DVD Changer
DPC-5.2
Instruction Manual
Thank you for purchasing the Integra DVD
Changer.
Please read this manual thoroughly before
making connections and turning on the
power. Following the instructions in this manual
will enable you to obtain optimum
performance and listening enjoyment from
your new DVD Changer. Please retain this
manual for future reference.
Contents
Before Using Your DVD Changer
Getting Started
Facilities and Connections
Basic Operation
Advanced Operation
Function Setup
Others
2
6
10
17
20
30
37
