CareGuard™Shower Chair
Assembly, Installation and Operating Instructions
Model Nos. 95-1, 95-2, 90-2
NOTE: Check all parts for shipping damage. In case of damage, DO NOT use. Contact
Carrier/Invacare for further instructions.
MODEL NO.
95-1
95-2
90-2
To ensure the safe and proper installation of the CareGuard Shower Chair, these
instructions MUST be followed:
DO NOT install this equipment without first reading and understanding this
instruction sheet. If you are unable to understand these Warnings, Cautions
and Instructions, contact a healthcare professional, dealer or technical
personnel if applicable before attempting to install this equipment -
otherwise, injury or damage may occur.
All four (4) leg tips MUST be in contact with shower/tub floor at all times.
Always inspect the shower chair to ensure that it is properly positioned and
stable before using. DO NOT use if shower chair is wobbly or unstable.
Check leg tips for rips, tears, cracks or wear. If any of these conditions exist,
replace leg tips immediately.
ALWAYS ensure that the snap buttons fully protrude through the same
respective adjustment hole of each adjustable leg before using.
This product should only be used with tub floors wider than 16-inches.
Users with limited physical capabilities should be supervised or assisted when
using the shower chair.
Shower chair is NOT to be used as a transfer bench, transfer device or
climbing device.
These shower chairs (Models 95-1, 95-2, and 90-2) have a weight limitation of
300 lbs (136 kg).
Exercise caution when assembling the chair to avoid pinching.
Invacare products are specifically designed and manufactured for use in con-
junction with Invacare accessories. Accessories designed by other manufac-
turers have not been tested by Invacare and are not recommended for use
with Invacare products.
For more information regarding Invacare products, parts, and services,
Part No 1118360
SAVE THESE INSTRUCTIONS
One (1) Pack Shower Chair with Back Aluminum Legs
Two (2) Pack Shower Chair with Back Aluminum Legs
Two (2) Pack Shower Chair without Back Aluminum Legs

SAFETY SUMMARY

WARNING
please visit www.invacare.com
DESCRIPTION
1
CareGuard™Shower Chair
