- Page 1 How to remove Jammed Paper C610/C610DM/C710/ C711/C711DM/C711WT ES3032/ES6410/ES6410DM/ ES7411/ES7411DM/ES7411WT Rev.1...
-
Page 2: Paper Jams
Paper Jams Paper jams occasionally occur due to paper misfeeding from a paper tray or at any point on the paper path through the printer. When a jam occurs, the printer immediately stops and the Attention LED on the Status Panel informs you of the event. For example: This document explains how to clear them quickly and simply. - Page 3 Error codes and Location Refer to the table below to find the location of the paper jam Error Code Location on Printer Refer to Page Duplex Unit Duplex Unit Duplex Unit Duplex Unit Inside Printer Inside Printer Inside Printer Duplex Unit Inside Printer Multi Purpose Tray Paper Tray 1...
- Page 4 Error Code 370, 371, 372, 373 & 383 A paper jam has occurred near the duplex unit 1. The duplex unit is located at the rear of the 3. Remove the duplex unit from the printer. printer. Pinch and lift the jam release lever of the duplex unit to open the duplex unit cover.
- Page 5 Error Code 380, 381, 382 & 385 A paper jam has occurred inside the printer 1. Press the cover release (1) and open the 3. Cover the image drum and the toner cartridges. printer’s top cover fully (2). 4. To remove a sheet with its leading edge at the front of the belt (A), carefully lift the sheet from 2.
- Page 6 6. To remove a sheet just entering the fuser, 9. Press release lever (G) and pull the trapped separate the sheet from the belt, push the fuser paper from the fuser. pressure release lever (C) down to release the fuser’s grip on the sheet, and withdraw the sheet through the drum cavity area.
- Page 7 12. Lower the top cover but do not press down to 15. If the sheet is low down in this area and difficult latch it closed yet. This will protect the drums to remove, it is probably still gripped by the fuser. from excessive exposure to room lighting while In this case raise the top cover, reach around and you check the remaining areas for jammed...
- Page 8 Error Code 390 A paper jam has occurred near the Multi Purpose Tray 1. Pull down the Multi Purpose Tray using the 4. Close the front cover. depressions. 5. Close the Multi Purpose Tray 2. Lift the front cover release lever and lower the front cover.
- Page 9 Error Code 391, 392, 393 & 400 A paper jam has occurred while feeding paper from a paper tray. 1. Error code 400 notifies that paper of an 4. Insert the paper cassette tray back into the improper size was fed from the tray. Check the printer.
-
Page 10: Turning Off The Printer
Turning off the printer 1. Before turning off the printer, be sure to shut down by using the following procedure. Note: Pressing the OFF (O) side of the power switch suddenly, may cause the printer to be inoperable and could damage the printer. 2.
