DVD/VIDEO CD/CD CHANGER
DPC-6.1
Instruction Manual
Thank you for purchasing the Integra DVD Changer.
Please read this manual thoroughly before making
connections and turning on the power.
Following the instructions in this manual will enable you
to obtain optimum performance and listening
enjoyment from your new DVD Changer.
Please retain this manual for future reference.
Contents
Before Using Your DVD Changer
Getting Started
Connections
Basic Playback
Advanced Playback
Function Setup
Others
2
6
10
14
21
32
40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPC-6.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Integra DPC-6.1

Summary of Contents for Integra DPC-6.1

  • Page 1 DVD/VIDEO CD/CD CHANGER DPC-6.1 Instruction Manual Thank you for purchasing the Integra DVD Changer. Please read this manual thoroughly before making connections and turning on the power. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new DVD Changer.

  • Page 2: Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
  • Page 3 Precautions CAUTION: VISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR DEFEATED. DO NOT STARE INTO BEAM. CAUTION: THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
  • Page 4 Precautions 1. Regional restriction codes (region number) Regional restriction codes are built-in to DVD Changers and DVD videos for each sales region. If the regional code of the DVD Changer does not match one of the regional codes of the DVD video, playback is not possible. The region number can be found on the rear panel of the DVD Changer.

  • Page 5: Table Of Contents

    Disc Compatibility and Handling ... 9 Discs You can Use ... 9 Connections Connecting the DPC-6.1 to a TV ... 10 Connecting the DPC-6.1 to a TV ... 10 Connecting to an Audio System and TV with COMPONENT VIDEO Inputs ... 11 Other Audio Playback Options ...

  • Page 6: Features

    • Enhanced black-level setting • Next Selection Video Features • DTS Compatibility means the DPC-6.1 can pass a DTS- encoded digital signal from discs with DTS soundtracks to an external processor or receiver with a DTS decoder • Advanced 10-Bit 27 MHz Video D/A Conversion for four times the accuracy of conventional 8-bit, 13.5...

  • Page 7: Supplied Accessories

    Supplied Accessories After unpacking, check whether the box contains all items listed below. If anything is missing, contact the ONKYO/Integra dealer where you bought the DVD Changer. The number of accessories is indicated in brackets. Remote controller (RC-426DV) [1] Batteries for the remote controller...

  • Page 8: Preparing The Remote Controller

    Using the remote controller Point the remote controller toward the remote control sensor. DPC-6.1 Notes: • Place the unit away from strong light such as direct sunlight or inverted fluorescent light which can prevent proper operation of the remote controller.

  • Page 9: Disc Compatibility And Handling

    Disc Compatibility and Handling In this section, you will learn which discs can be used with your DPC-6.1, and how to handle, clean, and store them. Discs You can Use Your DVD Changer can play back the following discs: Disc...

  • Page 10: Connections

    • Before connecting the DVD Changer to your TV, be sure to turn off the power to and unplug both units from the wall outlet. • If your TV set has one audio input (monaural), connect a Y cable adapter to the DPC-6.1’s ANALOG OUTPUTs, and the other end of the adapter to the TV’s audio input.

  • Page 11: Connecting To An Audio System And Tv With Component Video Inputs

    Some TVs or monitors are equipped with Color Difference inputs. Connecting the DPC-6.1 to these inputs allows you to enjoy a better picture quality. Be sur e to match the DPC-6.1’s VIDEO OUTPUT s with the Component Video inputs of your TV or monitor (see the illustration).

  • Page 12: Other Audio Playback Options

    CDs to your amplifier in the digital domain if it is fitted with a digital input. See pages 10 and 11 for the video hookup of the DPC-6.1 to your TV set. When using an optical digital cable, remove the cap from the DIGITAL OUTPUT OPTICAL connector and firmly fit the cable’s jack into the connector.

  • Page 13: Connecting To An Amplifier Equipped With A Dts Decoder

    Warnings • If you connect to the digital input of an amplifier that does not have a Dolby Digital decoder or DTS decoder, set the DPC-6.1’s “Audio Out Select” function to “PCM.” Any other setting may damage your ears or speakers when using high volume levels.

  • Page 14: Playing Back Discs

    Basic Playback Preparations • To view a video disc, switch on your TV set and select the video input the DPC-6.1 is connected to. See also pages 10, 11 for how to connect the DVD Changer to your TV set.
  • Page 15 Selecting the desired disc for playback Press one of the DISC 1–6 buttons on the main unit or on the remote controller. The DPC-6.1 starts playing the first title of the selected disc. There is no need to press the <main unit>...

