Waeco PerfectCharge IU152A Installation And Operating Manual

Iu0u automatic charger
Hide thumbs Also See for PerfectCharge IU152A:
Table of Contents

Advertisement

Quick Links

See also: Installation and Operating Manual
PerfectCharge
IU152A, IU154A, IU252A, IU254A, IU452A,
IU404A, IU802A
DE
11 IU0U-Automatiklader
Montage- und Bedienungsanleitung
EN 36 IU0U Automatic Charger
Installation and Operating Manual
FR
58 Chargeur automatique de batteries IU0U
Instructions de montage et de service
ES
83 Cargador automático IU0U
Instrucciones de montaje y de uso
IT
108 Caricabatterie automatico IU0U
Istruzioni di montaggio e d'uso
NL
132 IUOU automatische lader
Montagehandleiding en gebruiks-
aanwijzing
DA 156 IU0U automatisk oplader
Monterings- og betjeningsvejledning
SV
178 IU0U automatisk lader
Monterings- och bruksanvisning
NO 200 IU0U-Automatisk batteriladdare
Monterings- og bruksanvisning
FI
222 IU0U-automaattilaturi
Asennus- ja käyttöohje

Advertisement

Table of Contents
loading

Related Manuals for Waeco PerfectCharge IU152A

Summary of Contents for Waeco PerfectCharge IU152A

  • Page 1 PerfectCharge IU152A, IU154A, IU252A, IU254A, IU452A, IU404A, IU802A 11 IU0U-Automatiklader 132 IUOU automatische lader Montage- und Bedienungsanleitung Montagehandleiding en gebruiks- aanwijzing EN 36 IU0U Automatic Charger DA 156 IU0U automatisk oplader Installation and Operating Manual Monterings- og betjeningsvejledning 58 Chargeur automatique de batteries IU0U...
  • Page 2 WAECO. Bestellen Sie einfach unsere Kataloge kostenlos und unverbindlich unter der Internetadresse: www.dometic-waeco.de We will be happy to provide you with further information about WAECO products. Please order our free catalogue with no obligation to buy on our homepage: www.dometic-waeco.com Demandez d’autres informations relatives à...
  • Page 3 PerfectCharge...
  • Page 4 PerfectCharge IU152A START BATT + BATT + BATT - 230 V AC INPUT IU154A, IU252A BATT 1+ BATT 2+ BATT 3+ BATT - 230 V AC INPUT IU254A, IU452A, IU404A, IU802A BATT 1+ BATT 2+ BATT 3+ BATT - 230 V AC...
  • Page 5 PerfectCharge 2 3 0 V A IN P U T...
  • Page 6 PerfectCharge...
  • Page 7 PerfectCharge 2 3 0 V A IN P U T IU152A START BATT + BATT + BATT - 230 V AC INPUT 12 V 12 V...
  • Page 8 PerfectCharge IU154A BATT 1+ BATT 2+ BATT 3+ BATT - 230 V AC INPUT 24 V 24 V 24 V IU252A BATT 1+ BATT 2+ BATT 3+ BATT - 230 V AC INPUT 12 V 12 V 12 V...
  • Page 9 PerfectCharge IU254A, IU404A BATT 1+ BATT 2+ BATT 3+ BATT - 230 V AC INPUT 24 V 24 V 24 V IU452A, IU802A BATT 1+ BATT 2+ BATT 3+ BATT - 230 V AC INPUT 12 V 12 V 12 V...
  • Page 10 PerfectCharge...

  • Page 11: Table Of Contents

    PerfectCharge Please read this manual carefully before installing and starting up the device, and store it in a safe place. If the device is passed on to another person, this manual must also be handed over with it. Table of contents Notes on using the manual .

  • Page 12: Notes On Using The Manual

    Notes on using the manual PerfectCharge Notes on using the manual Warning! Safety instruction: failure to observe this instruction can cause material damage or personal injury. Caution! Safety instruction: Failure to observe this instruction can cause material damage and impair the function of the device. Warning! Safety instruction relating to a danger from an electrical current or voltage.

  • Page 13: General Safety

    General safety instructions PerfectCharge Please observe the following basic safety information when using electrical devices to protect against: Electric shock Fire hazards Injury General safety Batteries contain aggressive acids. Avoid coming into contact with battery fluid. If your skin does come into contact with battery fluid, wash the part of your body in question and your clothes thoroughly with plenty of fresh water.

  • Page 14: Scope Of Delivery

    Scope of delivery PerfectCharge Operating the device safely If electrical devices are incorrectly installed on boats, corrosion damage might occur. The IU0U automatic charger should be in- stalled by a specialist (marine) electrician. Only operate the IU0U automatic charger if you are certain that the housing and the cables are not damaged.

  • Page 15: Accessories

    The IU0U automatic charger can be used to continuously charge supply or starter batteries. It can charge these batteries or maintain a high charge level: 12 V batteries: IU152A, IU252A, IU452A, IU802A 24 V batteries: IU154A, IU254A, IU404A The IU0U automatic charger can be used to charge the following types of bat-...

  • Page 16: Technical Description

    Your IU0U automatic charger can be used to charge batteries up to a speci- fied battery capacity (see chapter “Technical data” on page 55): IU152A: suitable for charging one supply battery and one starter battery IU154A, IU252A: suitable for charging up to two supply batteries and one...

  • Page 17: Control Elements

    TS: connection for temperature sensor (accessory) Battery connection terminals BATT 1+, BATT 2+, BATT 3+: positive terminal for supply batteries BATT –: negative terminal START BATT + (only IU152A), BATT 1+ (only IU154A, IU252A): posi- tive terminal of the starter battery...

