Installing Front Riggings on the At'm
Assembly, Installation and Operating Instructions
Kit Numbers: 9153644014, 9153644018
NOTE: Check all parts for shipping damage. In case of damage, DO NOT use. Contact
Carrier/Invacare for further instructions.
To ensure the safe and proper installation and use of the front riggings on the At'm, these
instructions MUST be followed:
After ANY adjustments, repair or service and BEFORE use, make sure that all
attaching hardware is tightened securely - otherwise injury or damage may result.
Invacare products are specifically designed and manufactured for use in conjunction
with Invacare accessories. Accessories designed by other manufacturers have not
been tested by Invacare and are not recommended for use with Invacare products.
Description of the Kit
Kit Numbers 9153644014 and 9153644018 for Red or Blue At'm Front Riggings contain:
PART NUMBER
1132651
1132652
1133151
1134702
1134703
Installing Front Rigging Support Brackets
NOTE: For this procedure, refer to FIGURE 1.
NOTE: Perform the following steps one (1) side at a time.
1. Remove the plug button from the seat frame tube.
2. Note the orientation of the hardware that connects front seat support tube to the seat
frame tube.
3. Remove the mounting screw, coved washers, spacers, washers and locknut securing
front seat support tube to the seat frame tube. DO NOT discard.
For more information regarding Invacare products, parts, and services,
Part No 1130250
SAVE THESE INSTRUCTIONS
Safety Summary
WARNING
DESCRIPTION
Right Legrest Support Assembly
Left Legrest Support Assembly
Mounting Hardware Assembly
70° Complete Right Footrest Assembly
70° Complete Left Footrest Assembly
please visit www.invacare.com
1
QUANTITY
1
1
1
1
1
Installing Front Riggings on the At'm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Invacare 9153644014
Summary of Contents for Invacare 9153644014
-
Page 1: Safety Summary
Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. Description of the Kit Kit Numbers 9153644014 and 9153644018 for Red or Blue At’m Front Riggings contain: PART NUMBER 1132651... - Page 2 4. Insert the proper (right or left) front rigging support bracket into the seat frame tube until two (2) of the four (4) mounting holes on the front rigging support bracket are aligned with the two (2) mounting holes in the seat frame tube. Two (2) mounting screws are used to secure the front rigging support bracket to the seat frame tube for any mounting position used.
- Page 3 Installing/Removing the Front Rigging Assembly NOTE: For this procedure, refer to FIGURE 2. Installing 1. Turn the front rigging assembly to the side (open footrest is perpendicular to the wheelchair). 2. Insert the mounting pin on the front rigging assembly into the front rigging support bracket.
-
Page 4: Adjusting Footrest Height
570 Matheson Blvd E Unit 8 Invacare is a registered trademark of Mississauga Ontario Invacare Corporation. L4Z 4G4 Canada Yes, you can. is a trademark of Invacare 800-668-5324 Corporation © 2005 Invacare Corporation Part No 1130250 Rev A - 06/05...
