wipe the LCD screen gently with a soft cloth. •...
  • Page 21: Specifications

    400 × 300 M6 (length: refer to diagram on page 16.) 36.1/79.6 28.8/63.5 43.3/95.4 30.1/66.3 24.8/54.7 46NX700 40NX700 129 W 109 W Less than 0.13 W with 120 V AC and less than 0.2 W with 240 V AC 46 inches 40 inches 34 ×...
  • Page 22 Model name KDL- System Television system NTSC: American TV standard ATSC (8VSB terrestrial): ATSC compliant 8VSB QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality) Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69 Analog Cable: 1 - 135 / Digital Cable: 1 - 135 Panel system LCD (Liquid Crystal Display) Panel...
  • Page 23 Some of these TV stand models may not be available in your area. To Customers Sufficient expertise is required for TV installations. Be sure to subcontract the installation to a Sony dealer or licensed contractor and pay adequate attention to safety during the installation. 40NX700...
  • Page 24 United States Software Canada Updates: NOTE: If your TV is connected to the Internet, you can check for software updates by selecting Settings, Product Support and then Automatic Software Update. © 2010 Sony Corporation Printed in U.S.A. http://productregistration.sony.com http://www.SonyStyle.ca/registration http://www.sony.com/tvsupport http://www.sony.ca/support...
