  • Page 1: User Manual

    Snapshot Use on Dimmer Outdoor Use Sound Activated Master/Slave External Power Supply Replaceable Fuse User Serviceable Duty Cycle Linkable Power User Manual 5200 NW 108 Ave Sunrise, FL 33351 (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com...
  • Page 2: Table Of Contents

    PECIFICATIONS CHAUVET®, 2010, All Rights Reserved Information and specifications in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Cirrus™ User Manual 2010-08-09...
  • Page 3: Before You Begin

    Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. EANING...
  • Page 4: Safety Instructions

    Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact the dealer nearest to you. Cirrus™ User Manual 2010-08-09...
  • Page 5: Non-Interlocked Housing Warning

    The legal requirements for using laser entertainment products vary from country to country. The user is responsible for the legal requirements at the location/country of use. Always use appropriate lighting safety cables when hanging lights and effects overhead. Cirrus™ User Manual 2010-08-09...
  • Page 6: Laser Safety Label Reproduction

    LASER SAFETY LABEL REPRODUCTION Cirrus™ User Manual 2010-08-09...
  • Page 7: Laser Emission Data

    This laser product complies with EN/IEC 60825-1 2007, and US FDA/CDRH FLPPS via the terms of Laser Notice No. 50 dated June 24, 2007. This laser device is Classified 3R. (Class 3R is the international equivalent of US Class IIIa). No maintenance is required to keep this product in compliance with laser performance standards. Cirrus™ User Manual 2010-08-09...
  • Page 8: Introduction

    Laser: separate red and green strobe rates or full on LED: electronic dimmer (0 – 100%) Laser & LED: rotation speed • High-power, 5 W (1,000 mA) LED • Complies with FDA / CDRH standards for Class 3R Cirrus™ User Manual 2010-08-09...
  • Page 9: Product Overview

    Hanging bracket Light output Bracket adjustment knob (2) Rubber feet (4) Safety attachment point Microphone Microphone sensitivity adjustment pot Green strobe speed Red strobe speed Power ON/OFF switch LED Dimmer Power In Rotation speed Mode switch (MANUAL/MUSIC/AUTO) Cirrus™ User Manual 2010-08-09...
  • Page 10: Proper Usage

    CAUTION: Use of controls, adjustments, or performance of procedures other than those specified herein may result in hazardous radiation exposure CAUTION: Use of controls, adjustments, or performance of procedures other than what is specified herein may result in hazardous radiation Cirrus™ User Manual 2010-08-09...
  • Page 11: Setup

    To determine the power requirements for a particular fixture, see the label affixed to the back plate of the fixture or refer to the fixture’s specifications chart. A fixture’s listed current rating indicates its average current draw under normal conditions. Cirrus™ User Manual 2010-08-09...
  • Page 12: Mounting

    Safety cables must always be used. • Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. • Do not use any tool on the bracket adjustment knob. Hand-tighten only! Cirrus™ User Manual 2010-08-09...
  • Page 13: Operation

    The DIMMER adjustment and ROTATION SPEED adjustment controls will function in this mode. However, they will work along with the program, which means that any adjustments will only work when the program sets the LED and lasers to ON. Cirrus™ User Manual 2010-08-09...
  • Page 14: Appendix

    Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET® and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return.
  • Page 15: General Troubleshooting

    No laser output Bounce mirror motor may have shifted during shipping; readjust If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support. Contact Us W o r l d W i d e General Information CHAUVET®...
  • Page 16: Technical Specifications

    PHOTO OPTIC Coverage Angle ..........................76° THERMAL Maximum ambient temperature ..................104° F (40° C) ORDERING INFORMATION Cirrus™ ............................CIRRUS WARRANTY INFORMATION Fixture Warranty (excluding laser diode) ............. 1-year limited warranty Laser Diode Warranty..................90-day limited warranty Power Supply Only! Cirrus™...
