- Page 1 Input Gain Bass Low-Mid Hi-Mid Treble MASTER SmallBlock Expander Passive Active 500H Clip Limiter Mute Tuner Phones MODEL TYPE: YS1110 S ma l l Block 500 H B A S S G U I T A R A M P L I F I E R...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is an equilateral triangle, is intended to alert the user to intended to alert the user to the presence of important the presence of uninsulated “dangerous voltage” operating and maintenance (servicing) instructions in within the product’s enclosure that may be of sufficient the literature accompanying the appliance. - Page 3 Small Block Bass Guitar Amplifier Small Block 500H Thank you for choosing the Small Block 500H super-lightweight power amplifier. You’ll be happy to discover that this bass guitar amplifier has the ability to sound “right” with a minimum amount of knob twirling. This amp delivers great tone making it ideal for any performance.
- Page 4 Limiter Mute Tuner Phones Power SmallBlock 500H Send Return TRAYNOR SB500H Post Lift SPEAKON ™ Pin Config 1+1– Speaker Out Line Out Min 4 ohms Power Switch and Status Lamp (switch located on rear) 0dB/Passive and -6dB/Active Inputs and Clip LED – ¼-inch phone jacks...
- Page 5 The balanced Return jack is used to return effects (processed audio signals) back into the Small Block 500H. The EFX Return can also be used as an auxiliary input for mixing in a secondary source of audio such as pre-recorded music.
- Page 6 13. Line Out XLR The Line Out allows the user to connect the Small Block preamp directly to a mixing console when performing live or recording in the studio. Use a standard XLR mic cable, or an XLR female to a 1/4-inch TRS patch cable, depending on the mixer’s available inputs (it is usually best to use a 1/4-inch TRS line-level input on the board to match gain levels).
- Page 7 Input Gain Bass Low-Mid Hi-Mid Treble MASTER SmallBlock Expander Passive Active 500H Clip Limiter Mute Tuner Phones Amplificateur Pour Guitare Basse Small Block Small Block 500H. Merci d’avoir choisi l’amplificateur de puissance super-léger Small Block. Vous découvrirez que cet amplificateur de basse vous offrira le « bon » son avec un minimum de réglages des commandes et une tonalité...
- Page 8 Limiter Mute Tuner Phones Power SmallBlock 500H Send Return TRAYNOR SB500H Post Lift SPEAKON ™ Pin Config 1+1– Speaker Out Line Out Min 4 ohms Interrupteur et Témoin d’Alimentation (interrupteur situé sur le panneau arrière) Entrées 0dB/Passive, -6dB/Active et DEL Clip – prises ¼-pouce...
- Page 9 2. Entrées 0dB/Passive, -6dB/Active et DEL Clip Le circuit d’entrée du Small Block a été conçu pour la plupart des basses, mais toutes les basses n’ont pas été créées égales. Certaines basses offrent un signal très fort tandis que d’autres fournissent offrent un signal très faible. Pour une clarté optimale, utiliser l’entrée 0dB pour les guitares basses avec micros standards à...
- Page 10 La prise symétrique Return est utilisée pour retourner les signaux des effets externes au Small Block 500H. La prise EFX Return peut aussi être utilisé comme entrée auxiliaire pour mélanger une source audio secondaire comme la musique pré enregistrée.
- Page 11 Spécifications Modèle SB500H ampli pour basse Type: Impédance d'Enceinte (ohms): 4 ohms Puissance @ min. impédance (watts): 500 watts Impédance Minimum (ohms): 4 ohms 600 watts Puissance de Pointe - 2 cycles: Canaux d'entrée: Canal 1 - entrées: passive 0 dB, active -6 dB Canal 1 - commandes: Gain, Bass, Low Mid, High Mid, Treble, Low Expander Mute, Ground Lift, Line Out Pre/Post EQ, Limter, EFX send/rtn, Master...
- Page 13 Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date, simply return it to your Traynor dealer with original proof of purchase and it will be repaired free of charge.
- Page 14 WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920 Fax: (905) 837-8746 Fax: (716) 297-3689 Manual-Owners-SMALLBLOCK500H-00-1v0 • January 24, 2014...