  • Page 18: Fastening The Iu0U Automatic Charger

    Fastening the IU0U automatic charger PerfectCharge Fastening the IU0U automatic charger You can fasten the IU0U automatic charger using the four holders supplied. When selecting the installation location, observe the following instructions: You can mount the IU0U automatic charger either horizontally or vertical- Do not operate the device –...

  • Page 19: Connecting The Iu0U Automatic Charger To The Exhaust System

    Connecting the IU0U automatic charger to the exhaust system PerfectCharge Mounting the IU0U automatic charger on the wall ➤ Clip two holders on the left bar and two on the lower right bar (fig. 4, page 5). You can move the holders as required. ➤...
  • Page 20 Loose connections may cause overheating. Tighten the screws on the terminals to a torque of 12 – 13 Nm. Note IU152A: To connect starter batteries, use the special “START BATT +” terminal intended for this purpose. Note IU154A, IU252A: To connect starter batteries, use the special...
  • Page 21 ➤ Connect the positive battery cable to the respective slot: – Supply battery: “BATT 1+”, “BATT 2+”, “BATT 3+” – Starter battery: “START BATT +” (IU152A), “BATT 1+” (IU154A, IU252A) ➤ Connect the negative battery cable or earth cable to the respective slot: –...
  • Page 22 Connecting the IU0U automatic charger PerfectCharge ➤ Retighten the safety bolt (3). Connecting batteries ➤ Connect batteries according to the circuit diagram of your IU0U automatic charger. Closing the IU0U automatic charger ➤ Refit the rear panel (1) and fasten it with the screws (2). Connecting the 230 V power cable ➤...

  • Page 23: Using The Iu0U Automatic Charger

    You can use the IU0U automatic charger to trickle charge empty batteries or supply batteries. Note The chargers IU152A, IU252A and IU154A have a charger output for the starter battery with an output voltage in the range between 13.2 V (26.4 V) and 13.8 V (27.6 V). The charger output for the starter battery recharges the starter battery with a current of up to 1 A or maintains a high charge level.
  • Page 24 Using the IU0U automatic charger PerfectCharge Setting the charging voltage for IU152A, IU252A, IU452A and IU802A: Charging voltage Switch 1 Switch 2 Area of application 13.8 V Old starter batteries, mains adapter operation 14.4 V Wet and gel batteries 14.8 V...

  • Page 25: Conditioning The Battery

    Using the IU0U automatic charger PerfectCharge 10.3 Conditioning the battery To prevent any sulphation of the battery during prolonged non-use (during the winter), it must be charged beforehand. ➤ If applicable, disconnect the starter battery from the charger. ➤ Connect the battery to be charged. ➤...

  • Page 26: Charging Characteristics

    Using the IU0U automatic charger PerfectCharge 10.4 Charging characteristics The charging characteristics are referred to as modified IU0U characteristics. 8/16 h I 80% I 10% I Phase The empty battery is charged with a constant current at the beginning of the charging process, until the battery voltage reaches 13.8 V or 27.6 V.
  • Page 27 Using the IU0U automatic charger PerfectCharge U Phase If the current falls to 10% of the rated current or if the time limit of 8/16 hours is exceeded, the charger switches to trickle charge (13.8 V or 27.6 V) (U phase). Note The chargers with two or three charging connections enable batter- ies to be charged separately.

  • Page 28: Cleaning And Servicing The Iu0U Automatic Charger

    Cleaning and servicing the IU0U automatic charger PerfectCharge 10.5 Functional check The charging of the batteries can be monitored by means of an LED on the front of the device: Battery charge status I Phase Between 10% and 50% U0 Phase Between 50% and 90% U Phase Above 90%...

  • Page 29: Guarantee

    Guarantee PerfectCharge The battery is not completely charged after charging for approximately 20 hours. ➤ Disconnect the IU0U automatic charger from the mains power. ➤ Remove the charger terminals from the battery and wait for a few minutes. ➤ Use a suitable multimeter to check the voltage of the battery terminals. 12 V battery: if the multimeter indicates a voltage of 10 V or below, this means that the battery is defective and cannot be charged.

  • Page 30: Disposal

    Protect the environment! Do not dispose of any batteries with general household waste. Return defective or used batteries to your retailer or dispose of them at collection points. Technical data WAECO PerfectCharge IU152A IU252A IU154A Item no.: 2222500001...
  • Page 31 Technical data PerfectCharge WAECO PerfectCharge IU452A IU254A Item no.: 2222500004 2222500005 Battery connection 1: 13,8 – 14,8 V 27,6 – 29,6 V total max. 45 A for total max. 25 A for Battery connection 2: all three all three Battery connection 3:...
  • Page 32 Technical data PerfectCharge Variations, technical improvements and delivery options reserved. Tests/certificates applied to the IU0U automatic charger: Product series standard: IEC 60950-1:2001 (1 Edition), EN 60950-1: 2001 + A11: 2004 Basic standard: EN 55022:2006 Class B EN 55024: 1998 + A1: 2001 + A2:2003 EN 61000-3-2: 2000 + 2005 Class A EN 61000-3-3: 1995 + A1: 2001 + A2: 2005...
  • Page 33 Dometic WAECO International GmbH Hollefeldstraße 63 · D-48282 Emsdetten ℡ +49 (0) 2572 879-195 · +49 (0) 2572 879-322 Mail: info@dometic-waeco.de · Internet: www.dometic-waeco.de Europe Overseas + Middle East Dometic Austria GmbH Dometic Italy S.p.A. Dometic Australia Neudorferstrasse 108 Via Virgilio, 3...
