Technical Specifications

Processor
Operating foltage
Card size
Array interface to host
SATA bus speed
Serial port
SATA controller
SATA ports
Physical and virtual drive
support
Cache
Firmware
Compatible devices
Cabling
Redundant configuration
Enclosure management
Enclosure support
Array support
11
Specification
®
Intel RAID Controller SRCSATAWB
LSI* 1078 Integrated RAID on Chip 500 MHz
+3.3 V, +12 V
Low profile, extended half-length (7.71-inch x 2.536-inch)
PCI Express* Rev 1.0A, x4 lane width 2.5 Gbps
3 Gbps per port, point-to-point
3-pin RS232-compatible connector for debug use only
LSI 1078
2x4 internal ports, 16 devices per port with expanders
16 drives per controller; 32 virtual drives per controller; 16 hot
spares per controller (global and/or dedicated)
128 MBs DDR2 667 MHz SDRAM, optional battery backup
4 M in reflashable flash ROM
2.5-inch and 3.5-inch SATA 3.0 drives; non disk devices
including expanders and drives of mixed capacity.
Small, thin cables do not restrict airflow; Shared connectors for
multiple drives
32 Kb NVRAM and config-on-disk (COD)
In-band and out-of-band SES2
Assumes one SEP per enclosure
128 arrays per controller; 16 drives per array; 16 virtual drives
per array.
Intel® RAID Controller SRCSATAWB Hardware User's Guide
