Instruction Manual
INSTRUCTION MANUAL
M ULT I MEDI A AU DIO A N D VI SU A L
MODEL : SB-5654
1x4 HDMI DISTRIBUTION AMPLIFIER
1x4 HDMI DISTRIBUTION AMPLIFIER
HDMI DISTRIBUTION AMPLIFIER Series
Thank you for purchasing the SB-5654 1x4 HDMI DISTRIBUTION AMPLIFIER. You will fi nd this unit easy to
install and highly reliable but it is essential that you read this manual thoroughly before attempting to use this
switcher.
Advertisement
Table of Contents
Related Manuals for Shinybow USA SB-5654
Summary of Contents for Shinybow USA SB-5654
- Page 1 HDMI DISTRIBUTION AMPLIFIER Series Thank you for purchasing the SB-5654 1x4 HDMI DISTRIBUTION AMPLIFIER. You will fi nd this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting to use this...
-
Page 2: Safety Information
SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fi re, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit. -
Page 3: Table Of Contents
• Do not attach the power supply cabling to building surfaces. The SB-5654 is high quality HDMI distribution amplifi er, HD high performance designed to distribution HDMI signal. Providing I/O as • Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged. -
Page 4: Features & Specifications
FEATURES & SPECIFICATIONS FEATURES • Support 1x4 HDMI Distribution Amplifi er • I/O Signals : HDMI with HDCP Digital Video and Digital Audio (PCM) • HDMI and HDCP compliant • Support link speeds of up to 2.25 Gbps (link clock rate of 225 MHZ) •... -
Page 5: Front Panel
FRONT PANEL FRONT PANEL 1. POWER SWITCH The power switch turns the unit on and off. The LED will illuminate red to indicate that the switcher is ON and is receiving power 2. INPUT SOURCES STATUS DISPLAY Input source 1 to 4 LED illuminates blue to indicate that a video source is present on that input. 3. -
Page 6: Rear Panel
REAR PANEL REAR PANEL 1. DC POWER INLET The distributor is fi tted with a DC power plug-park input connector. Power Jack: Please ensure that the plug-park used is of an approved type and DC Jack - Inner OD ᴓ 2.1mm (+ ) is of suffi... -
Page 7: Remote Control
REMOTE CONTROL Before making any connections to the SB-5654. Observe the following: > Ensure the mains voltage supply matches the label on the > Connect all audio video sources and destination equipment supplied plug- Pack (+/- 10%) > Power up all source and destination audio-visual sources >... -
Page 8: Typical Application
2. HDMI - HDMI connector with fi x screw 3. HDMI - HDMI connector with fi x screw 4. HDMI - HDMI connector with fi x screw SB-5654 SUPPORT ONE HDMI INPUT TO FOUR HDMI DISTRIBUTOR OUTPUTS SUPPORT IR REMOTE CONTROL... -
Page 9: Limited Warranty
LIMITED WARRANTY PLEASE READ THE FOLLOWING TERMS AND CONDITIONS CAREFULLY BEFORE USING THIS HARDWARE, COMPONENTS AND SOFTWARE PROVIDED BY, THROUGH OR UNDER SHINYBOWUSA, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to SHINYBOWUSA, Inc. - Page 10 M ULT IM EDI A AUDIO AN D V IS UA L 122 Rose Ln. Suite 303 | Frisco, Texas 75034 1-877-SHINY-USA 1-877-744-6987 1-972-377-2508 sales@shinybowusa.com www.shinybowusa.com...
