Cabinet - Metro DataVac C199 Series User Manual

CABINET REPLACEMENT PARTS LIST
( 1 / & 3 / height cabinet parts not shown)
2 4
Item No. Part No.
1 RPC199P-1102T
2 RPC199P-1102B
3 RPC199HP-1102
4 RPC199TP-1102
5 RPC06-809
6 RPC06-811
7 RPC06-810
8 RPC14-118
9 RPC14-119
10 C4SC
11 C4SC-T
12 C4SC-H
13 C8SN
14 C8SN-T
15 C8SN-H
16 CVSN
17 CVSN-T
18 CVSN-H
19 RPC175-1108
20 RPC199H-1108
21 RPC199T-1108
22 B5DNB
23 B5DN
24 RPC06-179A
25 RPC13-106
26 RPCAB-HBMPR
27 RPC06-067
28 RPHANG-KIT
Description
Top Door
Bottom Door
1
Door ( / height cabinet)
2
3
Door ( / height cabinet)
4
Gasket (double door units)
1
Gasket ( / height cabinet)
2
Gasket ( 3 / height cabinet)
4
Door Latch (strike plate included)
Door Hinge (complete assembly)
C4SC Rack (full height cabinet) (2 required for entire cabinet)
C4SC-T Rack ( 3 / height cabinet)
4
1
C4SC-H Rack ( / height cabinet)
2
C8SN Rack (full height cabinet)
3
C8SN-T Rack ( / height cabinet)
4
1
C8SN-H Rack ( / height cabinet)
2
CVSN Rack (full height cabinet)
3
CVSN-T Rack ( / height cabinet)
4
CVSN-H Rack ( 1 / height cabinet)
2
Chimney (full height cabinet)
Chimney ( 1 / height cabinet)
2
Chimney ( 3 / height cabinet)
4
Caster With Brake
Caster Without Brake
Drip Trough Pan — Plastic (not shown)
Snap Bushing
Handle Bumper (not shown)
Cabinet Bumper (not shown)
Rack Hanger Kit (2 right-hand and 2 left-hand hangers)
9