  • Page 16: Direct Playback, Stop And Pause

    • The sound is muted during still mode. 2. Press the PLAY button to r esume playback. Note: The DPC-6.1 also provides a function for optimum display of still pic- tures (only available for DVD videos). See “Pause/Still” on page 37. Stopping Playback Press the STOP button.

  • Page 17: Slow-Motion Playback

    REMOTE CONTROLLER RC - 426 DV Slow-Motion Playback DVD videos can be played back in slow motion. This is done by reducing the playback speed. Press the SLOW button during playback. SLOW By pressing either button repeatedly, you can cycle through the three available playback speeds.

  • Page 18: Locating Titles, Chapters, Or Tracks

    Locating Titles, Chapters, or Tracks DVD video Title 1 Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3 Normally, DVD videos are divided into “titles”, while the titles are themselves sub-divided into “chapters”. VIDEO CDs and audio CDs are divided into “tracks”. You can quickly locate any specific title, chapter, or track. Locating a Title Using the Title Menu If the DVD video you are playing back contains a title menu, you can locate any specific title you wish to play...

  • Page 19: Selecting Chapters Or Tracks

    Selecting Chapters or Tracks Direct Selection using the Numeric Buttons The DPC-6.1 also allows you to directly select a Chapter of a Title (DVD videos) or a Track (Video or audio CD). Note: Steps 1 and 2 are only necessary for DVD videos. Start with step 3 if you want to select a Track of a Video or audio CD.

  • Page 20: Selecting A Precise Scene Or Audio Passage

    Selecting a Precise Scene or Audio Passage It is also possible to directly select a given location and to start playback from there. This may come in handy when you want to view a given scene (DVD videos/Video CDs) or listen to a specific passage (audio CD) within the currently selected Title or Track.

  • Page 21: Repeat Functions

    Repeat Functions Your DVD Changer allows you to repeat a given Title, Chapter/track or disc indefinitely. It is also possible to repeat a given scene or audio passage (A–B Repeat). Repeating a Title or Chapter/Track Here is what you need to do in order to program a play- back loop of the selected Title, Chapter/track, or disc: Select the disc that contains the material to be repeated (or that you...

  • Page 22: Setting The Desired Playback Order

    Chapter : 25 Chapter : 25 Your DPC-6.1 comes with a special 28-step memory that allows you to program the order in which the Titles and Chapters/tracks are to be played back. Such “sequences” can include material from several discs.

  • Page 23: Other Memory Functions

    Here are a few programming examples: Chapters 25 and 12 of Title # 2 on disc #3 (two steps): Disc number Title number Memory 1 Memory 2 All chapters of Title #1 on disc #1: Disc number Title number Memory 3 Chapter 2 of Title #4 on disc #1: Memory 4 MEMORY...

  • Page 24: Additional Playback Functions

    DISC DISC 1–6 NEXT SELECTION REMOTE CONTROLLER RC - 426 DV Tip: You can also use the DISC SKIP button on the DPC-6.1 to select the next disc. Checking the next selection NEXT SELECTION Notes: • The function is activated. Pressing the DISC SKIP buttons or DISC +/–...

  • Page 25: Using The Dvd Changer As Cd Player

    RC - 426 DV Using the DVD Changer as CD player Since your DPC-6.1 allows you to insert up to five discs in any combination (DVD videos, Video CDs, audio CDs), there may be times when you only want to listen to music and avoid having to press the DISC SKIP or DISC +/ –...

  • Page 26: Random Playback

    Chapter : 2 The DPC-6.1’s Random playback functions allow you to select a mode where the DPC-6.1 decides which Title or Chapter/track to play next. A similar func- tion is available on most CD players. There are two Random functions: one for...

  • Page 27: Dvd Video Functions

    DVD Video Functions Zooming in The Zoom function allows you to magnify a portion of a picture. Feel free to select the area to be magnified. Press the ZOOM button during normal or ZOOM slow (see page 17) playback or while playback is paused (“still”, see page 16).

  • Page 28: Audio Playback Settings

    Recording system: Select the recording system that best matches the input capabilities of your amplifier or receiver. For example, there is little point in selecting “ 5.1. Depending on the selected recording system, the DPC-6.1 automatically converts the audio data to an acceptable format for your amplifier.
  • Page 29 • The Audio settings are not saved internally. When you switch off the DVD Changer or open the disc tray, the DPC-6.1 returns to the default setting. See page 34. • When you select an option that is not available on the selected DVD video, the DPC-6.1 ignores your setting and...

