OKI
C7200/C7400
Color LED Page Printer

Spare Parts List

[Extracted from C7200/C7400 Maintenance Manual]
ODA/OEL/INT
2002-12-12 Rev.9
41316401TH Rev.9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C7200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oki C7200

Summary of Contents for Oki C7200

  • Page 1: Spare Parts List

    C7200/C7400 Color LED Page Printer Spare Parts List [Extracted from C7200/C7400 Maintenance Manual] ODA/OEL/INT 2002-12-12 Rev.9 41316401TH Rev.9...
  • Page 2 Oki Data CONFIDENTIAL PARTS LIST 39, 40 Figure 7-1-1/3 41316401TH Rev.9...
  • Page 3 Oki Data CONFIDENTIAL Figure 7-1-2/3 41316401TH Rev.9...
  • Page 4 Oki Data CONFIDENTIAL Board Assy.-cu 43 (Maintenance) [41848502] consists of a set of a bracket to support Motor Fan 46 (41410201), a sheet metal to secure PCB Assy-SWA 35 (41716809), a gasket bonded to that sheet metal, and screws (attached to the assembly).

  • Page 5: Main Assembly

    Oki Data CONFIDENTIAL Table 7-1-1/3 Main Assembly Recommended Q’ty/Year Patrs No. Name Q’ty Remarks /Unit 1000 2000 40864601 Front Cover Assy 41042501 Front Cover Inner Baffle 40866701 Cassette Assy 41138401 Retard Pad Assy 40864301 Rear Cover 41374902 Face Up Stacker Assy...
  • Page 6 Oki Data CONFIDENTIAL Table 7-1-2/3 Recommended Q’ty/Year Patrs No. Name Q’ty Remarks /Unit 1000 2000 41303901 Belt-Unit 41303903 Belt-Unit OEL/APS 41304105 ID-Y 41304106 ID-M 41304107 ID-C 41304108 ID-K 41304109 ID-Y OEL/APS 41304110 ID-M OEL/APS 41304111 ID-C OEL/APS 41304112 ID-K OEL/APS...
  • Page 7 Oki Data CONFIDENTIAL Table 7-1-3/3 Recommended Q’ty/Year Patrs No. Name Q’ty Remarks /Unit 1000 2000 41377401 Plate-Indicator 41716809 PCB Assy-SWA 8164323M0000 EEPROM(CU) 41356111 Board-TNO 41437418 Board-Memory 64MB 1200dpi-ODA 41437414 Board-Memory 64MB 1200dpi-OEL 41437410 Board-Memory 64MB 1200dpi-APS 41437419 Board-Memory 128MB 1200dpi Duplex-ODA...
  • Page 8 Oki Data CONFIDENTIAL Figure 7-2 41316401TH Rev.9...

  • Page 9: Top Cover Assembly

    Oki Data CONFIDENTIAL Table 7-2 Top Cover Assembly Recommended Q’ty/Year Parts No. Name Q’ty Remarks /Unit 1000 2000 40859701 Top Cover 41071401 LED Assy (1200dpi) 41072401 LED Assy (1200dpi) 41072402 LED Assy (600dpi) 40861001 LED Assy Spring 41257901 LED Control PWB (Y71)
  • Page 10 Oki Data CONFIDENTIAL Figure 7-3-1/2 41316401TH Rev.9...
  • Page 11 Oki Data CONFIDENTIAL Figure 7-3-2/2 41316401TH Rev.9...

  • Page 12: Printer Unit Chassis

    Oki Data CONFIDENTIAL Table 7-3-1/2 Printer Unit Chassis Recommended Q’ty/Year Parts No. Name Q’ty Remarks /Unit 1000 2000 41189701 Drum contact Assy 40844301 Registration Roller Assy (A) 40844303 Registration Roller Assy (B) 40845401 Registration Drive Gear 41187101 Registration Clutch 40845801...
  • Page 13 Oki Data CONFIDENTIAL Table 7-3-2/2 Recommended Q’ty/Year Parts No. Name Q’ty Remarks /Unit 1000 2000 40846001 Main Feeder Drive Motor 40848501 Main Feeder Drive Gear A 40848601 Main Feeder Drive Gear B 41303601 Left Plate Assy 40850201 Contact Assy 40737401...
  • Page 14 Oki Data CONFIDENTIAL C’ C’ Figure 7-4 41316401TH Rev.9...
  • Page 15 Oki Data CONFIDENTIAL Table 7-4 Paper Tray Guide Recommended Q’ty/Year Parts No. Name Q’ty Remarks /Unit 1000 2000 40839801 Main Feed Assy 40371301 Feed Roller 40313201 Nudger Roller 40325401 Main Feeder Drive Gear 40839001 Left Cassette Guide Assy 40839401 Right Cassette Guide Assy...
  • Page 16 Oki Data CONFIDENTIAL Figure 7-5 41316401TH Rev.9...

  • Page 17: Duplex Unit

    Oki Data CONFIDENTIAL Table 7-5 Duplex Unit Recommended Q’ty/Year Parts No. Name Q’ty Remarks /Unit 1000 2000 41305301 Duplex Transport Assy 4PB4043-4718P001 Screw (SP3×10) 4PB4083-2500P010 Screw (T3×10) 4PB4083-2500P008 Screw (T3×8) 4PB4013-3100P006 Screw (M3×6) 41372901 Duplex Unit 41372903 Duplex Unit 41372907 Duplex Unit 41316401TH Rev.9...
