Traynor Small Block 200H Manual

Type ys1109

Hide thumbs Also See for Small Block 200H:

Manual (12 pages)

page of 14

/ 14
Bookmarks

Available languages

Quick Links

Download this manual

Low

Input

Gain

Bass

Low-Mid

Hi-Mid

Treble

Expander

Passive

Active

Mute

SmallBlock

-6

200H

MODEL TYPE: YS1109

S ma l l Block 200 H

B A S S

G U I T A R

A M P L I F I E R

Need help?

Do you have a question about the Small Block 200H and is the answer not in the manual?

Questions and answers

Summary of Contents for Traynor Small Block 200H

Page 1 Input Gain Bass Low-Mid Hi-Mid Treble Expander Passive Active Mute SmallBlock 200H MODEL TYPE: YS1109 S ma l l Block 200 H B A S S G U I T A R A M P L I F I E R...
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is an equilateral triangle, is intended to alert the user to intended to alert the user to the presence of important the presence of uninsulated “dangerous voltage” operating and maintenance (servicing) instructions in within the product’s enclosure that may be of sufficient the literature accompanying the appliance.
Page 3 200H Small Block Bass Guitar Amplifier Small Block 200H Thank you for choosing this Small Block power amplifier. You’ll be happy to discover that this bass amplifier has the ability to sound “right” with a minimum amount of knob twirling.
Page 4 200H Pin Config 1+1– Power Spkr Out Line Out TRAYNOR SB200H Combi-Jack • Min 4 ohms Status LED and Power Switch (switch located on rear) 0dB/Passive and -6dB/Active Inputs and Clip LED – ¼-inch phone jacks Mute Control Gain Control Tone Controls –...
Page 5 1. Power Switch and Lamp The power switch is located on the rear panel next to the IEC AC power connector. When the Small Block is powered up, the power lamp which is located on the front panel illuminates red for standby, mute or protect and illuminates blue when the amp ready to use. 2.
Page 6 10. Line Out EQ Switch This feature routes the preamp signal destined for the balanced Line Out XLR either through the amp’s tone control and Scoop circuits, or around them. Depress the button (Post-EQ setting) to have the same sound as your amp going to the PA or recording mixer, or leave it in the out position (Pre-EQ setting) to send the instrument’s original, non-EQ’d signal to the board.
Page 7 SmallBlock 200H Amplificateurs Pour Guitare Basse Small Block Small Block 200H Merci d’avoir choisi cet amplificateur de puissance Small Block. Vous serez heureux d’apprendre que cet amplificateur pour basse vous offrira avec un minimum d’ajustement et d’effort, la bonne sonorité et une tonalité superbe qui les rend parfait pour pratiquement tout type de performance.
Page 8 200H Pin Config 1+1– Power Spkr Out Line Out TRAYNOR SB200H Combi-Jack • Min 4 ohms DEL d’État et Sélecteur d’Alimentation (Sélecteur situé sur le panneau arrière) DEL d’Entrée et Clip 0dB/Passive et -6dB/Active – prises phone ¼-pouce Commande Mute Commande de Gain Commandes de Tonalité–...
Page 9 à être utilisé. 2. DEL d’Entrée et Clip 0dB/Passive et -6dB/Active Le circuit d’entrée du Traynor Small Block a été conçu pour la plupart des basses. Mais les basses n’ont pas toutes été créé égale. Certaines basses disposent d’un niveau de sortie de signal élevée alors que d’autres disposent d’un niveau de sortie très bas.
Page 10 8. Prise Phones (Casque) Connectez un casque d’écoute à cette prise pour pratiquer ou enregistrer. Quand vous branchez un téléphone, vous coupez les haut-parleurs de l'amplificateur et sortie ligne; la sortie envoyé à la prise de sortie du tuner n'est pas désactivé. 9.
Page 11 Spécifications SB200H Modèle amplificateur pour basse Type: 4 ohms Impédance d'Enceinte (ohms): Puissance @ min. impédance (watts): 200 watts Impédance Minimum (ohms): 4 ohms 250 watts Puissance de Pointe - 2 cycles: Canaux d'entrée: Canal 1 - entrées: passive 0 dB, active -6 dB Canal 1 - contrôles: Gain, Bass, Low Mid, High Mid, Treble, Low Expander Mute, Ground Lift, Line Out Pré/Post EQ...
Page 13 Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date, simply return it to your Traynor dealer with original proof of purchase and it will be repaired free of charge.
Page 14 WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920 Fax: (905) 837-8746 Fax: (716) 297-3689 Manual-Owners-SMALLBLOCK200H-00-1v3• January 16, 2014...
