Chapter 3, Intel ® Raid Controller Srcsatawb Characteristics - Intel SRCSATAWB Hardware User's Manual

3
Intel
Characteristics
Jumper
J1
J2
J3
J5
J6
J7
J8
J9
J10
Intel® RAID Controller SRCSATAWB Hardware User's Guide
®
RAID Controller SRCSATAWB
Embedded RAM
J7
Battery Mount Points
Description
Dirty cache LED 2-pin
header header
On-board BIOS 2-pin
enable jumper
Serial UART port 4-pin
header
Drive fault LEDs 8x2 header
2
I C header (SES2) 3-pin
header
Battery connector Daughter
card
connector
Internal SAS/SATA SFF8087
port connector
Internal SAS/SATA SFF8087
port connector
Firmware recovery 2-pin
jumper jumper
J1 J2
LSI* 1078 ROC
Type
Provides signal to indicate cache needs to write
data.
Default is for no jumper
Debug use only
LED signal for drive fault per port for eight ports
(not available through expander)
Enclosure management support (usually a non-
expander hot-swap backplane)
Connector used for optional battery backup pack
For ports 0 - 3
For ports 4 - 7
This jumper needed only for flashes if the firmware
is corrupted. The card does not function as a
controller if this jumper is in place.
Figure 4. Card Layout
J3 Speaker
J10
Comments
s
J6
J5
J8,
ports 3 - 0
J9,
ports 7 - 4
AF002341
10