  • Page 30: Selecting The Subtitle Language

    DVD Changer or open the disc tray, the DPC- 6.1 returns to the default settings. See page 34. • When you select an option that is not available on the selected DVD video, the DPC-6.1 ignores your setting and goes on using the previously selected language, etc. (continued)

  • Page 31: Using The On-Screen Display Functions

    Information about a disc and its operational status can be monitored on your TV screen. If you want to take advantage of this feature for audio CDs, please remember to connect the DPC-6.1 to your TV set (see pages 10 and 11) and to switch it on.

  • Page 32: Function Setup

    Advanced Settings The DPC-6.1 contains a lot more functions than have been covered so far. Most of these functions can only be accessed via the on-screen menu. Please note that not all available functions apply to all disc types supported by the DPC-6.1. Setting the language, for instance, has no effect for audio CDs.
  • Page 33 Setting On-Screen Language Disc Menu Language Audio Language Subtitle Language TV Shape Black Level Audio Out Select Dynamic Range Control Karaoke Vocal Extended Audio Features On-Screen Displays OSD Background Color Extended Subtitle Features Screen Saver Pause/Still Parental Lock Title Stop Details Allows you to select the language of the on-screen displays.

  • Page 34: Language Functions

    Advanced Settings LANGUAGE On-Screen Language Disc Menu Language Audio Language Subtitle Language LANGUAGE Functions On-Screen Language This function allows you to select the language for the on-screen displays. • English • French • Spanish Disc Menu Language This function allows you to select the language used by the disc menus.

  • Page 35: Picture Settings

    Subtitle Language Use this function to select the subtitle language, or to switch the subtitles off altogether. • English • French • Spanish • No Subtitle (subtitles are switched off) • Others: To select another language than the above, see steps (a) – (e) under “Disc Menu Lan- guage”.

  • Page 36: Audio Settings

    Karaoke Vocal DVD Karaoke discs sometimes also contain a vocal track you probably don’t need for Karaoke applications. That is why the DPC-6.1 allows you to switch the lead vocal off. Off: The lead vocal track is muted. If available on the selected DVD Karaoke disc, the lead vocal track is output.

  • Page 37: Display Settings

    DVD videos equipped with the Parental Lock function allow you to decide what exactly can be viewed on your DPC-6.1, which is especially useful if you have children. For example: you could select a level where violent scenes unsuitable for children are skipped and replaced with more suitable scenes, or prevent play- back of a disc altogether.

  • Page 38: Changing The Parental Lock Level

    Title Stop This function allows you to specify what happens when the DPC-6.1 reaches the end of a DVD Title. Off: The DPC-6.1 continues after playback of a Title is completed. Selecting this option also changes the...

  • Page 39: Table Of Languages

    Table of Languages Table of Languages and Their Abbreviations Abbreviation Abbreviation of the Language of the Language Language ––– No alternate language CHI (ZH) Chinese DUT (NL) Dutch ENG (EN) English FRE (FR) French GER (DE) German ITA (IT) Italian JPN (JA) Japanese KOR (KO)

  • Page 40: Others

    Troubleshooting If your DPC-6.1 does not seem to work as expected, check the following table for the possible cause before contacting your ONKYO/Integra dealer or service. Symptoms and Corrections Symptom No power. • The power plug is disconnected. No picture.

  • Page 41: Identification Of Controls

    Identification of Controls See the pages in [ ] for details. Front Panel Repeat button [21] Dimmer button [42] Standby/On indicator [14] Standby/On button [14] Power Power button Standby/On [14] O f f Direct Digital Path Rear Panel COMPONENT VIDEO OUT jacks [11] COMPONENT ANALOG...

  • Page 42: Display

    Identification of Controls Display Track number indicator Chapter number indicator Group number indicator Title number indicator NEXT DISC indicator The indicators vary depending on the kinds of discs you play. DVD video • When closing the disc tray: Example Total number of titles •...

  • Page 43: Remote Controller

    Most steps in this manual need to be per formed using the supplied remote contr oller. That is why the functions of the remote contr oller’s buttons are explained in the relative chapters and sections. See the pages in [ ] for details.

  • Page 44: Specifications

    • Design and specifications are subject to change without notice. Integra Division of ONKYO U.S.A. CORPORATION 200 Williams Drive, Ramesy, N.J. 07446, U.S.A. Tel: 201-825-7950 Fax: 201-825-8150 E-mail: integra@onkyousa.com Integra Division of ONKYO CORPORATION Sales & Product Planning Div. :...
