Manual
Model No. WLTL29400
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through di-
rect assistance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
¨
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo WLTL29400
Summary of Contents for Weslo WLTL29400
- Page 1 ¨ USER'S MANUAL Model No. WLTL29400 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee complete satisfaction through di- rect assistance from our factory.
-
Page 2: Table Of Contents
120 volts AC and 15 amps. To purchase a surge suppressor, see 6. Keep children under the age of 12 and pets your local WESLO dealer or call 1-800-999- away from the treadmill at all times. 3756 and order part number 146148. - Page 3 14. Never start the treadmill while you are 19. Inspect and tighten all parts of the treadmill standing on the walking belt. Always hold every three months. the handrails while using the treadmill. 20. Never drop or insert any object into any 15.
-
Page 4: Before You Begin
The model youÕre not exercising, the unique CADENCE 325 can number of the treadmill is WLTL29400. The serial be folded up, requiring less than half the floor space of number can be found on a decal attached to the tread- other treadmills. -
Page 5: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Refer to the drawings below to identify the parts used in assembly. Assembly requires the following tools: The included allen wrench and your own phillips screwdriver , mallet... - Page 6 3. Slide a Rubber Ring (74) onto the post on each Upright (14). Refer to the inset drawing. Make sure that each Rubber Ring is turned so the tapered edge is toward Post the thickest part of the post. Post Tapered Edge 4.
-
Page 7: Operation And Adjustment
To purchase a surge suppressor, see your local The temporary adapter should be used only until a WESLO dealer or call 1-800-999-3756 and order part properly grounded outlet (drawing 1) can be installed number 146148. Use only a single-outlet surge sup- by a qualified electrician. - Page 8 DIAGRAM OF THE CONSOLE Displays Speed Control Clip CAUTION: Before operating the ¥ Adjust the speed in small increments. console, read the following precautions. ¥ The training zones marked above the speed control are general guidelines only. See page ¥ Do not stand on the walking belt when turning 14 for more information.
- Page 9 FAT BURNING on page 14.) In addition, the dis- Insert the key fully into the power switch. play shows the speed of the walking belt, in miles per hour. Every seven seconds, the display will Inserting the key will change from one number to the next. Arrows in the not turn on the dis- display will indicate which number is currently plays.
-
Page 10: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. Caution: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1. - Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left thumb, press the storage latch and hold it. Pivot the treadmill until the frame and foot rail are past the storage latch.
-
Page 12: Trouble-Shooting
TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). 1. -
Page 13: Is Ul 1449 Listed As A Transient Voltage Surge
4. SYMPTOM: THE WALKING BELT SLOWS WHEN WALKED ON a. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS). The surge suppressor must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation of 450 joules. -
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES Aerobic Exercise WARNING: Before beginning If your goal is to strengthen your cardiovascular sys- this or any exercise program, consult your tem, your exercise must be Òaerobic.Ó Aerobic exercise physician. This is especially important for in- is activity that requires large amounts of oxygen for dividuals over the age of 35 or individuals prolonged periods of time. - Page 15 Training Zone Exercise to cool down. This will increase the flexibility of your muscles and will help to prevent post-exercise problems. After warming up, increase the intensity of your exer- cise until your pulse is in your training zone for 20 to Exercise Frequency 60 minutes.
- Page 16 PART LISTÑModel No. WLTL29400 R0800A Key No. Qty. Description Key No. Qty. Description Key/Clip Belt Guide Handrail Belly Pan Electronic Screw Releasable Tie Handrail Screw Cable Tie Clamp Rear Isolator Screw Motor Belly Pan Console Base 7 1/2Ó Cable Tie Speed Control Knob 8Ó...
-
Page 18: Ordering Replacement Parts
If possible, place the treadmill near your telephone for easy reference when calling. WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
